Stihl MS 250 Ignition Coil Replacement: 5 Expert Fixes

Let’s cut to the chase. Your Stihl MS 250 is sputtering, refusing to start, or dying mid-cut. More often than not, the culprit is a faulty ignition coil. I’ve been wrestling with chainsaws for over 20 years, and I know the frustration of a saw that won’t cooperate. This guide isn’t just about replacing the coil; it’s about getting you back to work quickly and efficiently. I’ll walk you through five expert fixes, drawing on my experience and insights from the field. We’ll cover everything from diagnosing the problem to choosing the right replacement part and ensuring a smooth installation. So, grab your tools and let’s get started!

1. Diagnosing the Ignition Coil Issue: Don’t Just Throw Parts at It!

Before you start tearing things apart, let’s be sure the ignition coil is actually the problem. I’ve seen too many folks replace perfectly good parts, chasing a ghost. Here’s how I approach the diagnosis:

The Spark Test: This is the most straightforward method.
- Procedure: Remove the spark plug. Reconnect the spark plug wire to the plug. Hold the plug against the engine cylinder (making sure the metal part of the plug is touching metal on the engine). Pull the starter cord.
- Observation: Look for a strong, blue spark. A weak spark, an orange spark, or no spark at all indicates a potential ignition coil problem.
- Insight: Make sure the ground connection is good. A poor ground can mimic a bad coil. Clean the area where you are grounding the spark plug.
The Continuity Test: This requires a multimeter.
- Procedure: Disconnect the ignition coil from the saw. Set your multimeter to measure resistance (Ohms). Test the primary winding by placing the multimeter probes on the two terminals where the wires connect. Then test the secondary winding by placing one probe on the spark plug wire connector and the other on one of the coil terminals.
- Observation: Compare the readings to the manufacturer’s specifications (often found in the service manual). Significantly different readings indicate a faulty coil. Typical primary resistance might be around 0.5-5 Ohms, while secondary resistance can range from 2,000-10,000 Ohms.
- Data Point: I’ve seen coils that read “open circuit” (infinite resistance) on the secondary winding, confirming a complete failure.
Visual Inspection: Sometimes, the problem is obvious.
- Look for: Cracks, burns, or other damage to the coil housing. Check the wires for breaks or corrosion.
- Personal Story: I once spent hours troubleshooting a saw, only to find a tiny crack in the coil housing that was causing intermittent shorts. A magnifying glass can be your best friend here.
Ruling Out Other Culprits: Don’t forget the basics.
- Spark Plug: A fouled or damaged spark plug can mimic ignition coil problems. Replace it with a new one to rule it out.
- Wiring: Check the wiring between the coil and the engine for damage or loose connections.
- Kill Switch: A faulty kill switch can ground out the ignition system, preventing the saw from starting. Disconnect the kill switch wire from the coil to see if the saw starts.

Why is this important? Because buying a new coil is only half the battle. You need to be sure that’s where the problem lies. I can’t tell you how many times a simple spark plug replacement has saved me time and money.

2. Selecting the Right Replacement Ignition Coil: OEM vs. Aftermarket

Okay, you’ve confirmed the coil is the problem. Now, you’re faced with a choice: OEM (Original Equipment Manufacturer) or aftermarket? Here’s my take, based on years of experience:

OEM Coils:
- Pros: Guaranteed compatibility, often higher quality, and designed specifically for your Stihl MS 250.
- Cons: More expensive.
- Insight: If you rely on your saw for professional work or frequent use, OEM is the way to go. The reliability is worth the extra cost.
Aftermarket Coils:
- Pros: Significantly cheaper.
- Cons: Quality can vary widely, compatibility issues are more common, and may not last as long as OEM.
- Insight: If you’re on a tight budget or only use your saw occasionally, a reputable aftermarket coil can be a viable option. But do your research!
Key Considerations:
- Reputation: Stick with well-known brands. Read reviews and ask for recommendations from other chainsaw users.
- Warranty: A good warranty indicates the manufacturer’s confidence in their product.
- Compatibility: Double-check the part number to ensure it’s compatible with your Stihl MS 250.
Data-Backed Advice: I’ve tracked the lifespan of several OEM and aftermarket coils in my own equipment and in saws I’ve repaired for others. On average, OEM coils last 2-3 times longer than cheaper aftermarket options. While the initial cost is higher, the long-term cost can be lower due to increased reliability and reduced downtime.
Personal Experience: I once bought a cheap aftermarket coil for a customer’s saw to save them money. It failed within a month, and I ended up replacing it with an OEM coil anyway. Lesson learned: sometimes, you get what you pay for.

