Tree Notch Diagram Explained: Open Face vs. Conventional Cuts
The notch cut is arguably the most critical part of felling a tree. It dictates the direction of the fall and, when executed correctly, significantly minimizes the risk of barber chairs (vertical splits up the trunk) and other dangerous scenarios. I’ve seen firsthand the consequences of a poorly executed notch, and believe me, it’s not pretty. Understanding the differences between the open face and conventional cuts is crucial for safe and efficient wood processing.
What is a Notch Cut?
Before we delve into the specifics, let’s define what we’re talking about. The notch cut is a wedge-shaped cut made on the side of the tree in the direction you want it to fall. It consists of two cuts: the top cut (typically angled downwards) and the bottom cut (typically angled upwards), which meet to form a point. The size and angle of these cuts determine the hinge, which controls the fall of the tree.
Conventional Notch Cut
The conventional notch cut, also known as the 70-degree notch, is the most traditional and widely used method. It’s a reliable technique that’s been around for generations.
How to Make a Conventional Notch Cut
- Planning: Before you even start your chainsaw, thoroughly assess the tree. Look for lean, wind direction, and any obstacles in the intended fall zone. This is where my experience comes into play. I remember one time, I was so eager to drop a large oak that I overlooked a slight lean towards a nearby power line. Luckily, I caught it just in time, but it was a close call. Always take the time to assess the situation.
- Top Cut: Make the top cut at a downward angle of approximately 45 degrees. Aim for a depth that’s about 1/5 to 1/3 of the tree’s diameter.
- Bottom Cut: Make the bottom cut at an upward angle to meet the top cut, forming a precise point. The angle should be roughly 25 degrees.
- Hinge: The hinge is the uncut wood left between the notch and the back cut. For a conventional notch, the hinge should be about 80% of the tree’s diameter.
- Back Cut: Make the back cut horizontally, slightly above the apex of the notch. Leave enough wood to create the hinge.
- Wedges: Insert wedges into the back cut before completing it to prevent the tree from sitting back on your saw. This is crucial, especially for larger trees.
Advantages of the Conventional Notch
- Simple and Easy to Learn: The conventional notch is straightforward and relatively easy to master, making it a great starting point for beginners.
- Reliable: It’s a proven method that provides consistent results when executed correctly.
- Suitable for Most Trees: It works well for trees with a variety of sizes and leans.
Disadvantages of the Conventional Notch
- Prone to Barber Chairing: If the hinge is too small or the wood is weak, the tree can split vertically up the trunk (barber chair), which is extremely dangerous.
- Requires Precise Angles: Achieving the correct angles can be challenging, especially for beginners.
- Not Ideal for Trees with a Strong Lean: In situations where trees have a significant lean, using the conventional notch may require additional techniques and caution.
Open Face Notch Cut
The open face notch cut, also known as the Humboldt notch, is a more modern technique that offers greater control and safety, especially for larger trees or those with a significant lean.
How to Make an Open Face Notch Cut
- Planning: As with any tree felling operation, thorough planning is essential. Assess the tree’s lean, wind direction, and potential hazards.
- Top Cut: Make the top cut at a downward angle of approximately 70-90 degrees. This creates a larger opening than the conventional notch. The depth should still be about 1/5 to 1/3 of the tree’s diameter.
- Bottom Cut: Make the bottom cut horizontally to meet the top cut. This creates a wider, more open notch.
- Hinge: The hinge is still the uncut wood between the notch and the back cut. For an open face notch, the hinge should be about 80% of the tree’s diameter.
- Back Cut: Make the back cut horizontally, slightly above the apex of the notch. Leave enough wood to create the hinge.
- Wedges: Use wedges to prevent the tree from sitting back on your saw. This is especially important for larger trees.
Advantages of the Open Face Notch
- Greater Control: The wider notch provides more control over the direction of the fall.
- Reduced Risk of Barber Chairing: The larger notch helps to prevent the tree from splitting vertically up the trunk.
- Suitable for Trees with a Strong Lean: It’s a better option for trees that have a significant lean, as it allows for more precise control.
Disadvantages of the Open Face Notch
- More Complex: The open face notch is more complex to execute than the conventional notch, requiring more skill and experience.
- Requires More Precision: Achieving the correct angles and depth is crucial for the open face notch to be effective.
- Not Suitable for All Trees: It may not be the best option for smaller trees or those with a minimal lean.
Choosing the Right Notch Cut
So, how do you decide which notch cut to use? Here’s a breakdown of factors to consider:
- Tree Size: For smaller trees, the conventional notch is usually sufficient. For larger trees, the open face notch offers greater control and safety.
- Tree Lean: If the tree has a significant lean, the open face notch is the better option.
- Experience Level: If you’re a beginner, start with the conventional notch and gradually progress to the open face notch as you gain experience.
- Wood Type: Certain wood types are more prone to barber chairing than others. For example, oak and hickory are known for their tendency to split. In these cases, the open face notch is a safer choice.
- Terrain: The terrain can also influence your choice of notch cut. If you’re working on a steep slope, the open face notch may provide greater control.
Safety Considerations
No matter which notch cut you choose, safety should always be your top priority. Here are some essential safety tips:
- Wear appropriate personal protective equipment (PPE): This includes a helmet, eye protection, hearing protection, gloves, and chainsaw chaps.
- Inspect your chainsaw: Make sure your chainsaw is in good working condition and properly sharpened. A dull chain can increase the risk of kickback and other accidents.
- Clear the area: Remove any obstacles from the area around the tree and in the intended fall zone.
- Establish an escape route: Plan your escape route before you start cutting and make sure it’s clear of obstacles.
- Be aware of your surroundings: Pay attention to the wind direction, the presence of other people, and any potential hazards.
- Never work alone: Always work with a partner who can assist you in case of an emergency.
- Take breaks: Fatigue can lead to mistakes. Take regular breaks to stay alert and focused.
