Starting Stihl MS170 Troubleshooting: Pro Tips for Smooth Ignition

The Stihl MS170 is a workhorse. It’s the chainsaw I often recommend to friends and family just starting out with wood cutting. It’s lightweight, relatively inexpensive, and surprisingly powerful for its size.

I’ve spent countless hours in the woods, from the crisp, cool mornings of the Pacific Northwest to the humid, sweltering afternoons of the Southeast, relying on my trusty Stihl MS170. I’ve learned that a little preventative maintenance and understanding of its inner workings can save you a lot of frustration. Think of this guide as your personal chainsaw whisperer, helping you diagnose and solve those pesky starting issues.

This guide will provide you with a systematic approach to troubleshooting starting problems with your Stihl MS170. I’ll cover everything from the basics like fuel and spark to more advanced issues like carburetor adjustments. I’ll share pro tips I’ve picked up over the years, along with some data-backed insights and safety considerations to ensure you’re not just getting your saw running, but doing it safely and efficiently.

1. The Essential Checks: Fuel, Spark, and Air

Before diving into more complex troubleshooting, let’s cover the three essentials: fuel, spark, and air. These are the pillars of any internal combustion engine, and a problem with any of them can prevent your MS170 from starting.

1.1 Fuel System Inspection

Fuel Mix: The Stihl MS170 requires a 50:1 fuel-to-oil ratio. That means 50 parts gasoline to 1 part 2-cycle engine oil. Using the wrong ratio can lead to poor performance, engine damage, and starting problems. I always recommend using Stihl’s own 2-cycle engine oil, but any high-quality, TC-W3 rated oil will work. I usually mix a gallon at a time, and I always shake the container thoroughly to ensure the oil is properly mixed with the gasoline.
- Pro Tip: I mark my fuel can clearly with the date I mixed the fuel. Fuel can degrade over time, especially when mixed with oil. I generally try to use up my mixed fuel within 30 days for optimal performance. According to studies conducted by the American Society for Testing and Materials (ASTM), gasoline can start to degrade and lose octane rating after just a few weeks of storage, especially when exposed to air and sunlight.
Fuel Filter: The fuel filter is located inside the fuel tank, attached to the end of the fuel line. A clogged fuel filter restricts fuel flow, making it difficult for the engine to start.
- Inspection: Remove the fuel cap and use a clean wire or hooked tool to pull the fuel filter out of the tank. Examine it for dirt, debris, or discoloration.
- Cleaning/Replacement: If the filter is only slightly dirty, you can try cleaning it with carburetor cleaner. However, if it’s heavily clogged or damaged, it’s best to replace it. Fuel filters are inexpensive and readily available. I recommend replacing the fuel filter at least once a year, or more often if you’re using your saw frequently in dusty conditions.
- Data Point: A clogged fuel filter can reduce fuel flow by as much as 50%, leading to hard starting and poor engine performance.
Fuel Lines: Inspect the fuel lines for cracks, leaks, or kinks. Over time, fuel lines can become brittle and deteriorate, especially when exposed to ethanol-blended fuels.
- Inspection: Carefully examine the fuel lines from the fuel tank to the carburetor. Look for any signs of damage. Pay close attention to the areas where the fuel lines connect to the carburetor and fuel tank, as these are common points of failure.
- Replacement: If you find any damage, replace the fuel lines immediately. Fuel lines are relatively easy to replace, and it’s a good idea to keep a spare set on hand.
- Pro Tip: When replacing fuel lines, make sure you use fuel lines that are specifically designed for use with gasoline. Using the wrong type of fuel line can lead to premature failure and fuel leaks.
Fuel Tank Vent: The fuel tank vent allows air to enter the fuel tank as fuel is consumed, preventing a vacuum from forming. A clogged fuel tank vent can prevent fuel from flowing properly to the carburetor.
- Inspection: The fuel tank vent is usually located on top of the fuel tank. Remove the vent and inspect it for dirt or debris.
- Cleaning: Clean the vent with carburetor cleaner or compressed air. If the vent is damaged, replace it.
- Case Study: I once spent an entire afternoon trying to diagnose a starting problem on a Stihl MS170, only to discover that the fuel tank vent was completely clogged with sawdust. After cleaning the vent, the saw started right up.

