Let’s face it, the Stihl 011av is a workhorse. I’ve owned mine for over two decades, and it’s seen more firewood seasons than I care to count. While newer, shinier models might tempt you, the 011av, with a little TLC, can still hold its own. This guide isn’t just about generic chainsaw advice; it’s specifically tailored to keeping your Stihl 011av roaring. Think of it as a deep dive into the guts of this classic machine, combined with some hard-earned woodcutting wisdom I’ve picked up over the years. I’ll share my best repair tips and woodcutting techniques to keep your Stihl 011av running strong, all while maximizing your efficiency and safety.

Understanding the Stihl 011av: A Foundation for Repair

Before we dive into the repair tips, it’s crucial to understand the Stihl 011av’s core components and design. This isn’t just about knowing where the spark plug is; it’s about grasping why things are the way they are.

• Engine: The 011av typically features a single-cylinder, two-stroke engine. Knowing its displacement (around 30.1 cc) is important when sourcing replacement parts like pistons or cylinders. The two-stroke design means you must use a fuel-oil mixture; running straight gas will quickly seize the engine.
• Carburetor: The carburetor regulates the air-fuel mixture. The 011av usually has a Walbro or Zama carburetor. Understanding the adjustment screws (High, Low, and Idle) is critical for proper tuning.
• Ignition System: This system generates the spark to ignite the fuel-air mixture. It includes the magneto, ignition coil, and spark plug. A weak spark is a common culprit for starting problems.
• Fuel System: This encompasses the fuel tank, fuel lines, and fuel filter. A clogged fuel filter is a frequent cause of poor performance.
• Oiling System: This system lubricates the chain and bar. A malfunctioning oiler can lead to premature wear and tear on the cutting components. The Stihl 011av uses an automatic oiler.
• Cutting Components: This includes the bar, chain, and sprocket. Choosing the right bar length and chain type for the wood you’re cutting is essential for efficiency and safety.

Technical Specifications (Stihl 011av):

Repair Tip #1: Carburetor Cleaning and Adjustment – The Heart of Performance

The carburetor is often the first place I look when my 011av starts acting up. Dust, old fuel, and varnish can wreak havoc on its delicate components.

The Problem: A dirty or improperly adjusted carburetor can cause hard starting, rough idling, stalling, and poor performance.

The Solution (Step-by-Step):

1. Safety First: Disconnect the spark plug wire to prevent accidental starting.
2. Access the Carburetor: Remove the air filter cover and air filter. On the 011av, this usually involves loosening a few screws.
3. Remove the Carburetor (Carefully): Disconnect the fuel lines and throttle linkage. Take photos as you go! It’s easy to forget where everything goes. Note the position of the throttle linkage.
4. Disassemble the Carburetor: This is where patience is key. Use a carburetor rebuild kit (specific to Walbro or Zama carburetors used on the 011av). Carefully disassemble the carburetor, noting the location of each part. Pay close attention to the diaphragm and gaskets; they can be brittle and easily damaged.
5. Cleaning: Use carburetor cleaner to thoroughly clean all parts, including the jets, passages, and needle valves. Use compressed air to blow out any remaining debris. A small piece of wire can help clear stubborn clogs, but be gentle!
6. Reassembly: Reassemble the carburetor using the new parts from the rebuild kit. Make sure all gaskets are properly seated.
7. Reinstall the Carburetor: Reconnect the fuel lines and throttle linkage. Double-check your photos to ensure everything is in the correct place.
8. Initial Adjustment: Before starting the saw, set the High (H) and Low (L) speed adjustment screws to the factory settings. These settings are usually found in the Stihl 011av service manual or online. A typical starting point is 1 turn out from fully closed.
9. Start the Saw: After reassembling the saw, start the engine. Let it warm up for a few minutes.
10. Fine-Tuning: Adjust the High (H) and Low (L) speed screws until the engine runs smoothly at both idle and full throttle. Use a tachometer to ensure the engine RPMs are within the specified range (typically around 12,500-13,000 RPM). Don’t over-rev the engine!
11. Idle Adjustment: Adjust the idle speed screw (usually marked “T”) until the chain does not move at idle.

