Stihl FS 56 RC Starter Rope Replacement (Fix Recoil Spring Issues)

As an expert in chainsaws, wood processing, logging tools, and firewood preparation, I understand the inevitable wear-and-tear these tools endure. The Stihl FS 56 RC is no exception. One of the most common issues I’ve seen over the years is a malfunctioning starter rope, often accompanied by problems with the recoil spring. I’ve personally tackled dozens of these repairs, and I’m here to share my knowledge and guide you through the process of replacing the starter rope and addressing recoil spring issues on your Stihl FS 56 RC. Let’s dive in and get your trimmer back in top shape!

Understanding the Starter Mechanism

Before we get our hands dirty, let’s understand how the starter mechanism works. It’s a relatively simple system, but knowing the components and their functions will make the repair process much smoother.

• Starter Rope: The rope you pull to initiate the engine’s rotation.
• Recoil Spring: A coiled spring that retracts the starter rope after you pull it.
• Starter Pulley: The wheel around which the starter rope is wound.
• Pawls (Dogs): Small levers that engage with the engine’s flywheel to turn the engine over.
• Housing: The protective casing that encloses the entire mechanism.

When you pull the starter rope, it turns the starter pulley. The pawls engage with the flywheel, causing the engine to rotate. Once the engine starts, the pawls disengage, and the recoil spring retracts the rope back into the housing.

Identifying the Problem

Before you start tearing things apart, it’s crucial to accurately diagnose the problem. Here are a few common symptoms and their potential causes:

• Rope Breaks Easily: This usually indicates a worn or frayed rope.
• Rope Won’t Retract: This typically points to a broken or weak recoil spring.
• Rope Pulls Out Easily Without Resistance: This could mean a broken recoil spring or disengaged pawls.
• Rope is Difficult to Pull: This might be due to a seized engine, but can also be a very tight/overwound recoil spring, or internal debris.

My Experience: I once spent an hour trying to diagnose a trimmer that wouldn’t start, only to discover that the starter rope was frayed and intermittently slipping on the pulley. A simple rope replacement solved the problem. Always start with the obvious!

Tools and Materials You’ll Need

Having the right tools and materials on hand will make the repair process much easier and faster. Here’s what I recommend:

• New Starter Rope: Purchase a high-quality rope that is the correct diameter and length for your Stihl FS 56 RC. I prefer a rope with a braided nylon construction for durability.
• New Recoil Spring (Optional): If you suspect the recoil spring is damaged, it’s best to replace it.
• Screwdrivers: A set of screwdrivers, including both flathead and Phillips head, will be necessary to remove the starter housing.
• Pliers: Pliers are useful for gripping and manipulating small parts.
• Needle-Nose Pliers: These are particularly helpful for working with the recoil spring.
• Work Gloves: Protect your hands from dirt, grease, and sharp edges.
• Safety Glasses: Always wear safety glasses to protect your eyes from debris.
• Pen or Marker: For marking the rope length.
• Lighter or Heat Source: To melt the end of the rope and prevent fraying.
• Clean Work Surface: A clean and well-lit workspace will help you stay organized and avoid losing small parts.
• Stihl Special Tool (Optional but Recommended): A Stihl winding tool or similar can make the recoil spring installation much easier and safer.

Pro Tip: I always keep a small container handy to store screws and other small parts. This prevents them from getting lost and makes reassembly much easier.

Step-by-Step Guide to Starter Rope Replacement

Now, let’s get into the actual repair process. Follow these steps carefully, and you’ll have your Stihl FS 56 RC back up and running in no time.

Step 1: Removing the Starter Housing

1. Locate the Starter Housing: The starter housing is typically located on the side of the engine. It’s a circular or oval-shaped cover with the starter rope extending from it.
2. Remove the Screws: Use a screwdriver to remove the screws that secure the starter housing to the engine. The number of screws may vary, but it’s usually between three and five. Store the screws in a safe place.
3. Carefully Remove the Housing: Gently pull the starter housing away from the engine. Be careful not to damage any of the internal components.

My Experience: I once rushed this step and accidentally stripped one of the screws. Take your time and use the correct size screwdriver to avoid this problem.

Step 2: Inspecting the Components

1. Examine the Starter Rope: Check the starter rope for signs of wear, fraying, or damage. If the rope is worn, it needs to be replaced.
2. Inspect the Recoil Spring: Look for any signs of damage, such as broken coils or distortion. If the spring is damaged, it needs to be replaced.
3. Check the Starter Pulley: Make sure the pulley is clean and free of debris. Also, check the pawls (dogs) to ensure they move freely and engage properly.
4. Clean the Housing: Use a brush or compressed air to remove any dirt or debris from the starter housing.