1.2 Ignition System Check

Spark Plug: The spark plug ignites the fuel-air mixture in the cylinder, starting the combustion process. A fouled or damaged spark plug can prevent the engine from starting.
- Removal: Disconnect the spark plug wire and use a spark plug wrench to remove the spark plug.
- Inspection: Examine the spark plug for signs of fouling, such as carbon buildup, oil deposits, or a cracked insulator. Also, check the electrode gap. The correct gap for the Stihl MS170 is typically around 0.5 mm (0.020 inches).
- Cleaning/Replacement: If the spark plug is only slightly fouled, you can try cleaning it with a wire brush. However, if it’s heavily fouled or damaged, it’s best to replace it. I recommend replacing the spark plug at least once a year, or more often if you’re using your saw frequently.
  - Data Point: A fouled spark plug can reduce spark intensity by as much as 70%, leading to hard starting and poor engine performance.
- Testing for Spark: With the spark plug removed, reattach the spark plug wire. Hold the spark plug against the engine block and pull the starter cord. You should see a strong, blue spark jumping across the electrode gap. If you don’t see a spark, or if the spark is weak or intermittent, there may be a problem with the ignition coil or the spark plug wire.
Ignition Coil: The ignition coil generates the high-voltage electricity needed to create a spark at the spark plug. A faulty ignition coil can prevent the engine from starting.
- Testing: Testing the ignition coil requires a multimeter and some technical knowledge. You’ll need to measure the resistance of the primary and secondary windings of the coil. The specific resistance values will vary depending on the model of the ignition coil. Consult the Stihl MS170 service manual for the correct values.
- Pro Tip: If you suspect that the ignition coil is faulty, it’s often easier and more cost-effective to simply replace it. Ignition coils are relatively inexpensive and readily available.
Spark Plug Wire: The spark plug wire connects the ignition coil to the spark plug. A damaged or corroded spark plug wire can prevent the engine from starting.
- Inspection: Inspect the spark plug wire for cracks, cuts, or corrosion. Pay close attention to the areas where the wire connects to the ignition coil and spark plug.
- Replacement: If you find any damage, replace the spark plug wire immediately.

1.3 Air Intake System Check

Air Filter: The air filter prevents dirt and debris from entering the engine. A clogged air filter restricts airflow, leading to poor performance and starting problems.
- Inspection: Remove the air filter cover and inspect the air filter for dirt and debris.
- Cleaning/Replacement: If the air filter is only slightly dirty, you can try cleaning it with compressed air. However, if it’s heavily clogged or damaged, it’s best to replace it. I recommend cleaning the air filter after every use and replacing it at least once a year.
  - Data Point: A clogged air filter can reduce airflow by as much as 80%, leading to hard starting and poor engine performance.
- Pro Tip: I always keep a spare air filter on hand so I can quickly replace a dirty filter in the field.
Intake Manifold: The intake manifold connects the carburetor to the engine. A leak in the intake manifold can cause the engine to run lean, leading to starting problems.
- Inspection: Inspect the intake manifold for cracks or leaks. You can use a spray bottle filled with soapy water to check for leaks. Spray the soapy water around the intake manifold while the engine is running (if possible). If you see bubbles forming, there’s a leak.
- Replacement: If you find any leaks, replace the intake manifold immediately.

2. Carburetor Troubleshooting: The Heart of the Matter

The carburetor is responsible for mixing fuel and air in the correct proportions for combustion. A malfunctioning carburetor is a common cause of starting problems in the Stihl MS170.

