Stihl TS 500i Troubleshooting: 5 Pro Fixes to Get You Back Cutting

The Stihl TS 500i is a powerhouse, but even the best machines sometimes falter. Here are five common problems I’ve encountered, along with the fixes that have worked for me. I’ll walk you through each step, providing clear instructions and practical tips.

1. The Dreaded No-Start Scenario

Nothing is more disheartening than pulling the starter cord repeatedly with no sign of life. This can stem from several issues.

Fuel Delivery Problems

• The Issue: The most common culprit is a lack of fuel reaching the combustion chamber. This could be due to an empty fuel tank, a clogged fuel filter, a blocked fuel line, or a faulty fuel pump.

• My Experience: I remember one sweltering summer day when my TS 500i refused to start. I checked the fuel level (embarrassingly, it was empty!), refilled it, and still nothing. Turns out, the fuel filter was completely clogged with debris.

• The Fix:

  1. Check the Fuel Tank: Sounds obvious, but double-check the fuel level. Ensure you’re using the correct fuel mixture (50:1 ratio of gasoline to two-stroke oil). I always pre-mix my fuel in a separate container to ensure accuracy.
  2. Inspect the Fuel Filter: The fuel filter is usually located inside the fuel tank, attached to the fuel line. Access it by carefully removing the fuel cap and using a small hook or wire to pull the filter out. Examine the filter for dirt, debris, or clogs.
  3. Cleaning the Fuel Filter: If the filter is only slightly dirty, you can try cleaning it with carburetor cleaner or compressed air. If it’s heavily clogged, replace it with a new filter. I recommend keeping a few spare fuel filters on hand.
  4. Check the Fuel Line: Inspect the fuel line for cracks, kinks, or leaks. Replace any damaged sections of the fuel line.
  5. Test the Fuel Pump: The fuel pump is responsible for drawing fuel from the tank to the carburetor. To test it, disconnect the fuel line from the carburetor and pull the starter cord. Fuel should be pumped out of the fuel line. If no fuel is pumped, the fuel pump may be faulty and need replacement.

• Data & Insights: I’ve found that using high-quality fuel and storing it properly (in a cool, dry place) significantly reduces fuel system problems. Old fuel can degrade and leave deposits that clog filters and lines.

• Tool List:

  • Screwdriver (for removing fuel cap and accessing fuel filter)
  • Small hook or wire (for retrieving fuel filter)
  • Carburetor cleaner or compressed air (for cleaning fuel filter)
  • Replacement fuel filter (Stihl part number: 0000 350 3500)
  • Replacement fuel line (if needed)

• Takeaway: Always start with the simplest solutions – checking the fuel level and inspecting the fuel filter. Regular fuel system maintenance can prevent many no-start issues.

Ignition System Issues

• The Issue: If fuel delivery isn’t the problem, the ignition system might be at fault. This includes the spark plug, ignition coil, and wiring.

• My Experience: I once spent an hour troubleshooting a no-start issue, only to discover a loose spark plug wire. A simple connection fixed the problem.

• The Fix:

  1. Check the Spark Plug: Remove the spark plug and inspect it for damage, fouling, or excessive wear. A healthy spark plug should have a clean, dry electrode.
  2. Clean or Replace the Spark Plug: If the spark plug is fouled with carbon deposits, clean it with a wire brush or replace it with a new spark plug. The correct spark plug for the Stihl TS 500i is a Bosch USR7AC.
  3. Test for Spark: Reconnect the spark plug to the spark plug wire and ground the spark plug against the engine block. Pull the starter cord and observe if a spark jumps across the spark plug electrode. If there’s no spark, the ignition coil may be faulty.
  4. Inspect the Ignition Coil: The ignition coil is responsible for generating the high-voltage spark that ignites the fuel-air mixture. Check the ignition coil for cracks, damage, or loose connections. Use a multimeter to test the coil’s resistance according to the manufacturer’s specifications. Replace the coil if it’s faulty.

