USG Stihl Rakers Setup (Optimize Chain Performance Tips)

A Quick Note on Pet-Friendly Chainsaw Use

Before diving into the technical details, it’s crucial to address safety, not just for ourselves but also for our pets. Chainsaws are inherently dangerous, and the noise and flying debris can be particularly distressing for animals. Always keep pets a safe distance away from your work area. Consider using hearing protection for your dogs if they are particularly sensitive to loud noises. When storing your chainsaw and fuel, ensure they are out of reach of pets to prevent accidental ingestion or contact with harmful substances. Clean up sawdust and wood chips regularly, as some wood types can be toxic if ingested. Prioritizing pet safety ensures a safer and more enjoyable wood processing experience for everyone.

Understanding Rakers: The Key to Chainsaw Performance

The rakers, also known as depth gauges, are the small, rounded projections located in front of each cutting tooth on your chainsaw chain. Their primary function is to regulate the depth of cut each tooth takes. Think of them as the “gatekeepers” of your cutting performance. If the rakers are too high, the teeth won’t bite into the wood effectively, resulting in slow cutting and excessive vibration. If they’re too low, the teeth will take too big of a bite, leading to aggressive cutting, increased risk of kickback, and potential damage to the chain and saw.

Why Raker Adjustment Matters

Proper raker adjustment is crucial for several reasons:

• Cutting Efficiency: Correctly adjusted rakers allow the teeth to cut at their optimal depth, maximizing cutting speed and minimizing effort.
• Safety: Properly set rakers reduce the risk of kickback, a dangerous situation where the saw abruptly jumps back towards the operator.
• Chain Longevity: When rakers are properly adjusted, the chain experiences less stress and wear, extending its lifespan.
• Smooth Cutting: Correctly adjusted rakers contribute to a smoother, more controlled cutting experience with less vibration.
• Fuel Efficiency: A properly cutting saw requires less power, resulting in improved fuel economy.

Key Terms and Concepts

Before we delve into the adjustment process, let’s define some key terms:

• Raker (Depth Gauge): The projection in front of each cutting tooth that controls the depth of cut.
• Cutting Tooth: The sharp, chisel-shaped part of the chain that does the actual cutting.
• Kickback: A sudden and forceful backward movement of the chainsaw, often caused by the tip of the bar contacting an object.
• Filing: Sharpening the cutting teeth of the chain.
• Raker Gauge (Depth Gauge Tool): A specialized tool used to measure and file the rakers to the correct height.
• Flat File: A hand file used to lower the rakers.
• Depth Gauge Setting: The specific height of the raker relative to the cutting tooth, typically measured in thousandths of an inch (e.g., 0.025″).
• Green Wood: Freshly cut wood with a high moisture content.
• Seasoned Wood: Wood that has been dried to a lower moisture content, typically through air-drying or kiln-drying. Green wood is generally more difficult to cut than seasoned wood.

Step-by-Step Guide to USG Stihl Raker Setup

Now, let’s get to the practical part. Here’s a detailed, step-by-step guide to adjusting the rakers on your Stihl chainsaw:

Step 1: Gather Your Tools and Materials

You’ll need the following tools and materials:

• Chainsaw: Your Stihl chainsaw, of course. Make sure it is in good working order and properly maintained.
• Raker Gauge (Depth Gauge Tool): This is essential for accurate adjustment. Stihl makes specific raker gauges for their chains, but universal gauges are also available.
• Flat File: A high-quality flat file with a smooth surface. An 8-inch or 10-inch file is typically sufficient.
• File Handle: A handle for your flat file to improve grip and control.
• Vise: A sturdy vise to securely hold the chainsaw bar.
• Gloves: Safety gloves to protect your hands.
• Eye Protection: Safety glasses or goggles to protect your eyes from metal filings.
• Work Light: Adequate lighting to see the rakers and cutting teeth clearly.
• Marker or Pen: To mark the rakers you’ve already adjusted.
• Depth Gauge Adjustment Chart: This chart, often found in your chainsaw’s manual or on the Stihl website, specifies the correct raker setting for your specific chain type and cutting conditions.

Step 2: Secure the Chainsaw Bar

• Remove the chain from your chainsaw. This makes the process much easier and safer.
• Secure the chainsaw bar in a vise. Ensure the bar is held firmly but not so tightly that it becomes damaged. The cutting teeth and rakers should be easily accessible.

Step 3: Inspect the Chain

• Carefully inspect the entire chain for any damage, such as broken or chipped teeth, loose rivets, or excessive wear. Replace the chain if it’s significantly damaged.
• Check the overall condition of the chain. Is it clean? If not, clean the chain with a brush and solvent to remove any dirt, oil, or debris. This will make it easier to see the rakers and cutting teeth.
• Examine the cutting teeth for sharpness. If the teeth are dull, sharpen them before adjusting the rakers. Adjusting rakers on a dull chain is counterproductive.

