Stihl MS 271 Ignition Coil Troubleshooting (5 Expert Fixes)

Understanding the Role of the Ignition Coil

The ignition coil is the heart of your chainsaw’s electrical system. It takes the low-voltage current from the magneto (powered by the flywheel) and transforms it into the high-voltage spark needed to ignite the fuel-air mixture in the cylinder. Without a properly functioning ignition coil, your chainsaw is essentially a very heavy and frustrating paperweight. Think of it as the conductor of an orchestra – without it, no music happens.

1. Initial Checks: The Quick & Dirty (and Mostly Free) Fixes

Before you even think about replacing the ignition coil, let’s run through some simple checks that could save you time and money. I’ve seen too many folks jump to conclusions and replace perfectly good parts.

1.1. Spark Plug Inspection and Cleaning

The Problem: A fouled or damaged spark plug can mimic ignition coil problems. Carbon buildup, cracks, or a worn electrode can prevent a strong spark.
The Fix: Remove the spark plug and inspect it. Look for any signs of damage or excessive carbon buildup. Clean the spark plug with a wire brush or spark plug cleaner. Check the gap using a spark plug gapping tool. The correct gap for the Stihl MS 271 is typically around 0.020 inches (0.5 mm).
Cost: Spark plug cleaner is relatively inexpensive, usually costing around $5-$10. A spark plug gapping tool is similarly priced. If the spark plug is beyond cleaning, a new one will set you back around $5-$15, depending on the brand and type.
My Experience: I recall one particularly frustrating day when my MS 271 refused to start. After tearing my hair out for an hour, I finally decided to check the spark plug. It was completely coated in carbon. A quick cleaning and re-gapping, and the chainsaw fired right up! It just goes to show that the simplest solutions are often the best.

1.2. Checking the Spark Plug Wire and Boot

The Problem: A damaged spark plug wire or boot can prevent the spark from reaching the spark plug. Cracks, cuts, or loose connections are common culprits.
The Fix: Inspect the spark plug wire and boot for any signs of damage. Ensure the boot is securely attached to the spark plug. If you suspect a break in the wire, you can use a multimeter to check for continuity.
Cost: A new spark plug wire and boot typically cost around $10-$20.
My Experience: I once had a similar issue where the chainsaw would start intermittently. After closer inspection, I found a tiny crack in the spark plug boot. Moisture was getting in and causing the spark to ground out. A new boot solved the problem instantly.

1.3. Fuel and Air Filter Check

The Problem: While not directly related to the ignition coil, a clogged fuel filter or air filter can starve the engine of fuel or air, causing it to run poorly or not start at all. This can sometimes be mistaken for an ignition problem.
The Fix: Inspect and clean or replace the fuel filter and air filter.
Cost: Fuel filters are generally inexpensive, costing around $5-$10. Air filters are similarly priced.
My Experience: I’ve learned the hard way that neglecting these filters is a recipe for disaster. A clogged air filter can lead to overheating and reduced power, while a clogged fuel filter can prevent the engine from getting enough fuel. Regular maintenance is key.

2. Testing the Ignition Coil: Is it Really the Culprit?

Before you invest in a new ignition coil, it’s crucial to confirm that it’s actually the problem. There are a few ways to test the ignition coil, ranging from simple visual inspections to using a multimeter.

2.1. Visual Inspection

The Method: Carefully examine the ignition coil for any signs of physical damage, such as cracks, melted plastic, or corrosion. Look for loose wires or connections.
Cost: Free! This is a simple visual check that requires no special tools or equipment.
My Insight: While a visual inspection won’t always reveal the problem, it can sometimes uncover obvious issues, such as a cracked housing or a burnt wire.