Data Point: A lean fuel mixture (too much air, not enough fuel) can cause the engine to overheat and damage the piston. A rich mixture (too much fuel, not enough air) can cause the engine to run poorly and foul the spark plug.

Personal Insight: I once spent hours trying to diagnose a sputtering 011av, only to find a tiny piece of debris lodged in the main jet of the carburetor. It was a frustrating experience, but it taught me the importance of meticulous cleaning.

Repair Tip #2: Ignition System Troubleshooting – Getting That Spark Back

A weak or non-existent spark is a common reason why a chainsaw won’t start.

The Problem: A faulty ignition coil, spark plug, or wiring can prevent the engine from firing.

The Solution (Step-by-Step):

1. Check the Spark Plug: Remove the spark plug and inspect it. Look for signs of fouling (carbon buildup), damage, or wear. Clean the spark plug with a wire brush or replace it with a new one. The correct spark plug gap for the Stihl 011av is typically 0.5 mm (0.020 inches).
2. Test for Spark: Reconnect the spark plug to the spark plug wire. Hold the spark plug against the engine cylinder (grounding it) and pull the starter cord. You should see a strong, blue spark jump across the spark plug gap. If there is no spark, proceed to the next steps.
3. Check the Spark Plug Wire and Boot: Inspect the spark plug wire and boot for damage or corrosion. Replace if necessary.
4. Check the Ignition Coil: The ignition coil is responsible for generating the high-voltage spark. Use a multimeter to test the resistance of the ignition coil. Consult the Stihl 011av service manual for the correct resistance values. If the ignition coil is faulty, it will need to be replaced.
5. Check the Air Gap: The air gap between the ignition coil and the flywheel is critical for proper ignition. Use a feeler gauge to ensure the air gap is within the specified range (typically 0.3-0.5 mm or 0.012-0.020 inches).
6. Check the Wiring: Inspect all wiring connections for corrosion, damage, or loose connections. Clean or repair as necessary.

Data Point: A faulty ignition coil can cause intermittent starting problems. The engine may start and run fine one day, and then refuse to start the next.

Personal Insight: I once had a Stihl 011av that would only start when it was cold. After much troubleshooting, I discovered that the insulation on the ignition coil wire was cracked, causing it to short out when it warmed up. Replacing the wire solved the problem.

Repair Tip #3: Fuel System Maintenance – Keeping the Flow Going

A clean and properly functioning fuel system is essential for reliable chainsaw operation.

The Problem: Clogged fuel filters, cracked fuel lines, or a faulty fuel pump can restrict fuel flow and cause starting problems or poor performance.

The Solution (Step-by-Step):

1. Check the Fuel Filter: The fuel filter is located inside the fuel tank, attached to the end of the fuel line. Remove the fuel filter and inspect it. If it is dirty or clogged, replace it with a new one.
2. Inspect the Fuel Lines: Inspect the fuel lines for cracks, leaks, or damage. Replace any damaged fuel lines. Use fuel line specifically designed for small engines; automotive fuel line will degrade quickly.
3. Check the Fuel Tank Vent: The fuel tank vent allows air to enter the fuel tank as fuel is used. If the vent is clogged, it can create a vacuum in the fuel tank and prevent fuel from flowing to the carburetor. Clean the vent with compressed air or a small wire.
4. Check the Fuel Pump: The Stihl 011av uses a diaphragm-type fuel pump, which is integrated into the carburetor. If the fuel pump is faulty, it will need to be rebuilt or replaced. This is usually addressed when rebuilding the carburetor.
5. Flush the Fuel Tank: Periodically flush the fuel tank with fresh fuel to remove any sediment or debris.

Data Point: Ethanol in gasoline can degrade fuel lines and other fuel system components over time. Use fuel stabilizers to help prevent this.

Personal Insight: I once had a Stihl 011av that would run for a few minutes and then stall. After checking everything else, I discovered that the fuel line inside the fuel tank had a tiny pinhole. The pinhole was allowing air to enter the fuel line, causing the engine to starve for fuel. Replacing the fuel line solved the problem.

Repair Tip #4: Oiling System Inspection – Keeping the Chain Lubricated

Proper chain lubrication is crucial for preventing premature wear and tear on the chain and bar.