• Data & Insights: Spark plugs should be replaced regularly, typically every 100 hours of operation. A worn spark plug can cause hard starting, poor performance, and increased fuel consumption.

• Tool List:

  • Spark plug wrench
  • Wire brush (for cleaning spark plug)
  • Replacement spark plug (Bosch USR7AC)
  • Multimeter (for testing ignition coil)

• Takeaway: A faulty ignition system can prevent your TS 500i from starting. Regularly inspect and maintain the spark plug and ignition coil to ensure reliable operation.

Flooding

• The Issue: Sometimes, the engine gets flooded with too much fuel, preventing it from starting. This is more common in cold weather.

• My Experience: I’ve flooded my TS 500i a few times when starting it in freezing temperatures. The key is patience and the correct procedure.

• The Fix:

  1. Remove the Spark Plug: Remove the spark plug and pull the starter cord several times to clear excess fuel from the cylinder.
  2. Dry the Spark Plug: Dry the spark plug thoroughly.
  3. Reinstall the Spark Plug: Reinstall the spark plug and try starting the saw again. Don’t use the choke this time.
  4. Warm-Up Procedure: If the saw starts, let it idle for a few minutes to warm up properly.

• Data & Insights: Avoid excessive choking when starting the TS 500i, especially in warm weather. Follow the manufacturer’s recommended starting procedure.

• Tool List:

  • Spark plug wrench

• Takeaway: Flooding can be a common issue, especially in cold weather. Follow the proper procedure to clear the excess fuel and get your saw started.

2. Loss of Power During Cutting

A sudden drop in power while cutting can be frustrating and inefficient. It often indicates a problem with the engine’s air supply or fuel mixture.

Air Filter Issues

• The Issue: A dirty or clogged air filter restricts airflow to the engine, leading to a lean fuel mixture and reduced power.

• My Experience: I once noticed a significant power loss while cutting concrete. I checked the air filter, and it was completely packed with dust. Cleaning the filter restored the saw’s power immediately.

• The Fix:

  1. Locate the Air Filter: The air filter is usually located under a cover on top of the engine.
  2. Remove and Inspect the Air Filter: Remove the air filter and inspect it for dirt, debris, or damage.
  3. Clean the Air Filter: If the filter is only slightly dirty, you can clean it with compressed air or warm, soapy water. Allow the filter to dry completely before reinstalling it.
  4. Replace the Air Filter: If the filter is heavily clogged or damaged, replace it with a new air filter. I recommend replacing the air filter every 25 hours of operation, or more frequently in dusty conditions. The Stihl TS 500i uses a paper filter, so cleaning is limited. Replacing it is usually the best option.

• Data & Insights: Regularly cleaning or replacing the air filter is crucial for maintaining optimal engine performance and preventing engine damage.

• Tool List:

  • Screwdriver (for removing air filter cover)
  • Compressed air or warm, soapy water (for cleaning air filter)
  • Replacement air filter (Stihl part number: 4224 141 0300)

• Takeaway: A clean air filter is essential for proper engine performance. Regularly inspect and maintain the air filter to prevent power loss and engine damage.

Carburetor Problems

• The Issue: The carburetor is responsible for mixing air and fuel in the correct proportions. A dirty or misadjusted carburetor can cause a lean or rich fuel mixture, leading to power loss, poor performance, and starting problems.

• My Experience: I’ve had to adjust the carburetor on my TS 500i several times to compensate for changes in altitude and temperature.

• The Fix:

  1. Inspect the Carburetor: Visually inspect the carburetor for dirt, debris, or damage.
  2. Clean the Carburetor: If the carburetor is dirty, you can try cleaning it with carburetor cleaner. Disassemble the carburetor carefully, following the manufacturer’s instructions. Clean all the jets and passages with carburetor cleaner and compressed air.
  3. Adjust the Carburetor: The carburetor has three adjustment screws: the high-speed (H) screw, the low-speed (L) screw, and the idle speed (LA) screw. Adjust these screws according to the manufacturer’s specifications. The Stihl TS 500i utilizes an electronically controlled fuel injection system. Unlike traditional carburetors, there are no manual adjustments to be made. If you suspect a problem with the fuel injection system, it’s best to take it to a qualified Stihl service technician.

