Stihl 011 AV Chainsaw Tips (5 Expert Fixes for Non-Starters)
The Stihl 011 AV: A Trendsetter’s Choice, A Logger’s Companion
Back in the day, the Stihl 011 AV wasn’t just another chainsaw; it was a statement. For many small-scale loggers and ambitious hobbyists, it was their first real taste of professional-grade equipment. It was lightweight, reliable, and surprisingly powerful for its size. I remember my own experience with one – a hand-me-down from my grandfather, a seasoned woodsman. That saw taught me more about wood processing and respect for machinery than any manual ever could. While newer models boast more features, the 011 AV remains a workhorse, especially for those who appreciate its simplicity and ease of repair. It’s a classic for a reason. But like any piece of machinery, it can face issues, and a common frustration is a non-starting engine. Let’s dive into some expert fixes to get your Stihl 011 AV roaring back to life.
Stihl 011 AV: 5 Expert Fixes for Non-Starters
A non-starting chainsaw can be incredibly frustrating, especially when you have a pile of logs waiting to be processed. Over the years, I’ve dealt with my fair share of stubborn Stihl 011 AVs. These are the five most common culprits and the fixes that I’ve found to be most effective.
1. Fuel System Troubles: The Prime Suspect
The fuel system is often the first place I look when an 011 AV refuses to start. Fuel issues account for approximately 60% of non-start problems in my experience. The problem could range from stale fuel to a clogged fuel filter or carburetor.
1.1. Stale Fuel: The Silent Killer
Old fuel is a common enemy of small engines. Gasoline degrades over time, especially when mixed with oil. This degradation can lead to varnish buildup in the carburetor and fuel lines, preventing the engine from starting.
- Symptoms: Hard starting, weak engine performance, fuel smells “off.”
-
Fix:
- Drain the tank: Completely empty the fuel tank. Dispose of the old fuel responsibly (check your local regulations).
- Flush the system: Use fresh, high-quality fuel mixed with a fuel stabilizer to flush the fuel lines. I recommend a fuel stabilizer like Sta-Bil to keep your fuel fresh for up to 24 months.
- Refill: Refill the tank with a fresh fuel mixture. The Stihl 011 AV typically requires a 50:1 fuel-to-oil ratio (50 parts gasoline to 1 part two-cycle engine oil). Important: Always refer to your owner’s manual for the specific fuel-oil mixture ratio for your model. Using the wrong ratio can cause serious engine damage.
- Prime the carburetor: Press the primer bulb (if equipped) several times to draw fuel into the carburetor.
-
Data Point: Gasoline can start to degrade in as little as 30 days, especially if stored in a non-airtight container.
1.2. Clogged Fuel Filter: A Small Part, A Big Problem
The fuel filter prevents debris from entering the carburetor. A clogged filter restricts fuel flow, leading to starting issues or poor performance.
- Symptoms: Engine starts but stalls quickly, lack of power, hard starting.
-
Fix:
- Locate the fuel filter: It’s usually inside the fuel tank, attached to the end of the fuel line.
- Remove the filter: Use a small hook or pliers to carefully pull the fuel filter out of the tank. Be gentle to avoid damaging the fuel line.
- Inspect the filter: Check for dirt, debris, or discoloration.
- Clean or replace the filter: If the filter is only slightly dirty, you can try cleaning it with carburetor cleaner. However, I usually recommend replacing it, as a new filter is inexpensive and ensures proper fuel flow.
- Reinstall the filter: Attach the new or cleaned filter to the fuel line and carefully insert it back into the fuel tank.
-
Tool Requirement: A small hook or long-nosed pliers are helpful for removing the fuel filter.
1.3. Carburetor Issues: The Heart of the Problem
The carburetor mixes air and fuel to create a combustible mixture. A dirty or improperly adjusted carburetor is a frequent cause of starting problems.
- Symptoms: Hard starting, rough idling, stalling, black smoke from the exhaust (rich mixture), lack of power (lean mixture).
-
Fix:
- Carburetor Cleaning: This is often the first step.
- Remove the air filter: Access the carburetor.
- Spray carburetor cleaner: Liberally spray carburetor cleaner into the carburetor throat and any visible jets. Let it soak for a few minutes.
- Start the engine: Try starting the engine. If it starts, let it run for a few minutes to burn off any remaining cleaner.
- Reassemble: Reinstall the air filter.
- Carburetor Adjustment (if cleaning doesn’t work):
- Locate the adjustment screws: The Stihl 011 AV typically has two or three adjustment screws labeled “L” (low-speed), “H” (high-speed), and sometimes “LA” (idle speed).
- Initial settings: As a starting point, turn both the “L” and “H” screws clockwise until they are lightly seated, then back them out 1 to 1.5 turns. This is a baseline, and you’ll need to fine-tune from here.
- Starting and idling: Start the engine. Adjust the “LA” screw to achieve a smooth idle speed. If the engine stalls, turn the “LA” screw clockwise slightly to increase the idle.