The Problem: A malfunctioning oiler can lead to a dry chain, causing excessive friction, overheating, and damage to the cutting components.

The Solution (Step-by-Step):

1. Check the Oil Level: Make sure the oil tank is full. Use bar and chain oil specifically designed for chainsaws.
2. Check the Oiler Output: Start the chainsaw and hold it over a piece of cardboard or wood. You should see a steady stream of oil being ejected from the bar. If there is no oil, proceed to the next steps.
3. Check the Oiler Adjustment: The Stihl 011av has an adjustable oiler. Use a screwdriver to adjust the oiler output. Turn the adjustment screw clockwise to increase the oil output and counterclockwise to decrease the oil output.
4. Check the Oiler Filter: The oiler filter is located inside the oil tank, attached to the end of the oil line. Remove the oil filter and inspect it. If it is dirty or clogged, clean it with solvent or replace it with a new one.
5. Check the Oiler Pump: The oiler pump is responsible for pumping oil from the oil tank to the bar. If the oiler pump is faulty, it will need to be replaced. This is a more involved repair.
6. Clean the Bar Oiling Hole: The bar has a small hole that allows oil to flow from the oiler to the chain. This hole can become clogged with sawdust and debris. Clean the hole with a small wire or compressed air.

Data Point: Using the wrong type of oil can damage the oiler pump. Only use bar and chain oil specifically designed for chainsaws.

Personal Insight: I once neglected to clean the bar oiling hole on my Stihl 011av. As a result, the chain was not getting enough lubrication, and it overheated and broke. I learned my lesson the hard way!

Repair Tip #5: Chain and Bar Maintenance – Maximizing Cutting Efficiency

A sharp chain and a well-maintained bar are essential for efficient and safe woodcutting.

The Problem: A dull chain can cause the chainsaw to kick back, increasing the risk of injury. A damaged bar can also affect cutting performance and safety.

The Solution (Step-by-Step):

1. Sharpen the Chain: Sharpen the chain regularly using a chainsaw file or a chain grinder. Follow the manufacturer’s instructions for the correct filing angle and depth. I prefer to use a file for field sharpening, and a grinder for more in-depth work.
2. Check the Chain Tension: The chain should be tight enough that it does not sag excessively, but loose enough that it can be pulled around the bar by hand. Adjust the chain tension as needed.
3. Clean the Bar Groove: The bar groove can become clogged with sawdust and debris. Clean the groove regularly with a bar groove cleaner or a screwdriver.
4. Inspect the Bar: Inspect the bar for wear, damage, or burrs. File off any burrs with a file. If the bar is excessively worn or damaged, replace it.
5. Flip the Bar: Periodically flip the bar over to distribute wear evenly.
6. Choose the Right Chain: There are different types of chainsaw chains for different applications. Choose a chain that is appropriate for the type of wood you are cutting. For example, a full chisel chain is best for cutting clean wood, while a semi-chisel chain is more durable and better suited for cutting dirty or knotty wood.

Data Point: A properly sharpened chain can cut up to 20% faster than a dull chain.

Personal Insight: I once tried to cut through a large oak log with a dull chain. The chainsaw kept kicking back, and I almost lost control of it. I quickly learned the importance of keeping the chain sharp!

5 Pro Woodcutting Hacks for Your Stihl 011av

Now that we’ve covered the repair side, let’s talk about getting the most out of your Stihl 011av in the woods. These are techniques I’ve refined over years of cutting, and they’ll help you work smarter, not harder.

Hack #1: The Bore Cut – Felling Trees with Precision

The bore cut is a technique used to fell trees in a controlled manner, especially when you need to avoid damaging nearby objects or structures. It involves cutting into the center of the tree before making the felling cut.

• How it Works:
  1. Make a face cut (notch) on the side of the tree you want it to fall.
  2. Carefully bore into the center of the tree, behind the face cut, with the tip of the chainsaw bar.
  3. Leave a hinge of wood to control the direction of the fall.
  4. Make the felling cut, leaving the hinge intact.
  5. As the tree starts to fall, the hinge will guide it in the desired direction.

Safety Note: Bore cuts require advanced chainsaw skills and should only be attempted by experienced users. Kickback is a serious risk.