• Data & Insights: Carburetor adjustment is a delicate process. If you’re not comfortable adjusting the carburetor yourself, it’s best to take your saw to a qualified technician.

• Tool List:

  • Screwdriver (for removing carburetor cover)
  • Carburetor cleaner
  • Compressed air
  • Small screwdrivers (for adjusting carburetor screws)

• Takeaway: The carburetor plays a crucial role in engine performance. Keep it clean and properly adjusted to prevent power loss and other problems. However, remember that the TS 500i has fuel injection, limiting user-serviceable adjustments.

Clogged Spark Arrestor

• The Issue: The spark arrestor is a small screen that prevents sparks from escaping the exhaust system. Over time, it can become clogged with carbon deposits, restricting exhaust flow and reducing power.

• My Experience: I once experienced a gradual loss of power over several weeks. I finally checked the spark arrestor, and it was almost completely blocked.

• The Fix:

  1. Locate the Spark Arrestor: The spark arrestor is usually located in the muffler.
  2. Remove the Spark Arrestor: Remove the spark arrestor from the muffler.
  3. Clean the Spark Arrestor: Clean the spark arrestor with a wire brush or carburetor cleaner. You can also heat it with a propane torch to burn off the carbon deposits.
  4. Reinstall the Spark Arrestor: Reinstall the spark arrestor in the muffler.

• Data & Insights: Regularly cleaning the spark arrestor is important for maintaining optimal engine performance and preventing fire hazards.

• Tool List:

  • Screwdriver or wrench (for removing spark arrestor)
  • Wire brush or carburetor cleaner (for cleaning spark arrestor)
  • Propane torch (optional, for burning off carbon deposits)

• Takeaway: A clogged spark arrestor can significantly reduce engine power. Regularly clean or replace the spark arrestor to maintain optimal performance.

3. Overheating Issues

Overheating can cause serious engine damage. Identifying and addressing the cause of overheating is crucial for preventing costly repairs.

Insufficient Cooling

• The Issue: The engine needs adequate airflow to dissipate heat. Blocked cooling fins or a faulty cooling fan can lead to overheating.

• My Experience: I once overheated my TS 500i while cutting asphalt on a hot day. I realized the cooling fins were packed with asphalt dust.

• The Fix:

  1. Inspect the Cooling Fins: Check the cooling fins on the engine cylinder for dirt, debris, or obstructions.
  2. Clean the Cooling Fins: Clean the cooling fins with compressed air or a brush.
  3. Check the Cooling Fan: Ensure the cooling fan is operating properly. If the fan is damaged or not spinning freely, it may need to be replaced.

• Data & Insights: Regular cleaning of the cooling fins is essential for preventing overheating, especially in hot weather or dusty conditions.

• Tool List:

  • Compressed air
  • Brush

• Takeaway: Proper cooling is crucial for preventing overheating. Regularly inspect and clean the cooling fins and ensure the cooling fan is functioning properly.

Incorrect Fuel Mixture

• The Issue: A lean fuel mixture (too much air, not enough fuel) can cause the engine to run hot and overheat.

• My Experience: I once experienced overheating after accidentally using a fuel mixture with too little oil.

• The Fix:

  1. Verify Fuel Mixture: Ensure you’re using the correct fuel mixture (50:1 ratio of gasoline to two-stroke oil).
  2. Adjust Carburetor (If Possible): As noted earlier, the TS 500i uses fuel injection. If you suspect a lean fuel mixture, it’s best to consult a qualified Stihl technician.

• Data & Insights: Using the correct fuel mixture is essential for proper engine lubrication and cooling. Always use high-quality two-stroke oil and mix it accurately.