Step 4: Determine the Correct Raker Setting

• Consult your chainsaw’s manual or the Stihl website to find the recommended raker setting for your specific chain type and cutting conditions.
• The raker setting is typically expressed in thousandths of an inch (e.g., 0.025″, 0.030″).
• The optimal setting can vary depending on the type of wood you’re cutting (softwood vs. hardwood, green wood vs. seasoned wood) and your cutting style.
• General Guidelines:
  • Softer Woods (Pine, Fir): A slightly lower raker setting (e.g., 0.030″) can improve cutting performance.
  • Harder Woods (Oak, Maple): A slightly higher raker setting (e.g., 0.025″) may be necessary to prevent the chain from bogging down.
  • Green Wood: A higher raker setting (e.g., 0.020″) is often recommended to prevent the chain from clogging.
  • Frozen Wood: A very high raker setting (e.g., 0.015″) is recommended.
  • For general purpose cutting: Sticking with the manufacturer’s recommendation is your best bet.

Step 5: Use the Raker Gauge

• Place the raker gauge on the chain so that it sits over a cutting tooth and the adjacent raker.
• The gauge will have a slot or opening that indicates the correct raker height.
• If the raker extends above the gauge, it needs to be filed down. If it’s below the gauge, it’s already at or below the correct height.

Step 6: File the Rakers

• If the raker extends above the gauge, carefully file it down using the flat file.
• Hold the file flat and at a slight angle to the top of the raker.
• Use smooth, even strokes to remove material. Avoid applying too much pressure, as this can damage the raker.
• File the raker until it is flush with the top of the gauge.
• Important: Only file the top of the raker. Do not file the sides.

Step 7: Round the Raker

• After filing the raker to the correct height, use the file to slightly round the front edge of the raker. This helps prevent the raker from digging into the wood and causing kickback.
• A rounded raker also allows for smoother chip flow.

Step 8: Repeat for All Rakers

• Repeat steps 5-7 for all the rakers on the chain.
• It’s important to adjust all the rakers to the same height to ensure consistent cutting performance.
• Use a marker or pen to mark the rakers you’ve already adjusted to avoid missing any.

Step 9: Reassemble and Test

• Once you’ve adjusted all the rakers, remove the chain from the vise and reassemble it on your chainsaw.
• Ensure the chain is properly tensioned.
• Test the chainsaw on a piece of wood. Observe the cutting performance and make any necessary adjustments.
• If the chain is cutting aggressively and pulling hard, the rakers may be too low. If the chain is cutting slowly and vibrating excessively, the rakers may be too high.

Practical Tips and Insights from the Field

Over the years, I’ve learned a few tricks and insights that can help you fine-tune your raker adjustment:

• Sharpen First, Adjust Later: Always sharpen your chain before adjusting the rakers. Adjusting rakers on a dull chain is a waste of time.
• Consistent Filing is Key: Strive for consistent filing technique. Uneven raker heights can lead to uneven cutting and increased vibration.
• Don’t Overdo It: It’s better to err on the side of caution when filing rakers. You can always file them down a little more, but you can’t put material back on.
• Listen to Your Saw: Your chainsaw will tell you if the rakers are properly adjusted. Pay attention to the sound and feel of the saw as you’re cutting. A properly adjusted saw will cut smoothly and efficiently with minimal vibration.
• Consider the Wood Type: Adjust your raker setting based on the type of wood you’re cutting. Softer woods require lower raker settings, while harder woods require higher settings.
• Use a Depth Gauge Chart: Always refer to a depth gauge chart for the recommended raker setting for your specific chain type.
• Practice Makes Perfect: Adjusting rakers takes practice. Don’t be discouraged if you don’t get it right the first time. Keep practicing, and you’ll eventually develop a feel for it.
• Invest in Quality Tools: A high-quality raker gauge and flat file will make the job much easier and more accurate.
• Clean Your Chain Regularly: A clean chain cuts more efficiently and reduces wear and tear.
• Check Chain Tension Frequently: Proper chain tension is essential for safe and efficient cutting.
• Lubricate Your Chain: Proper chain lubrication reduces friction and extends the life of the chain.
• Pay Attention to Chip Size: The size and shape of the wood chips can indicate whether the rakers are properly adjusted. Large, uniform chips indicate proper adjustment. Small, powdery chips indicate that the rakers are too high. Long, stringy chips indicate that the rakers are too low.