- Fine-tuning: Once the engine is idling, slowly adjust the “L” screw. Turn it clockwise until the engine starts to stumble or slow down, then turn it counter-clockwise until it runs smoothly. Repeat this process for the “H” screw, listening for smooth acceleration and optimal high-speed performance.
- Caution: Overtightening the adjustment screws can damage the carburetor. Turn them gently.
- Carburetor Rebuild (if cleaning and adjustment fail): If the carburetor is severely dirty or damaged, a rebuild may be necessary. Carburetor rebuild kits are available and include replacement gaskets, diaphragms, and needles. This is a more involved process, and I recommend consulting a repair manual or watching a tutorial video.
- Carburetor Cleaning: This is often the first step.
-
Tool Requirement: A small flathead screwdriver is required for adjusting the carburetor screws.
- Technical Note: Carburetor adjustments are sensitive. Small adjustments can make a big difference in engine performance.
2. Ignition System Issues: Sparking the Solution
If the fuel system is working correctly, the next place to investigate is the ignition system. The ignition system creates the spark that ignites the fuel-air mixture in the cylinder.
2.1. Spark Plug Problems: The First Line of Defense
The spark plug ignites the fuel-air mixture. A fouled, worn, or improperly gapped spark plug can prevent the engine from starting.
- Symptoms: Hard starting, misfiring, rough running, lack of power.
-
Fix:
- Remove the spark plug: Disconnect the spark plug wire and use a spark plug wrench to remove the spark plug.
- Inspect the spark plug: Check for cracks, carbon buildup, or a worn electrode. A healthy spark plug should have a clean, light brown color.
- Clean or replace the spark plug: If the spark plug is only slightly dirty, you can try cleaning it with a wire brush. However, I usually recommend replacing it with a new spark plug of the correct type (Champion CJ8 or equivalent).
- Gap the spark plug: Use a spark plug gap tool to ensure the gap between the center electrode and the ground electrode is correct. The recommended gap for the Stihl 011 AV is typically 0.5 mm (0.020 inches). Always confirm the correct gap in your owner’s manual.
- Reinstall the spark plug: Carefully thread the spark plug back into the cylinder head and tighten it with a spark plug wrench. Don’t overtighten.
- Reconnect the spark plug wire: Ensure the spark plug wire is securely attached to the spark plug.
-
Tool Requirement: Spark plug wrench, spark plug gap tool, wire brush.
- Data Point: A spark plug’s lifespan is typically around 100-200 hours of use.
2.2. Ignition Coil Failure: The Heart of the Spark
The ignition coil generates the high voltage needed to create a spark at the spark plug. A faulty ignition coil can prevent the engine from starting.
- Symptoms: No spark at the spark plug, engine cranks but doesn’t start.
-
Fix:
- Test for spark: Remove the spark plug and reconnect it to the spark plug wire. Hold the spark plug against a metal part of the engine (ground) and pull the starter rope. Observe the spark plug gap. A healthy ignition system should produce a strong, blue spark. If there is no spark or a weak, yellow spark, the ignition coil may be faulty.
- Check the ignition coil air gap: The air gap between the ignition coil and the flywheel is critical. If the gap is too large or too small, it can prevent the coil from generating a spark. Use a feeler gauge to check the air gap. The recommended air gap for the Stihl 011 AV is typically 0.3 mm (0.012 inches). Refer to your service manual for the precise specification.
- Replace the ignition coil: If the ignition coil is faulty, it will need to be replaced. Replacement coils are readily available online or at your local chainsaw repair shop. Disconnect the old coil, install the new coil, and set the air gap to the specified value.
-
Tool Requirement: Spark plug wrench, feeler gauge, multimeter (optional for testing coil resistance).
3. Compression Issues: Sealing the Deal
Compression is essential for the engine to ignite the fuel-air mixture. Low compression can be caused by worn piston rings, a damaged cylinder, or a leaking head gasket.
- Symptoms: Hard starting, lack of power, engine cranks easily but doesn’t start.
-
Fix:
- Compression Test: The most accurate way to check compression is with a compression tester.
- Remove the spark plug:
- Install the compression tester: Screw the compression tester into the spark plug hole.
- Pull the starter rope: Pull the starter rope several times while holding the throttle wide open.
- Read the gauge: Note the highest reading on the compression tester. A healthy Stihl 011 AV should have a compression reading of at least 120 psi (827 kPa). Anything below 100 psi (689 kPa) indicates a compression problem.
- Possible Causes and Solutions:
- Worn Piston Rings: Replacing the piston rings requires disassembling the engine. This is a more advanced repair.
- Damaged Cylinder: A scored or damaged cylinder can also cause low compression. In severe cases, the cylinder may need to be replaced.
- Leaking Head Gasket: A leaking head gasket can cause compression to escape. Replacing the head gasket is a relatively straightforward repair.
- Compression Test: The most accurate way to check compression is with a compression tester.
-
Tool Requirement: Compression tester.
- Technical Note: Performing a compression test can provide valuable information about the internal condition of the engine.