2.1 Carburetor Basics

The Stihl MS170 uses a simple, but effective, carburetor. It typically has three adjustment screws:

L (Low-Speed): Adjusts the fuel mixture at idle and low speeds.
H (High-Speed): Adjusts the fuel mixture at high speeds.
LA (Idle Speed): Adjusts the engine’s idle speed.

Important Note: Carburetor adjustments should only be made by someone with experience. Incorrect adjustments can damage the engine. If you’re not comfortable making these adjustments yourself, take your saw to a qualified service technician.

2.2 Initial Carburetor Settings

Before making any adjustments, it’s important to know the factory settings for the carburetor. These settings are a good starting point for troubleshooting.

L (Low-Speed): Typically 1 turn out from fully closed.
H (High-Speed): Typically 1 turn out from fully closed.
LA (Idle Speed): Adjust until the chain stops moving at idle.

Pro Tip: I always write down the factory settings before making any adjustments. This makes it easy to return to the original settings if something goes wrong.

2.3 Troubleshooting Steps

Flooding: If the engine is flooded with fuel, it will be difficult to start. To clear a flooded engine, remove the spark plug, pull the starter cord several times, and then reinstall the spark plug.
Lean Condition: If the engine is running lean (too much air, not enough fuel), it may be difficult to start or may stall easily. Try turning the L (Low-Speed) screw slightly counterclockwise to richen the mixture.
Rich Condition: If the engine is running rich (too much fuel, not enough air), it may be difficult to start or may produce black smoke. Try turning the L (Low-Speed) screw slightly clockwise to lean the mixture.
Carburetor Cleaning: Over time, the carburetor can become clogged with dirt and varnish. This can lead to starting problems and poor performance.
- Disassembly: Carefully disassemble the carburetor, taking note of the location of all the parts.
- Cleaning: Clean all the parts with carburetor cleaner. Pay close attention to the jets and passages.
- Reassembly: Reassemble the carburetor, making sure all the parts are properly installed.
- Pro Tip: I always use a carburetor rebuild kit when cleaning a carburetor. This ensures that I have all the necessary gaskets and seals to properly reassemble the carburetor.
Carburetor Replacement: If the carburetor is severely damaged or clogged, it may be necessary to replace it. Carburetors are relatively inexpensive and readily available.

2.4 Case Study: The Stubborn Stihl

I once worked on a Stihl MS170 that simply refused to start, no matter what I did. I checked the fuel, spark, and air, and everything seemed to be in order. I even cleaned the carburetor, but still no luck. Finally, I decided to replace the carburetor with a new one. To my surprise, the saw started right up. It turned out that the original carburetor had an internal crack that was preventing it from functioning properly. This experience taught me that sometimes, even after careful inspection, the only solution is to replace the carburetor.

3. Compression Test: Is the Engine Healthy?

If you’ve checked the fuel, spark, and air, and the carburetor seems to be in order, the next step is to check the engine’s compression. Low compression can indicate a problem with the piston, rings, or cylinder, which can prevent the engine from starting.

3.1 Performing a Compression Test

You’ll need a compression tester to perform this test.

Preparation: Remove the spark plug and screw the compression tester into the spark plug hole.
Testing: Pull the starter cord several times while observing the compression gauge.
Reading: The compression gauge will indicate the engine’s compression pressure. The Stihl MS170 should have a compression pressure of at least 120 PSI (pounds per square inch).

3.2 Interpreting the Results

Low Compression: If the compression pressure is below 120 PSI, there may be a problem with the piston, rings, or cylinder. This could be due to wear, damage, or carbon buildup.
No Compression: If there is no compression, there is likely a major problem with the engine, such as a cracked piston or cylinder.

3.3 Troubleshooting Low Compression

Carbon Buildup: Carbon buildup on the piston and rings can reduce compression. You can try removing the cylinder head and cleaning the carbon buildup with a wire brush.
Worn Piston Rings: Worn piston rings can allow combustion gases to leak past the piston, reducing compression. Replacing the piston rings can restore compression.
Damaged Piston or Cylinder: A damaged piston or cylinder can cause a major loss of compression. In this case, the engine will need to be rebuilt or replaced.