Case Studies: Raker Adjustment in Action

Let’s look at a couple of real-world case studies to illustrate the importance of proper raker adjustment:

Case Study 1: The Frustrated Firewood Cutter

A friend of mine, let’s call him Tom, was struggling to cut firewood. He had a Stihl MS 271 chainsaw, but he was constantly bogging down, and it took him forever to cut through even small logs. He was frustrated and ready to give up.

I visited him and quickly diagnosed the problem: his rakers were way too high. The cutting teeth were barely making contact with the wood. I showed him how to use a raker gauge and file the rakers down to the correct height.

The difference was dramatic. Suddenly, Tom’s chainsaw was cutting through wood like butter. He was amazed at how much faster and easier it was to cut firewood. He thanked me profusely and said he had learned a valuable lesson.

Case Study 2: The Professional Logger

A professional logger I know, let’s call him Sarah, relies on her chainsaws to make a living. She understands the importance of proper maintenance and regularly adjusts the rakers on her chains.

Sarah told me that she adjusts her raker settings depending on the type of wood she’s cutting. When she’s cutting softwood, she uses a lower raker setting to maximize cutting speed. When she’s cutting hardwood, she uses a higher raker setting to prevent the chain from bogging down.

She also emphasized the importance of using high-quality tools and taking the time to do the job right. She said that proper raker adjustment not only improves cutting performance but also extends the life of her chains and reduces the risk of kickback.

Common Mistakes to Avoid

Here are some common mistakes to avoid when adjusting rakers:

• Filing Rakers Too Low: This is one of the most common mistakes. Filing the rakers too low can lead to aggressive cutting, increased risk of kickback, and potential damage to the chain and saw.
• Filing Rakers Unevenly: Uneven raker heights can lead to uneven cutting and increased vibration.
• Using the Wrong Raker Gauge: Using the wrong raker gauge can result in incorrect raker settings.
• Not Sharpening the Chain First: Adjusting rakers on a dull chain is counterproductive.
• Ignoring the Wood Type: Failing to adjust the raker setting based on the type of wood you’re cutting can lead to poor cutting performance.
• Not Rounding the Rakers: Failing to round the front edge of the rakers can increase the risk of kickback.
• Rushing the Job: Rushing the job can lead to mistakes and inconsistent results.
• Not Wearing Safety Gear: Always wear safety gloves and eye protection when adjusting rakers.
• Using a Dull File: A dull file will make the job much more difficult and less accurate.
• Filing the Sides of the Rakers: Only file the top of the rakers. Filing the sides can weaken the rakers and cause them to break.

Strategic Advantages of Proper Raker Adjustment

Proper raker adjustment offers several strategic advantages:

• Increased Productivity: By maximizing cutting efficiency, proper raker adjustment can significantly increase your productivity.
• Reduced Costs: By extending the life of your chains and reducing fuel consumption, proper raker adjustment can save you money.
• Improved Safety: By reducing the risk of kickback, proper raker adjustment can make chainsaw operation safer.
• Enhanced Job Quality: By ensuring smooth, consistent cutting, proper raker adjustment can improve the quality of your work.
• Greater Professionalism: Demonstrating a commitment to proper chainsaw maintenance and operation can enhance your professional reputation.

Technical Details: Costs, Material Specs, Timing

Here’s a breakdown of some relevant technical details:

1. Gather Your Tools and Materials: Assemble the necessary tools and materials, including a raker gauge, flat file, vise, gloves, and eye protection.
2. Consult Your Manual: Refer to your chainsaw’s manual or the Stihl website to find the recommended raker setting for your specific chain type and cutting conditions.
3. Practice on an Old Chain: Before adjusting the rakers on your main chain, practice on an old or spare chain to get a feel for the process.
4. Start Slowly and Carefully: Take your time and be careful when filing the rakers. It’s better to err on the side of caution and file them down gradually.
5. Test and Adjust: After adjusting the rakers, test the chain on a piece of wood and make any necessary adjustments.
6. Maintain Your Chains Regularly: Make raker adjustment a regular part of your chainsaw maintenance routine.
7. Seek Expert Advice: If you’re unsure about any aspect of raker adjustment, seek advice from a qualified chainsaw technician.

Conclusion

Proper raker adjustment is a critical aspect of chainsaw maintenance that directly impacts cutting efficiency, safety, and chain longevity. By following the steps outlined in this guide and incorporating the practical tips and insights I’ve shared, you can optimize your Stihl chainsaw’s performance and enjoy a safer, more productive, and more enjoyable wood processing experience. Remember to prioritize safety, use quality tools, and take the time to do the job right. And don’t forget to keep your furry friends safe and sound while you’re working. Happy cutting!
