Stihl Strimmer Carburettor Tuning (5 Pro Tips for Peak Power)

I still remember the day I almost gave up on my old Stihl FS 38 strimmer. It was sputtering, lacking power, and generally behaving like a grumpy old man. After hours of frustration, I almost threw it in the scrap heap. But something told me to give it one last shot. That’s when I dove headfirst into the world of carburettor tuning. Now, years later, I’m going to share my hard-earned knowledge with you. This guide, “Stihl Strimmer Carburettor Tuning (5 Pro Tips for Peak Power)”, will provide actionable steps to bring your strimmer back to life, optimizing its performance for peak power. Let’s get started!

Stihl Strimmer Carburettor Tuning: 5 Pro Tips for Peak Power

The carburettor is the heart of your Stihl strimmer, responsible for mixing fuel and air in the correct ratio for optimal combustion. When it’s out of tune, you’ll experience a range of problems, from difficulty starting to poor performance and excessive fuel consumption. Tuning your carburettor is essential for maintaining your strimmer’s performance and prolonging its lifespan. Let’s dive into the specifics.

Understanding Your Stihl Strimmer Carburettor

Before you start twiddling screws, you need to understand the basics of how your Stihl strimmer’s carburettor works. Most Stihl strimmers use a two-stroke engine, which requires a specific air-fuel mixture to run efficiently. The carburettor’s job is to deliver this mixture under varying operating conditions.

• The Main Components: A typical Stihl strimmer carburettor consists of several key components:

  • Jets (High and Low Speed): These control the amount of fuel delivered at different engine speeds.
  • Needle Valves: These regulate the fuel flow through the jets.
  • Throttle Valve: This controls the amount of air entering the engine.
  • Choke: Used for starting a cold engine by enriching the fuel mixture.

• The Air-Fuel Ratio: The ideal air-fuel ratio for a two-stroke engine is around 14.7:1 (by weight). A lean mixture (more air) can cause overheating and engine damage, while a rich mixture (more fuel) can lead to poor performance and excessive smoke.

• Identifying Your Carburettor Type: Stihl strimmers use different types of carburettors. The most common are Walbro and Zama. Knowing your carburettor type can help you find specific tuning instructions and parts. Look for a stamp or label on the carburettor body to identify it.

Takeaway: Familiarize yourself with the components of your strimmer’s carburettor and understand the importance of the air-fuel ratio. This knowledge will form the foundation for effective tuning.

Tip 1: Preparing for Carburettor Tuning

Proper preparation is crucial for a successful tuning session. Rushing into it without the right tools and knowledge can lead to frustration and potential damage to your strimmer.

• Gather Your Tools: You’ll need a few essential tools:

  • Screwdriver Set: A set of small screwdrivers, including a flathead and a special “D” shaped tool for adjusting some carburettor screws. Stihl often uses proprietary screws.
  • Tachometer (Optional): A tachometer helps you accurately measure the engine RPM, which is crucial for setting the high and low speed settings.
  • Spark Plug Wrench: To remove and inspect the spark plug.
  • Carburettor Cleaner: To clean any debris or build-up in the carburettor.
  • Safety Glasses and Gloves: Protect your eyes and hands from fuel and chemicals.

• Safety First: Before you start, disconnect the spark plug wire to prevent accidental starting. Work in a well-ventilated area, away from open flames or sparks. Fuel is highly flammable.

• Clean the Strimmer: Give your strimmer a thorough cleaning, paying particular attention to the air filter and carburettor area. A dirty air filter can affect the air-fuel mixture and throw off your tuning.

• Fresh Fuel: Use fresh, properly mixed fuel (usually a 50:1 ratio of gasoline to two-stroke oil). Stale fuel can cause starting and performance problems. I always use premium fuel to ensure optimal performance and longevity of my equipment.

• Inspect the Spark Plug: Remove the spark plug and inspect its condition. A fouled or worn spark plug can mimic carburettor problems. Clean or replace the spark plug as needed. The color of the spark plug can also provide clues about the air-fuel mixture:

  • Tan or Light Brown: Ideal mixture.
  • Black and Sooty: Rich mixture.
  • White or Light Gray: Lean mixture.