Pro Tip: Before tearing down the engine, try adding a small amount of oil to the cylinder through the spark plug hole. This can temporarily seal the piston rings and improve compression. If the compression improves significantly after adding oil, it’s likely that the piston rings are worn.

4. Recoil Starter: The Pulling Power

The recoil starter is responsible for turning the engine over when you pull the starter cord. A malfunctioning recoil starter can make it difficult or impossible to start the engine.

4.1 Recoil Starter Components

The recoil starter consists of several components:

Starter Cord: The cord you pull to start the engine.
Recoil Spring: The spring that retracts the starter cord.
Pawls: The small levers that engage the engine flywheel.
Pulley: The pulley that the starter cord wraps around.

4.2 Troubleshooting Steps

Broken Starter Cord: If the starter cord is broken, it will need to be replaced.
Weak Recoil Spring: If the recoil spring is weak, the starter cord will not retract properly. The recoil spring will need to be replaced.
Sticking Pawls: If the pawls are sticking, they may not engage the engine flywheel properly. Clean the pawls with carburetor cleaner and lubricate them with a light oil.
Damaged Pulley: If the pulley is damaged, it may prevent the starter cord from retracting properly. The pulley will need to be replaced.
Binding: Sometimes the recoil starter mechanism can bind due to dirt, debris, or lack of lubrication. Disassemble the recoil starter, clean all the parts, lubricate them with a light grease, and reassemble.

Pro Tip: When replacing the starter cord, use a high-quality cord that is specifically designed for use in recoil starters.

5. Flywheel and Key: Timing is Everything

The flywheel is a heavy metal disc that is attached to the crankshaft. It helps to smooth out the engine’s power delivery and also provides a place for the ignition system to generate a spark. The flywheel key is a small piece of metal that keys the flywheel to the crankshaft, ensuring that the flywheel is properly timed with the engine.

5.1 Troubleshooting Steps

Sheared Flywheel Key: If the flywheel key is sheared, the flywheel will be out of time with the engine, preventing it from starting. To check the flywheel key, remove the flywheel and inspect the keyway in the flywheel and crankshaft. If the key is sheared, it will need to be replaced.
Loose Flywheel: If the flywheel is loose, it can also cause timing problems. Make sure the flywheel is properly tightened to the crankshaft.
Damaged Flywheel: A damaged flywheel can also cause starting problems. Inspect the flywheel for cracks or other damage. If the flywheel is damaged, it will need to be replaced.

Pro Tip: When installing a new flywheel key, make sure it is properly seated in the keyway.

6. Exhaust System: Is it Breathing Properly?

The exhaust system is responsible for removing exhaust gases from the engine. A clogged exhaust system can restrict airflow, leading to poor performance and starting problems.

6.1 Troubleshooting Steps

Spark Arrestor: The spark arrestor is a small screen that prevents sparks from escaping the exhaust system. Over time, the spark arrestor can become clogged with carbon buildup. Remove the spark arrestor and clean it with a wire brush.
Exhaust Port: The exhaust port is the opening in the cylinder that connects to the exhaust system. Over time, the exhaust port can become clogged with carbon buildup. Remove the exhaust system and clean the exhaust port with a scraper or wire brush.
Muffler: The muffler is the part of the exhaust system that reduces noise. A clogged muffler can restrict airflow. Remove the muffler and inspect it for obstructions. If the muffler is clogged, it will need to be replaced.
- Data Point: A clogged exhaust system can reduce engine power by as much as 20%.

Pro Tip: When cleaning the exhaust port, be careful not to damage the cylinder walls.