2.2. The Spark Test

The Method: Remove the spark plug and reattach it to the spark plug wire. Hold the spark plug against the engine block (or any grounded metal part) and pull the starter cord. Look for a strong, blue spark at the spark plug gap. A weak, yellow spark or no spark at all indicates a potential problem with the ignition coil.
Cost: Free! This test only requires the tools you already have to remove the spark plug.
Important Note: Be careful when performing this test, as you’re working with high voltage. Avoid touching the spark plug or wire while pulling the starter cord.
My Experience: This is my go-to test for quickly assessing the ignition system. A healthy spark is a good sign, while a weak or absent spark points to a potential issue with the ignition coil, wiring, or magneto.

2.3. Using a Multimeter to Test Resistance

The Method: A multimeter can be used to measure the resistance of the primary and secondary windings of the ignition coil. This can help determine if there’s a short or open circuit within the coil.
Tools Required: A multimeter capable of measuring resistance (ohms).
Procedure:
1. Consult the Stihl MS 271 service manual for the correct resistance values for the primary and secondary windings.
2. Disconnect the ignition coil from the wiring harness.
3. Set the multimeter to the ohms setting.
4. Measure the resistance between the primary terminals of the ignition coil.
5. Measure the resistance between the secondary terminal (spark plug wire) and one of the primary terminals.
6. Compare your readings to the values specified in the service manual.
Cost: A basic multimeter can be purchased for around $20-$50. A more advanced multimeter with additional features may cost more.
Data-Driven Insight: According to a study by the Equipment Service Association, approximately 60% of ignition coil failures are due to internal shorts or open circuits, which can be detected using a multimeter.
My Expertise: Using a multimeter provides a more precise diagnosis than the spark test. It can help identify subtle problems that might be missed with a visual inspection or spark test. However, it’s important to consult the service manual for the correct resistance values, as these can vary depending on the specific model and revision of the ignition coil.

3. The Air Gap: Setting it Right is Crucial

The air gap is the distance between the ignition coil and the flywheel. This gap is critical for the ignition system to function properly. If the air gap is too large, the spark will be weak or nonexistent. If it’s too small, the ignition coil can rub against the flywheel, causing damage.

3.1. Finding the Correct Air Gap

The Specification: The correct air gap for the Stihl MS 271 is typically around 0.012 inches (0.3 mm). However, it’s always best to consult the service manual for the specific model of your chainsaw.
Cost: A feeler gauge set, which is used to measure the air gap, costs around $10-$20.
My Experience: I once spent hours troubleshooting a chainsaw that wouldn’t start, only to discover that the air gap was slightly off. A simple adjustment with a feeler gauge, and the chainsaw fired right up. This experience taught me the importance of paying attention to even the smallest details.

3.2. Adjusting the Air Gap

The Process:
1. Loosen the screws that hold the ignition coil in place.
2. Insert a feeler gauge of the correct thickness (0.012 inches or 0.3 mm) between the ignition coil and the flywheel.
3. Push the ignition coil against the flywheel so that it’s snug against the feeler gauge.
4. Tighten the screws that hold the ignition coil in place.
5. Remove the feeler gauge.
My Pro Tip: Some people use a business card as a makeshift feeler gauge, as it’s approximately the correct thickness. However, a proper feeler gauge set is more accurate and reliable.

4. Replacing the Ignition Coil: A Step-by-Step Guide

If you’ve confirmed that the ignition coil is faulty, it’s time to replace it. This is a relatively straightforward process that can be done with basic tools.

4.1. Gathering Your Tools and Parts

Tools Required: Screwdrivers, pliers, socket set, and a new ignition coil for the Stihl MS 271.
Cost of a New Ignition Coil: The cost of a new ignition coil for the Stihl MS 271 can vary depending on the brand and quality. Aftermarket coils typically range from $20-$40, while genuine Stihl coils can cost $40-$80.
My Recommendation: While aftermarket coils can be tempting due to their lower price, I generally recommend using genuine Stihl parts whenever possible. They’re more reliable and will ensure optimal performance and longevity of your chainsaw.