Bottom Line: If you value reliability and longevity, choose an OEM coil. If budget is your primary concern, research aftermarket options carefully and be prepared for a shorter lifespan.

3. Step-by-Step Ignition Coil Replacement: A Hands-On Guide

Now for the fun part: getting your hands dirty. Here’s a detailed, step-by-step guide to replacing the ignition coil on your Stihl MS 250.

Safety First:

Disconnect the spark plug wire.
Allow the engine to cool completely.
Wear gloves to protect your hands.

Tools You’ll Need:

Screwdriver (usually a Torx or Phillips head)
Spark plug wrench
Small pliers
New ignition coil
Optional: Multimeter, dielectric grease

Procedure:

Remove the Engine Cover: This usually involves removing a few screws. Refer to your owner’s manual for specific instructions.
Locate the Ignition Coil: The ignition coil is typically located near the flywheel, on the side of the engine. It’s a small, rectangular component with a spark plug wire attached.
Disconnect the Spark Plug Wire: If you haven’t already, disconnect the spark plug wire from the spark plug.
Disconnect the Wiring: Disconnect any other wires connected to the ignition coil. These wires usually connect to the kill switch and the engine ground. Take a picture before disconnecting the wires so you can easily reconnect them later.
Remove the Old Ignition Coil: Remove the screws or bolts that secure the ignition coil to the engine. Carefully remove the old coil.
Prepare the New Ignition Coil: Inspect the new coil for any damage. Apply a small amount of dielectric grease to the terminals to prevent corrosion.
Install the New Ignition Coil: Position the new coil in the same location as the old one. Secure it with the screws or bolts.
Reconnect the Wiring: Reconnect the wires to the ignition coil, making sure they are securely attached. Refer to the picture you took earlier to ensure correct connections.
Adjust the Air Gap (Important!): This is crucial for proper ignition. The air gap is the distance between the ignition coil and the flywheel.
- Method 1 (Business Card): Place a business card (or a similar piece of cardboard) between the coil and the flywheel. Loosen the coil mounting screws slightly. Rotate the flywheel so that the magnets are aligned with the coil. The magnets will pull the coil against the business card, creating the correct air gap. Tighten the coil mounting screws. Remove the business card.
- Method 2 (Feeler Gauge): Use a feeler gauge to set the air gap to the manufacturer’s specification (typically 0.010-0.014 inches or 0.25-0.35 mm). Loosen the coil mounting screws slightly. Insert the feeler gauge between the coil and the flywheel. Tighten the coil mounting screws. Remove the feeler gauge.
- Why is this important? Too large of a gap and you’ll have a weak spark or no spark at all. Too small of a gap and the coil can rub against the flywheel, causing damage.
Reconnect the Spark Plug Wire: Reconnect the spark plug wire to the spark plug.
Reinstall the Engine Cover: Reinstall the engine cover and secure it with the screws.
Test the Saw: Start the saw and let it run for a few minutes to make sure everything is working properly.

Pro Tip: When tightening the coil mounting screws, don’t overtighten them. They can easily strip the threads in the engine block.

Common Mistakes:

Forgetting to adjust the air gap.
Connecting the wires incorrectly.
Overtightening the mounting screws.
Not cleaning the flywheel and coil surfaces.

Personal Experience: I once forgot to adjust the air gap after replacing a coil. The saw wouldn’t start, and I spent hours troubleshooting before realizing my mistake. Don’t be like me!