Pro Tip: While you have the housing open, it’s a good idea to lubricate the pawls with a small amount of grease. This will help them move smoothly and prevent them from sticking.

Step 3: Removing the Old Starter Rope

1. Locate the Knot: Find the knot on the end of the starter rope that secures it to the starter pulley.
2. Untie the Knot: Use a small screwdriver or needle-nose pliers to carefully untie the knot.
3. Pull Out the Rope: Gently pull the old starter rope out of the pulley.

My Experience: Sometimes the knot is very tight and difficult to untie. In these cases, I use a small knife to carefully cut the knot, being careful not to damage the pulley.

Step 4: Installing the New Starter Rope

1. Insert the New Rope: Thread the new starter rope through the hole in the starter pulley.
2. Tie a Secure Knot: Tie a secure knot in the end of the rope to prevent it from slipping out of the pulley. I recommend using a figure-eight knot or a double overhand knot. Make sure the knot is tight and secure.
3. Wind the Rope: Wind the starter rope around the starter pulley in the correct direction. The direction will depend on the design of the pulley, so pay attention to how the old rope was wound.
4. Secure the Rope End: Thread the other end of the starter rope through the hole in the starter housing. Pull the rope through until the knot is snug against the pulley.
5. Adjust the Rope Length: Pull the rope out to its full extension and mark the desired length with a pen or marker. Allow for enough slack to comfortably grip the handle.
6. Cut the Rope: Cut the rope at the marked length.
7. Melt the End: Use a lighter or heat source to melt the end of the rope and prevent it from fraying. This will also make it easier to thread the rope through the handle.
8. Attach the Handle: Thread the melted end of the rope through the hole in the starter handle and tie a secure knot.

Pro Tip: Before tying the knot in the handle, make sure the rope is properly aligned and not twisted. This will prevent the rope from binding and ensure smooth operation.

Step 5: Addressing Recoil Spring Issues (If Necessary)

If you suspect the recoil spring is damaged, you’ll need to remove it and replace it. This can be a tricky process, so proceed with caution.

1. Release Tension: Before removing the recoil spring, you need to release the tension on it. This can be done by carefully unwinding the spring a few turns at a time. Wear safety glasses, as the spring can snap and cause injury.
2. Remove the Spring: Once the tension is released, you can remove the recoil spring from the housing.
3. Install the New Spring: Install the new recoil spring into the housing. Make sure the spring is properly seated and aligned.
4. Wind the Spring: Use a Stihl winding tool or similar to wind the recoil spring. This will preload the spring and provide the necessary tension to retract the starter rope. If you don’t have a winding tool, you can carefully wind the spring by hand, but this is more difficult and potentially dangerous.
5. Secure the Spring: Once the spring is wound, secure it in place with the retaining clip or other mechanism.

Warning: The recoil spring is under tension and can cause serious injury if mishandled. Always wear safety glasses and gloves when working with the recoil spring. If you are not comfortable working with the recoil spring, it’s best to take the starter housing to a qualified repair technician.

My Experience: I’ve replaced dozens of recoil springs, and I still find it to be a challenging task. The Stihl winding tool is a lifesaver! It makes the process much easier and safer.

Step 6: Reassembling the Starter Housing

1. Position the Housing: Carefully position the starter housing back onto the engine.
2. Align the Holes: Align the screw holes in the housing with the corresponding holes in the engine.
3. Install the Screws: Install the screws and tighten them securely. Be careful not to overtighten the screws, as this can damage the housing or the engine.

Pro Tip: Before tightening the screws, make sure the starter rope retracts smoothly and fully. If the rope is not retracting properly, check the recoil spring and make sure it is properly wound and secured.

Step 7: Testing the Repair

1. Pull the Starter Rope: Pull the starter rope a few times to make sure it retracts smoothly and fully.
2. Start the Engine: Attempt to start the engine. If the engine starts, congratulations! You have successfully replaced the starter rope and addressed any recoil spring issues.
3. Fine-Tune (If Necessary): If the engine doesn’t start, double-check all of your connections and make sure everything is properly aligned. You may need to adjust the tension on the recoil spring or adjust the carburetor settings.