4.2. Removing the Old Ignition Coil

The Process:
1. Disconnect the spark plug wire from the spark plug.
2. Remove the engine cover to access the ignition coil.
3. Disconnect the wires from the ignition coil. Make a note of which wire goes where, or take a picture for reference.
4. Remove the screws that hold the ignition coil in place.
5. Remove the old ignition coil.
Safety First: Always disconnect the spark plug wire before working on the ignition system to prevent accidental shocks.

4.3. Installing the New Ignition Coil

The Process:
1. Install the new ignition coil in the same location as the old one.
2. Tighten the screws that hold the ignition coil in place.
3. Connect the wires to the ignition coil, making sure they’re connected correctly.
4. Set the air gap between the ignition coil and the flywheel, as described in Section 3.
5. Reinstall the engine cover.
6. Reconnect the spark plug wire to the spark plug.

5. Preventative Maintenance: Keeping Your Ignition Coil Healthy

Prevention is always better (and cheaper!) than cure. By following a few simple preventative maintenance steps, you can significantly extend the life of your ignition coil and avoid costly repairs.

5.1. Regular Cleaning

The Practice: Keep the engine compartment clean and free of debris. Dirt and grime can trap heat and cause the ignition coil to overheat and fail.
My Method: I use compressed air to blow out the engine compartment after each use. This helps remove dirt, sawdust, and other debris that can accumulate over time.

5.2. Avoiding Overheating

The Issue: Overheating is a major cause of ignition coil failure. Ensure the engine is properly cooled by keeping the cooling fins clean and free of obstructions.
My Tip: Pay attention to the engine temperature. If the engine starts to overheat, stop using the chainsaw and allow it to cool down before continuing.

5.3. Using the Correct Fuel Mixture

The Importance: Using the correct fuel mixture is crucial for engine health. Too much oil can cause carbon buildup on the spark plug and other engine components, while too little oil can lead to excessive wear and tear.
The Specification: The Stihl MS 271 typically requires a fuel mixture of 50:1 (50 parts gasoline to 1 part oil). Always use high-quality 2-stroke oil that meets the specifications recommended by Stihl.
Data Insight: A study by the American Society of Agricultural and Biological Engineers found that using the correct fuel mixture can extend the life of small engines by up to 25%.

5.4. Proper Storage

The Practice: When storing your chainsaw for extended periods, drain the fuel tank and run the engine until it stalls. This will prevent the fuel from gumming up the carburetor and other engine components.
My Method: I also remove the spark plug and add a few drops of oil to the cylinder before storing the chainsaw. This helps prevent rust and corrosion.

Understanding the Broader Cost Landscape: Chainsaw Ownership & Maintenance

While we’ve focused on the ignition coil, it’s important to understand the larger picture of chainsaw ownership and maintenance costs. These costs can vary significantly depending on factors such as the frequency of use, the type of wood being cut, and the quality of maintenance performed.

6.1. Initial Investment: Chainsaw Purchase Price

The Range: The Stihl MS 271 typically costs between $400 and $600, depending on the retailer and any included accessories.
Cost-Benefit Analysis: While a more expensive chainsaw may offer better performance and durability, it’s important to consider your specific needs and budget. A less expensive chainsaw may be sufficient for occasional use, while a more durable model is a better investment for frequent or heavy-duty use.

6.2. Fuel and Oil Costs

The Calculation: The cost of fuel and oil can add up quickly, especially if you use your chainsaw frequently. A typical chainsaw uses around 1-2 gallons of fuel per day, depending on the size of the engine and the type of work being performed.
Data Point: According to the U.S. Energy Information Administration, the average price of gasoline in the United States in 2023 was around $3.50 per gallon.
My Tip: Buy fuel and oil in bulk to save money. You can also consider using ethanol-free gasoline, which is less likely to cause problems with small engines.