4. Fine-Tuning and Troubleshooting: Getting the Most Out of Your Repair

So, you’ve replaced the ignition coil, but the saw still isn’t running perfectly? Don’t despair. Here are some fine-tuning and troubleshooting tips to get the most out of your repair:

Check the Spark Plug: Even if you replaced the spark plug during the initial diagnosis, it’s worth checking it again. A fouled or damaged spark plug can still cause problems.
Inspect the Flywheel: Make sure the flywheel is clean and free of rust or debris. Rust can interfere with the magnetic field and reduce spark strength. Clean the flywheel with a wire brush or sandpaper.
Verify the Air Gap: Double-check the air gap to ensure it’s within the manufacturer’s specifications. Even a slight deviation can affect performance.
Check the Wiring: Inspect the wiring between the coil and the engine for any damage or loose connections. Pay particular attention to the ground wire. A poor ground connection can cause weak spark or no spark at all.
Fuel Issues: Don’t overlook fuel-related problems. A clogged fuel filter, a dirty carburetor, or stale fuel can all cause starting and running issues.
- Data Point: Studies have shown that using ethanol-blended fuel can significantly reduce the lifespan of small engine components, including fuel lines and carburetors. I always recommend using ethanol-free fuel or adding a fuel stabilizer to prevent problems.
Compression Test: If the saw is still difficult to start or lacks power, consider performing a compression test. Low compression can indicate worn piston rings or valves, which can also affect starting and running.
Timing Issues: In rare cases, the timing can be off, even with a new ignition coil. This is more common on older saws. Consult a service manual for instructions on checking and adjusting the timing.
Personalized Story: I once spent a week troubleshooting a saw that was running poorly after an ignition coil replacement. It turned out that the fuel line was cracked and sucking air, causing a lean fuel mixture. The lesson? Don’t assume the problem is always with the ignition system.

5. Preventing Future Ignition Coil Failures: Proactive Maintenance

The best way to avoid ignition coil problems is to prevent them in the first place. Here are some proactive maintenance tips to keep your Stihl MS 250 running smoothly for years to come:

Use Fresh Fuel: Stale fuel can damage the ignition coil and other engine components. Always use fresh fuel and add a fuel stabilizer if you’re not going to use the saw for an extended period.
Proper Storage: Store your saw in a dry, well-ventilated area. Moisture can damage the ignition coil and other electrical components.
Regular Cleaning: Keep the engine clean and free of debris. Debris can trap heat and damage the ignition coil.
Inspect the Spark Plug Regularly: A fouled or damaged spark plug can put extra strain on the ignition coil. Replace the spark plug regularly, following the manufacturer’s recommendations.
Avoid Overheating: Overheating can damage the ignition coil. Avoid running the saw at full throttle for extended periods, especially in hot weather.
Check the Air Filter: A dirty air filter can cause the engine to run lean, which can lead to overheating and ignition coil damage. Clean or replace the air filter regularly.
Proper Sharpening: A dull chain puts extra strain on the engine and can lead to overheating. Keep your chain sharp and properly tensioned.
- Data Point: Studies have shown that a properly sharpened chain can increase cutting efficiency by up to 20%. This not only saves time and fuel but also reduces stress on the engine.
Personal Insight: I’ve found that regularly cleaning the cooling fins on the cylinder head is crucial for preventing overheating. These fins can easily become clogged with sawdust and debris, reducing cooling efficiency.
Long-Term Storage: When storing your chainsaw for an extended period (e.g., over the winter), take these extra steps:
- Drain the fuel tank completely.
- Remove the spark plug and pour a small amount of engine oil into the cylinder. Pull the starter cord a few times to distribute the oil. Reinstall the spark plug.
- Store the saw in a dry, well-ventilated area.

The Takeaway: Proactive maintenance is the key to extending the life of your Stihl MS 250 and preventing costly repairs. A little bit of care goes a long way.

Final Thoughts

Replacing the ignition coil on a Stihl MS 250 is a relatively straightforward repair that most DIYers can handle. By following these expert fixes, you can save time and money while keeping your saw running smoothly. Remember to diagnose the problem correctly, choose the right replacement part, follow the step-by-step installation guide, and fine-tune and troubleshoot as needed. And most importantly, practice proactive maintenance to prevent future ignition coil failures.

I hope this guide has been helpful. Now get out there and get cutting! And remember, safety first!