Takeaway: Gather your tools, prioritize safety, clean your strimmer, use fresh fuel, and inspect the spark plug before starting any carburettor tuning. This will set you up for success.

Tip 2: Locating and Identifying Adjustment Screws

The location and type of adjustment screws on your Stihl strimmer’s carburettor can vary depending on the model and carburettor type. Identifying them correctly is essential for making accurate adjustments.

• Common Adjustment Screws: Most Stihl strimmer carburettors have three main adjustment screws:

  • L (Low Speed): Controls the fuel mixture at idle and low engine speeds.
  • H (High Speed): Controls the fuel mixture at high engine speeds.
  • LA (Idle Speed): Controls the engine idle speed.

• Locating the Screws: The adjustment screws are usually located on the side of the carburettor, often near the throttle linkage. They may be marked with the letters “L,” “H,” and “LA,” or with symbols.

• Special Tools: Some Stihl carburettors use proprietary adjustment screws that require special tools. These screws often have a “D” shape, a spline, or a Pac-Man shape. You can purchase these tools online or from a Stihl dealer. I found a set of these specialty tools incredibly useful, especially when working on older models.

• Understanding the Screws:

  • L (Low Speed): Adjusting this screw affects the engine’s starting, idling, and acceleration. Turning it clockwise leans the mixture (less fuel), while turning it counter-clockwise richens the mixture (more fuel).
  • H (High Speed): Adjusting this screw affects the engine’s performance at full throttle. Turning it clockwise leans the mixture, while turning it counter-clockwise richens the mixture. Be very careful with the H screw, as a lean mixture at high speed can quickly damage the engine.
  • LA (Idle Speed): Adjusting this screw controls the engine’s idle speed. Turning it clockwise increases the idle speed, while turning it counter-clockwise decreases the idle speed.

Takeaway: Locate and identify the L, H, and LA adjustment screws on your Stihl strimmer’s carburettor. Understand the function of each screw and use the correct tools for adjustment.

Tip 3: The Initial Carburettor Adjustment

Before making any fine-tuning adjustments, it’s important to set the carburettor to its initial or factory settings. This provides a baseline for further adjustments.

• Finding the Factory Settings: The factory settings for your Stihl strimmer’s carburettor can usually be found in the owner’s manual or on the Stihl website. If you can’t find the specific settings for your model, a good starting point is to turn both the L and H screws all the way in (clockwise) until they are lightly seated, and then back them out 1 to 1.5 turns.

• Setting the Idle Speed: The idle speed screw (LA) should be adjusted so that the engine idles smoothly without the cutting head engaging. If the cutting head is spinning at idle, turn the LA screw counter-clockwise until it stops.

• Why Factory Settings Matter: The factory settings are designed to provide a safe and reliable starting point for tuning. They ensure that the engine receives enough fuel to prevent damage while allowing for fine-tuning to optimize performance.

• Starting the Engine: After setting the initial adjustments, start the engine. It may take a few pulls to get it running, especially if the carburettor was completely empty. If the engine doesn’t start, double-check the fuel mixture, spark plug, and air filter.

Takeaway: Set the L and H screws to their factory settings (or 1 to 1.5 turns out if the factory settings are unavailable) and adjust the LA screw so that the engine idles without the cutting head engaging.

Tip 4: Fine-Tuning for Peak Performance

Once you have the initial settings established, you can start fine-tuning the carburettor for peak performance. This involves adjusting the L and H screws to optimize the air-fuel mixture at different engine speeds.

• Tuning the Low Speed (L Screw):

  • Idle Speed: Start by adjusting the idle speed. The engine should idle smoothly without stalling or sputtering. If the engine stalls, turn the L screw counter-clockwise (richer) slightly. If the engine sputters or smokes, turn the L screw clockwise (leaner) slightly.
  • Acceleration: Test the engine’s acceleration by quickly opening the throttle. If the engine hesitates or bogs down, turn the L screw counter-clockwise (richer) slightly. If the engine revs up quickly but then flattens out, turn the L screw clockwise (leaner) slightly.
  • The “Sweet Spot”: The goal is to find the “sweet spot” where the engine idles smoothly and accelerates crisply without hesitation. This may require making small adjustments to the L screw and then re-checking the idle speed.