6.3. Bar and Chain Maintenance

The Importance: The bar and chain are critical components of the chainsaw, and they require regular maintenance to ensure optimal performance and safety.
The Costs:
- Chain Sharpening: Chain sharpening can be done at home with a file or with a chain grinder. A chain file typically costs around $10-$20, while a chain grinder can cost $50-$200. Professional chain sharpening services typically cost around $10-$20 per chain.
- Bar Maintenance: The bar should be cleaned and lubricated regularly to prevent wear and tear. The bar rails should also be checked for damage and repaired or replaced as needed. A new chainsaw bar typically costs around $30-$100.
- Chain Replacement: Chains wear out over time and need to be replaced. A new chainsaw chain typically costs around $20-$50.
My Recommendation: Learn how to sharpen your own chainsaw chain. This will save you money in the long run and ensure that your chain is always sharp and ready to use.

6.4. Other Maintenance Costs

Air Filter Replacement: Air filters should be replaced regularly to ensure proper engine performance. A new air filter typically costs around $5-$10.
Fuel Filter Replacement: Fuel filters should also be replaced regularly to prevent fuel starvation. A new fuel filter typically costs around $5-$10.
Spark Plug Replacement: Spark plugs should be replaced annually or as needed. A new spark plug typically costs around $5-$15.
Professional Service: It’s a good idea to have your chainsaw professionally serviced at least once a year. A professional service typically costs around $50-$100.

6.5. The True Cost of DIY vs. Professional Repair

When faced with a chainsaw issue, you have two main options: tackle the repair yourself (DIY) or take it to a professional. Each approach has its own set of costs and benefits.

DIY Repair:
- Pros: Lower cost (you only pay for parts), convenience (you can do it on your own schedule), and the satisfaction of fixing it yourself.
- Cons: Requires knowledge and skills, can be time-consuming, and there’s a risk of making the problem worse if you’re not careful.
- Cost Breakdown: As we’ve seen, the cost of parts for ignition coil replacement and other common repairs can range from $20 to $80.
Professional Repair:
- Pros: Guaranteed quality of work, saves time and effort, and reduces the risk of further damage.
- Cons: Higher cost (you pay for labor as well as parts), and you have to take the chainsaw to a repair shop.
- Cost Breakdown: Labor rates for chainsaw repair typically range from $50 to $100 per hour. The total cost of a professional repair can easily exceed $100, especially if the problem is complex.

6.6. Budgeting for Chainsaw Maintenance

The Rule of Thumb: A good rule of thumb is to budget around 10-15% of the chainsaw’s purchase price per year for maintenance. For a $500 Stihl MS 271, this would translate to $50-$75 per year.
My Approach: I prefer to set aside a dedicated fund for chainsaw maintenance. This helps me avoid unexpected expenses and ensures that I have the money available when needed.

Conclusion: A Spark of Knowledge for Cost-Effective Chainsaw Care

Troubleshooting and fixing a Stihl MS 271 ignition coil issue can seem daunting, but with the right knowledge and tools, it’s a manageable task. By following the steps outlined in this guide, you can diagnose the problem, perform the necessary repairs, and keep your chainsaw running smoothly for years to come.

Remember, preventative maintenance is key to avoiding costly repairs. By keeping your chainsaw clean, using the correct fuel mixture, and performing regular maintenance, you can extend the life of your ignition coil and other engine components.

Ultimately, the decision of whether to tackle a repair yourself or take it to a professional depends on your skills, experience, and budget. If you’re comfortable working on small engines and have the necessary tools, DIY repair can be a cost-effective option. However, if you’re not confident in your abilities, it’s best to leave it to the professionals.

No matter which approach you choose, remember to prioritize safety and always follow the manufacturer’s recommendations. With a little care and attention, your Stihl MS 271 will continue to be a reliable workhorse for many years to come. So, get out there, sharpen your chain, and keep those fires burning – responsibly, of course! And remember, a well-maintained chainsaw isn’t just a tool; it’s an investment in your time, your property, and your peace of mind.