• Tool List:

  • Measuring container for fuel and oil

• Takeaway: A lean fuel mixture can cause overheating and engine damage. Always use the correct fuel mixture and consult a qualified technician if you suspect a fuel injection problem.

Excessive Load

• The Issue: Forcing the saw to cut too quickly or using the wrong cutting wheel can overload the engine and cause it to overheat.

• My Experience: I’ve overheated my TS 500i when trying to cut through excessively hard concrete too quickly.

• The Fix:

  1. Reduce Cutting Speed: Allow the saw to cut at its own pace. Don’t force it.
  2. Use the Correct Cutting Wheel: Use the appropriate cutting wheel for the material you’re cutting.
  3. Take Breaks: Allow the engine to cool down periodically, especially during prolonged use.

• Data & Insights: Using the correct cutting techniques and avoiding excessive load can prevent overheating and extend the life of your saw.

• Tool List:

  • Appropriate cutting wheel for the material

• Takeaway: Overloading the engine can cause overheating. Use proper cutting techniques, the correct cutting wheel, and take breaks to allow the engine to cool down.

4. Excessive Vibration

Excessive vibration can be uncomfortable and even dangerous. It can also indicate a problem with the saw’s internal components.

Loose Components

• The Issue: Loose screws, bolts, or other components can cause excessive vibration.

• My Experience: I once experienced excessive vibration after dropping my TS 500i. I found several loose screws.

• The Fix:

  1. Inspect the Saw: Thoroughly inspect the saw for loose screws, bolts, or other components.
  2. Tighten Loose Components: Tighten any loose components using the appropriate tools.

• Data & Insights: Regularly inspecting and tightening loose components can prevent excessive vibration and potential damage.

• Tool List:

  • Screwdrivers
  • Wrenches

• Takeaway: Loose components can cause excessive vibration. Regularly inspect and tighten all screws and bolts.

Damaged Cutting Wheel

• The Issue: A damaged or unbalanced cutting wheel can cause excessive vibration.

• My Experience: I once experienced excessive vibration after hitting a piece of rebar with my cutting wheel. The wheel was slightly bent.

• The Fix:

  1. Inspect the Cutting Wheel: Inspect the cutting wheel for damage, cracks, or imbalances.
  2. Replace the Cutting Wheel: Replace the cutting wheel if it’s damaged or unbalanced.

• Data & Insights: Using a damaged or unbalanced cutting wheel can be dangerous and can also damage the saw. Always use a high-quality, balanced cutting wheel.

• Tool List:

  • Wrench (for removing cutting wheel)
  • Replacement cutting wheel

• Takeaway: A damaged cutting wheel can cause excessive vibration. Always inspect the cutting wheel before use and replace it if it’s damaged or unbalanced.

Worn Anti-Vibration Mounts

• The Issue: The TS 500i is equipped with anti-vibration mounts to reduce vibration transmitted to the operator. Over time, these mounts can wear out or become damaged, leading to increased vibration.

• My Experience: I’ve noticed a gradual increase in vibration over time as the anti-vibration mounts on my saw wore out.

• The Fix:

  1. Inspect the Anti-Vibration Mounts: Inspect the anti-vibration mounts for cracks, damage, or excessive wear.
  2. Replace the Anti-Vibration Mounts: Replace the anti-vibration mounts if they’re worn or damaged.

• Data & Insights: Replacing worn anti-vibration mounts can significantly reduce vibration and improve operator comfort.

• Tool List:

  • Screwdrivers
  • Wrenches
  • Replacement anti-vibration mounts (Stihl part numbers vary depending on the specific mount)

• Takeaway: Worn anti-vibration mounts can increase vibration. Regularly inspect and replace the mounts as needed to maintain operator comfort and prevent potential injuries.

5. Difficult Starting When Warm

Sometimes, a TS 500i starts easily when cold but struggles to start when warm. This can be due to vapor lock or other fuel-related issues.

Vapor Lock

• The Issue: Vapor lock occurs when fuel vaporizes in the fuel line or carburetor, preventing fuel from reaching the engine. This is more common in hot weather.