• Tuning the High Speed (H Screw):

  • Full Throttle: After tuning the low speed, move on to the high speed. Run the engine at full throttle for a few seconds. Listen to the engine’s sound and watch for any signs of a lean or rich mixture.
  • Lean Mixture: If the engine sounds “tinny” or “screaming” at full throttle, it’s likely running lean. Immediately turn the H screw counter-clockwise (richer) slightly. A lean mixture at high speed can quickly damage the engine.
  • Rich Mixture: If the engine smokes excessively or feels sluggish at full throttle, it’s likely running rich. Turn the H screw clockwise (leaner) slightly.
  • Tachometer (Optional): If you have a tachometer, you can use it to set the high speed RPM according to the manufacturer’s specifications. This provides a more precise way to tune the high speed. Stihl usually recommends a maximum RPM. Exceeding this can cause damage.

• Iterative Process: Tuning the carburettor is an iterative process. You may need to make small adjustments to both the L and H screws to achieve optimal performance. After each adjustment, let the engine run for a few minutes to stabilize before making further adjustments.

Takeaway: Fine-tune the L and H screws to optimize the air-fuel mixture at different engine speeds. Listen to the engine’s sound, watch for signs of a lean or rich mixture, and use a tachometer (if available) to set the high speed RPM.

Tip 5: Troubleshooting Common Tuning Problems

Even with careful tuning, you may encounter some common problems. Here are some troubleshooting tips to help you resolve them.

• Engine Won’t Start:

  • Fuel: Make sure the fuel tank is full and the fuel is fresh.
  • Spark Plug: Check the spark plug for spark. If there’s no spark, replace the spark plug.
  • Choke: Use the choke for starting a cold engine.
  • Carburettor: Check the carburettor for fuel delivery. If the carburettor is dry, the fuel line may be clogged or the fuel pump may be malfunctioning.

• Engine Idles Poorly:

  • L Screw: Adjust the L screw to fine-tune the idle mixture.
  • Idle Speed: Adjust the LA screw to set the correct idle speed.
  • Air Filter: Check the air filter for dirt and debris. A dirty air filter can affect the idle mixture.
  • Vacuum Leaks: Check for vacuum leaks around the carburettor and intake manifold. Vacuum leaks can cause erratic idling.

• Engine Bogs Down on Acceleration:

  • L Screw: Adjust the L screw to richen the low-speed mixture.
  • Fuel Filter: Check the fuel filter for clogs. A clogged fuel filter can restrict fuel flow and cause the engine to bog down.
  • Spark Plug: Inspect the spark plug. A worn or fouled spark plug can cause the engine to bog down.

• Engine Overheats:

  • H Screw: Adjust the H screw to richen the high-speed mixture.
  • Cooling Fins: Clean the cooling fins on the engine cylinder. Dirty cooling fins can reduce cooling efficiency and cause the engine to overheat.
  • Air Filter: A dirty air filter can cause the engine to run lean and overheat.

• Engine Smokes Excessively:

  • H Screw: Adjust the H screw to lean the high-speed mixture.
  • Fuel Mixture: Ensure that you are using the correct fuel-to-oil ratio. Too much oil in the fuel can cause excessive smoking.

• Still Having Issues?: If you’ve tried all these troubleshooting steps and your Stihl strimmer is still not running properly, it may be time to take it to a qualified repair technician. A professional can diagnose and repair more complex problems, such as a damaged carburettor or a worn engine.

Takeaway: Be prepared to troubleshoot common tuning problems. Check the fuel, spark plug, air filter, and carburettor for any issues. Adjust the L and H screws as needed to correct the mixture. If you’re still having problems, consult a qualified repair technician.