My Experience: I’ve had a few instances where the engine wouldn’t start after replacing the starter rope. In these cases, I always double-check the spark plug, fuel filter, and carburetor settings.

Common Mistakes to Avoid

• Using the Wrong Size Rope: Using a rope that is too thick or too thin can cause problems with the starter mechanism. Always use the correct size rope for your Stihl FS 56 RC.
• Overtightening the Screws: Overtightening the screws can damage the starter housing or the engine. Tighten the screws until they are snug, but don’t overtighten them.
• Not Releasing Tension on the Recoil Spring: Attempting to remove the recoil spring without releasing the tension can be dangerous. Always release the tension on the spring before removing it.
• Forgetting to Lubricate the Pawls: Lubricating the pawls will help them move smoothly and prevent them from sticking.
• Using the Wrong Type of Knot: Using the wrong type of knot can cause the rope to slip out of the pulley or handle. Always use a secure knot that is appropriate for the application.

Maintenance Tips to Prolong Starter Rope Life

• Avoid Over-Pulling the Rope: Pulling the starter rope too hard can damage the rope and the recoil spring. Pull the rope smoothly and evenly.
• Keep the Starter Housing Clean: Dirt and debris can damage the starter rope and the other components of the starter mechanism. Keep the starter housing clean by wiping it down regularly.
• Store the Trimmer Properly: Storing the trimmer in a dry and protected location will help prevent the starter rope from deteriorating.
• Replace the Rope Regularly: Even with proper maintenance, the starter rope will eventually wear out. Replace the rope every year or two, or sooner if it shows signs of wear.

My Experience: I’ve found that using a silicone-based lubricant on the starter rope can help prolong its life. The lubricant helps to reduce friction and prevent the rope from drying out and cracking.

Alternative Solutions

If you’re not comfortable performing the starter rope replacement yourself, there are a few alternative solutions:

• Take it to a Repair Shop: A qualified repair technician can quickly and easily replace the starter rope and address any recoil spring issues.
• Purchase a New Starter Housing: If the starter housing is damaged, you may be able to purchase a new housing with the starter rope already installed. This can be a more expensive option, but it can save you time and effort.

Troubleshooting Guide

Here’s a quick troubleshooting guide to help you diagnose and fix common starter problems:

• Problem: Rope breaks easily.
  • Possible Cause: Worn or frayed rope.
  • Solution: Replace the starter rope.
• Problem: Rope won’t retract.
  • Possible Cause: Broken or weak recoil spring.
  • Solution: Replace the recoil spring.
• Problem: Rope pulls out easily without resistance.
  • Possible Cause: Broken recoil spring or disengaged pawls.
  • Solution: Replace the recoil spring or repair the pawls.
• Problem: Rope is difficult to pull.
  • Possible Cause: Seized engine, tight recoil spring, or internal debris.
  • Solution: Diagnose the engine, adjust the recoil spring tension, or clean the starter housing.
• Problem: Engine won’t start after replacing the rope.
  • Possible Cause: Incorrect rope installation, spark plug issues, fuel problems.
  • Solution: Double-check rope installation, check spark plug, check fuel filter and carburetor.

Safety Precautions

• Always wear safety glasses and gloves when working with the starter mechanism.
• Release the tension on the recoil spring before removing it.
• Be careful when handling the recoil spring, as it can snap and cause injury.
• Work in a well-lit and ventilated area.
• Disconnect the spark plug wire before working on the engine.
• Keep children and pets away from the work area.

Advanced Techniques

For those who want to delve deeper into starter mechanism repair, here are a few advanced techniques:

• Adjusting Recoil Spring Tension: The tension on the recoil spring can be adjusted to optimize the rope retraction force. This requires careful adjustment and a specialized tool.
• Replacing Pawls (Dogs): If the pawls are worn or damaged, they can be replaced. This requires disassembling the starter pulley and installing new pawls.
• Diagnosing Engine Problems: If the engine is difficult to start, it may be due to problems with the carburetor, spark plug, or other engine components. Diagnosing these problems requires specialized knowledge and tools.

Conclusion

Replacing the starter rope and addressing recoil spring issues on your Stihl FS 56 RC can seem daunting, but with the right knowledge and tools, it’s a manageable task. I’ve shared my personal experiences and insights to guide you through the process, from diagnosing the problem to reassembling the starter housing. Remember to prioritize safety and take your time. With a little patience and perseverance, you’ll have your trimmer back in top shape in no time. Now, get out there and get back to work!