4. Air Filter Obstructions: Breathing Easy
A clean air filter is crucial for proper engine performance. A dirty or clogged air filter restricts airflow, leading to a rich fuel mixture, hard starting, and reduced power.
- Symptoms: Hard starting, black smoke from the exhaust, lack of power.
-
Fix:
- Locate the air filter: The air filter is usually located in a housing on top of or behind the carburetor.
- Remove the air filter: Remove the air filter cover and take out the air filter.
- Inspect the air filter: Check for dirt, debris, or oil saturation.
- Clean or replace the air filter: If the air filter is only slightly dirty, you can try cleaning it with compressed air or warm, soapy water. Allow the filter to dry completely before reinstalling it. If the filter is heavily soiled or damaged, replace it with a new one.
- Reinstall the air filter: Place the clean or new air filter back into the housing and secure the air filter cover.
-
Tool Requirement: Compressed air (optional).
- Best Practice: I recommend cleaning the air filter after every 5-10 hours of use, or more frequently in dusty conditions.
5. Exhaust System Blockage: Letting it Flow
A blocked exhaust system can restrict the engine’s ability to expel exhaust gases, leading to reduced power and starting problems.
- Symptoms: Hard starting, lack of power, engine stalls easily, excessive heat.
-
Fix:
- Check the spark arrestor screen: The spark arrestor screen is a small screen located in the muffler that prevents sparks from exiting the exhaust system. Over time, this screen can become clogged with carbon deposits.
- Locate the spark arrestor screen: It’s usually accessible by removing a small cover on the muffler.
- Remove the spark arrestor screen: Use a small screwdriver or pick to carefully remove the screen.
- Clean the spark arrestor screen: Use a wire brush to remove any carbon deposits from the screen. You can also soak the screen in carburetor cleaner for a few minutes.
- Reinstall the spark arrestor screen: Place the clean screen back into the muffler and secure the cover.
- Check for other blockages: Inspect the muffler and exhaust port for any other obstructions, such as carbon buildup or debris. If you find any blockages, carefully remove them with a wire brush or scraper.
- Check the spark arrestor screen: The spark arrestor screen is a small screen located in the muffler that prevents sparks from exiting the exhaust system. Over time, this screen can become clogged with carbon deposits.
-
Tool Requirement: Small screwdriver or pick, wire brush.
- Safety Code: Regularly cleaning the spark arrestor screen is essential for preventing wildfires.
Preventative Maintenance: Keeping Your 011 AV in Top Shape
Beyond troubleshooting starting issues, regular preventative maintenance is key to ensuring your Stihl 011 AV runs smoothly for years to come.
- Regular Cleaning: Clean the chainsaw after each use, removing sawdust and debris from the engine, air filter, and chain.
- Chain Sharpening: Keep the chain sharp to improve cutting efficiency and reduce strain on the engine. I prefer using a chainsaw file and guide for precise sharpening.
- Chain Lubrication: Use high-quality chain oil to keep the chain properly lubricated. Check the oil level frequently and refill as needed.
- Proper Storage: Store the chainsaw in a dry place, away from direct sunlight and extreme temperatures. Drain the fuel tank before storing the chainsaw for extended periods.
- Scheduled Servicing: Follow the manufacturer’s recommended service schedule, including replacing the spark plug, fuel filter, and air filter at regular intervals.
Case Study: Reviving a Neglected 011 AV
I once acquired a Stihl 011 AV that had been sitting in a shed for over a decade. It was in rough shape, covered in dust and grime. Unsurprisingly, it wouldn’t start.
- Diagnosis: After a thorough inspection, I found the following issues:
- Stale fuel in the tank
- Clogged fuel filter
- Dirty carburetor
- Fouled spark plug
- Clogged air filter
- Restoration: I systematically addressed each issue:
- Drained the old fuel and flushed the fuel system with fresh fuel and fuel stabilizer.
- Replaced the fuel filter.
- Cleaned the carburetor and adjusted the mixture screws.
- Replaced the spark plug and gapped it to the correct specification.
- Cleaned the air filter.
- Result: After these repairs, the Stihl 011 AV started on the second pull and ran like a champ. This experience reinforced the importance of addressing all potential issues when troubleshooting a non-starting chainsaw.
Conclusion: Keeping the Legend Alive
The Stihl 011 AV is a classic chainsaw that deserves to be kept running. By understanding the common causes of non-starting issues and following these expert fixes, you can keep your 011 AV in top shape for years to come. Remember to prioritize safety, perform regular maintenance, and always refer to your owner’s manual for specific instructions and recommendations. With a little care and attention, your Stihl 011 AV will continue to be a reliable workhorse for all your wood processing needs.
Safety First: A Reminder
Before performing any maintenance or repairs on your chainsaw, always:
- Disconnect the spark plug wire to prevent accidental starting.
- Wear appropriate safety gear, including gloves, eye protection, and hearing protection.
- Work in a well-ventilated area.
- Dispose of used fuel and oil responsibly.
- Consult a qualified technician if you are not comfortable performing the repairs yourself.
Remember, your safety is paramount.