Beyond Tuning: Maintaining Your Stihl Strimmer

Tuning is only one part of keeping your Stihl strimmer running smoothly. Regular maintenance is essential for prolonging its lifespan and preventing future problems.

• Air Filter Cleaning: Clean the air filter regularly, especially in dusty conditions. A dirty air filter restricts airflow and can cause the engine to run poorly. I usually clean mine after every 5-10 hours of use.

• Spark Plug Replacement: Replace the spark plug annually or after every 100 hours of use. A worn spark plug can cause starting problems and reduce engine performance.

• Fuel Filter Replacement: Replace the fuel filter annually. A clogged fuel filter can restrict fuel flow and cause the engine to bog down.

• Fuel System Maintenance: Drain the fuel tank before storing the strimmer for extended periods. Stale fuel can cause starting problems and damage the carburettor. Consider using a fuel stabilizer to prevent fuel from going bad.

• Sharpening the Cutting Head: Keep the cutting head sharp for efficient cutting. A dull cutting head requires more power and can strain the engine.

• Regular Inspection: Inspect the strimmer regularly for any signs of wear or damage. Check the fuel lines, throttle cable, and other components for cracks or leaks.

• Proper Storage: Store the strimmer in a clean, dry place. Protect it from extreme temperatures and moisture.

Takeaway: Implement a regular maintenance schedule for your Stihl strimmer. Clean the air filter, replace the spark plug and fuel filter, maintain the fuel system, sharpen the cutting head, and inspect the strimmer regularly for any signs of wear or damage.

Advanced Tuning Techniques

For those who want to take their tuning skills to the next level, here are some advanced techniques to consider.

• Using a Vacuum Gauge: A vacuum gauge can be used to measure the vacuum pressure in the intake manifold. This can provide valuable information about the engine’s condition and the carburettor’s performance.

• Analyzing Exhaust Gases: An exhaust gas analyzer can be used to measure the levels of various gases in the exhaust. This can provide a more precise way to tune the carburettor for optimal emissions and performance.

• Modifying the Carburettor: Some enthusiasts modify their carburettors to improve performance. This may involve changing the jets, needles, or other components. However, modifying the carburettor can also void the warranty and potentially damage the engine.

• Dyno Tuning: A dynamometer (dyno) can be used to measure the engine’s horsepower and torque output. This provides a precise way to tune the carburettor for maximum performance.

Takeaway: Consider using advanced tuning techniques, such as a vacuum gauge, exhaust gas analyzer, carburettor modifications, or dyno tuning, to further optimize your Stihl strimmer’s performance. However, be aware of the risks involved and proceed with caution.

Safety Considerations

Working with fuel and power equipment can be dangerous. Always follow these safety precautions to prevent accidents and injuries.

• Wear Safety Glasses and Gloves: Protect your eyes and hands from fuel and chemicals.
• Work in a Well-Ventilated Area: Avoid breathing fuel vapors.
• Disconnect the Spark Plug Wire: Prevent accidental starting during maintenance.
• Keep Away from Open Flames: Fuel is highly flammable.
• Read the Owner’s Manual: Familiarize yourself with the strimmer’s operating instructions and safety precautions.
• Use Caution When Working with Sharp Objects: The cutting head can cause serious injuries.
• Never Operate the Strimmer Under the Influence: Alcohol or drugs can impair your judgment and coordination.

Takeaway: Prioritize safety when working with fuel and power equipment. Wear safety glasses and gloves, work in a well-ventilated area, disconnect the spark plug wire, keep away from open flames, read the owner’s manual, use caution when working with sharp objects, and never operate the strimmer under the influence.

Stihl Strimmer Tuning: A Final Thought

Tuning your Stihl strimmer’s carburettor can seem daunting at first, but with the right knowledge and tools, it’s a manageable task. By following these five pro tips, you can optimize your strimmer’s performance, prolong its lifespan, and save money on fuel and repairs. Remember to prioritize safety, take your time, and don’t be afraid to experiment. With a little practice, you’ll be able to keep your Stihl strimmer running smoothly for years to come. Now, go forth and conquer that overgrown lawn!