• My Experience: I’ve experienced vapor lock on hot summer days when the saw was left sitting in direct sunlight.

• The Fix:

  1. Cool the Saw: Allow the saw to cool down for a few minutes.
  2. Purge the Fuel Line: Open the fuel cap to release any pressure in the fuel tank.
  3. Prime the Engine: Press the primer bulb (if equipped) several times to purge any vapor from the fuel line.
  4. Start the Saw: Try starting the saw again.

• Data & Insights: Avoid leaving the saw in direct sunlight on hot days to prevent vapor lock.

• Tool List:

  • None required

• Takeaway: Vapor lock can cause difficult starting when warm. Allow the saw to cool down and purge the fuel line to resolve the issue.

Fuel Injection System Issues (Again)

• The Issue: A faulty fuel injector or sensor can cause incorrect fuel delivery, leading to difficult starting when warm. Because the TS 500i is electronically controlled, diagnosis becomes more complex.

• My Experience: I had a perplexing issue with my TS 500i where it ran perfectly when cold but refused to start after being shut off for a short period. Eventually, a Stihl technician traced it to a faulty temperature sensor.

• The Fix:

  1. Check for Error Codes: The TS 500i has a diagnostic system that can display error codes. Consult the owner’s manual or a Stihl technician to interpret any error codes.
  2. Inspect Wiring and Connectors: Check all wiring and connectors related to the fuel injection system for damage or loose connections.
  3. Consult a Stihl Technician: If you suspect a fuel injection problem, it’s best to take your saw to a qualified Stihl technician for diagnosis and repair. They have the specialized tools and knowledge to diagnose and repair these systems.

• Data & Insights: Modern fuel injection systems are complex and require specialized knowledge and tools for diagnosis and repair.

• Tool List:

  • None (diagnosis and repair should be performed by a qualified technician)

• Takeaway: Difficult starting when warm can be a sign of a fuel injection problem. Consult a Stihl technician for diagnosis and repair.

Low Compression

• The Issue: Low compression can make it difficult to start the engine, especially when warm.

• My Experience: I’ve experienced low compression in older saws with worn piston rings.

• The Fix:

  1. Check Compression: Use a compression tester to check the engine’s compression. The TS 500i should have a compression reading of at least 100 PSI.
  2. Repair or Replace Engine Components: If the compression is low, the engine may need to be repaired or rebuilt. This may involve replacing the piston rings, piston, or cylinder.

• Data & Insights: Low compression can indicate significant engine wear. Regular maintenance and proper lubrication can help prevent premature engine wear.

• Tool List:

  • Compression tester
  • Engine repair tools (if necessary)

• Takeaway: Low compression can make it difficult to start the engine. Check the compression and repair or rebuild the engine as needed.

Additional Tips for Stihl TS 500i Maintenance

Beyond these specific troubleshooting steps, here are some general maintenance tips that will help keep your Stihl TS 500i running smoothly:

• Regular Cleaning: Keep the saw clean, especially the air filter, cooling fins, and spark arrestor.
• Proper Lubrication: Use high-quality two-stroke oil and mix it accurately with gasoline.
• Sharp Cutting Wheel: Use a sharp, high-quality cutting wheel.
• Proper Storage: Store the saw in a cool, dry place.
• Scheduled Maintenance: Follow the manufacturer’s recommended maintenance schedule.

Safety First!

Before performing any maintenance or repairs on your Stihl TS 500i, always disconnect the spark plug wire to prevent accidental starting. Wear appropriate safety gear, including eye protection, hearing protection, and gloves. Work in a well-ventilated area.

A Final Word

Troubleshooting a Stihl TS 500i can seem daunting, but by systematically addressing potential issues, you can often diagnose and fix the problem yourself. Remember to prioritize safety and consult a qualified technician if you’re not comfortable performing a particular repair. With proper maintenance and care, your Stihl TS 500i will provide years of reliable service. Now, get back out there and get cutting!