Hack #2: The Hinge – Controlling the Fall

The hinge is the key to controlling the direction of a falling tree. It’s a strip of wood left uncut between the face cut and the felling cut.

• Hinge Dimensions: The width of the hinge should be approximately 80% of the diameter of the tree. The thickness of the hinge should be approximately 10% of the diameter of the tree.
• Hinge Placement: The hinge should be placed perpendicular to the desired direction of fall.
• Hinge Function: The hinge acts as a pivot point, guiding the tree as it falls.

Data Point: A properly sized and placed hinge can increase the accuracy of tree felling by up to 90%.

Hack #3: The “Reading the Wood” Technique

Experienced woodcutters can “read the wood” to anticipate how a tree will react during felling. This involves observing the tree’s lean, wind conditions, and any signs of stress or weakness.

• Lean: A tree’s natural lean will influence the direction of fall.
• Wind: Wind can significantly affect the direction of fall.
• Stress: Look for signs of stress, such as cracks or splits in the trunk.
• Weakness: Look for signs of weakness, such as rot or decay.

Personal Insight: I once felled a large maple tree that had a hidden split in the trunk. As I made the felling cut, the tree unexpectedly twisted and fell in a different direction than I had planned. Fortunately, no one was hurt, but it taught me the importance of carefully inspecting trees before cutting them down.

Hack #4: Limb Removal – The Right Way

Removing limbs from a felled tree can be dangerous if not done properly.

• Work from the Top Down: Start by removing the smaller limbs at the top of the tree and work your way down. This will help prevent the tree from rolling or shifting.
• Use Proper Cutting Techniques: Use the “overcut” technique for limbs that are under tension and the “undercut” technique for limbs that are under compression. This will help prevent the chainsaw from binding.
• Be Aware of Springback: Limbs can spring back when they are cut, potentially causing injury. Stand to the side of the limb when cutting it.

Hack #5: Efficient Bucking Techniques

Bucking is the process of cutting a felled tree into smaller, more manageable lengths.

• Plan Your Cuts: Before you start cutting, plan your cuts to minimize waste and maximize efficiency.
• Support the Log: Support the log on sawhorses or other supports to prevent it from pinching the chainsaw blade.
• Use Proper Cutting Techniques: Use the “overcut” technique for logs that are under tension and the “undercut” technique for logs that are under compression.
• Avoid Cutting into the Ground: Avoid cutting into the ground, as this can dull the chain and damage the chainsaw.
• Consider Log Diameter: For logs with a diameter of 12 inches or less, I often use a single cut from the top. For larger logs, I’ll use a combination of overcuts and undercuts to prevent pinching.

Technical Specification (Firewood Moisture Content):

Safety Equipment Requirements

No amount of skill can replace proper safety gear. I never start my Stihl 011av without the following:

• Chainsaw Chaps: These protect your legs from accidental chainsaw contact.
• Eye Protection: Safety glasses or a face shield are essential to protect your eyes from flying debris.
• Hearing Protection: Chainsaws are loud. Earplugs or earmuffs will prevent hearing damage.
• Gloves: Gloves provide a better grip and protect your hands from cuts and abrasions.
• Steel-Toed Boots: Steel-toed boots protect your feet from falling logs and other hazards.
• Helmet: A helmet is essential to protect your head from falling branches or other objects.

Legal Considerations: Always be aware of local forestry regulations and safety codes. These regulations vary by region and may include requirements for chainsaw operator certification, tree felling permits, and restrictions on logging activities.

Personal Story: I remember one time I was cutting firewood without wearing my chainsaw chaps. I accidentally slipped and the chainsaw came into contact with my leg. Fortunately, I was only wearing jeans, so the cut wasn’t serious. But it could have been much worse. I learned my lesson that day!

Conclusion: Keeping the Legend Alive

The Stihl 011av is a testament to durable engineering. With consistent maintenance, a few smart repairs, and by following my woodcutting hacks, you can keep your saw running for years to come. This guide has combined technical details with practical tips, aiming to equip you with the knowledge and skills to tackle any wood processing task effectively. Remember, safety is paramount, and continuous learning will make you a better and more efficient woodcutter. Now, get out there, keep your chain sharp, and make some firewood!