7. Safety First: A Word of Caution

Working with chainsaws can be dangerous. Always follow these safety precautions:

Wear appropriate safety gear: This includes safety glasses, hearing protection, gloves, and sturdy boots.
Read the owner’s manual: Familiarize yourself with the chainsaw’s operation and safety features.
Work in a well-ventilated area: Chainsaw exhaust contains carbon monoxide, which is a deadly gas.
Be aware of your surroundings: Watch out for obstacles, such as rocks, roots, and branches.
Never operate a chainsaw when you are tired or under the influence of drugs or alcohol.
Always disconnect the spark plug wire before performing any maintenance or repairs.
Use caution when working with fuel: Fuel is flammable and can be dangerous.
- Safety Code: OSHA (Occupational Safety and Health Administration) regulations require that fuel be stored in approved containers and that smoking be prohibited within 25 feet of fueling operations.

8. Preventative Maintenance: Keeping Your MS170 Running Smoothly

Preventative maintenance is the key to keeping your Stihl MS170 running smoothly and avoiding starting problems.

Clean the air filter regularly: Clean the air filter after every use.
Replace the fuel filter annually: Replace the fuel filter at least once a year.
Replace the spark plug annually: Replace the spark plug at least once a year.
Clean the carburetor periodically: Clean the carburetor every few years, or more often if you’re using your saw frequently.
Inspect the fuel lines regularly: Inspect the fuel lines for cracks or leaks.
Sharpen the chain regularly: A sharp chain will cut more efficiently and reduce strain on the engine.
- Data Point: A sharp chain can increase cutting speed by as much as 50%.
Store the chainsaw properly: Store the chainsaw in a dry place, away from direct sunlight and extreme temperatures.
Use fresh fuel: Use fresh fuel that is no more than 30 days old.
Follow the manufacturer’s recommendations: Follow the manufacturer’s recommendations for maintenance and lubrication.

Pro Tip: I always keep a log of all the maintenance I perform on my chainsaw. This helps me to keep track of when I need to perform certain tasks.

9. Wood Selection Criteria: Fuelwood Considerations

While this guide focuses on chainsaw troubleshooting, it’s worth touching on wood selection for firewood. The type of wood you burn can significantly impact the efficiency and cleanliness of your wood-burning appliance.

Hardwoods vs. Softwoods: Hardwoods like oak, maple, and ash are denser than softwoods like pine and fir. This means they contain more energy per unit volume and burn longer. Softwoods, on the other hand, tend to burn hotter and faster, but they also produce more smoke and creosote.
- Data Point: Oak has approximately 20% more energy content per cord than pine.
Moisture Content: The moisture content of firewood is critical. Burning wet wood is inefficient, produces excessive smoke and creosote, and can damage your chimney.
- Technical Limitation: Firewood should have a moisture content of 20% or less for optimal burning.
Seasoning: Seasoning is the process of drying firewood. To season firewood properly, split it, stack it loosely in a sunny, windy location, and allow it to dry for at least six months, or preferably a year.
- Practical Tip: Use a moisture meter to check the moisture content of your firewood before burning it.
Wood Identification: Learn to identify different types of wood. This will help you choose the best firewood for your needs.
- Visual Example: Consult a field guide or online resource for images of different types of wood.

10. Log Dimensions and Cord Volumes: Quantifying Your Firewood

Understanding log dimensions and cord volumes is essential for efficient firewood processing and sales.

Log Diameter: The diameter of logs will influence the ease of splitting and the size of firewood pieces.
- Precise Measurement: Aim for log diameters that are manageable for your splitting equipment and personal strength. Typically, logs with diameters between 6 and 12 inches are ideal for splitting by hand.
Firewood Length: Firewood should be cut to a length that is appropriate for your wood-burning appliance.
- Technical Requirement: Measure the firebox of your stove or fireplace to determine the maximum firewood length. A common firewood length is 16 inches.
Cord Volume: A cord is a standard unit of measurement for firewood. A full cord is 4 feet high, 4 feet wide, and 8 feet long, for a total volume of 128 cubic feet.
- Practical Tip: Use a firewood calculator or chart to estimate the volume of firewood in different stack configurations.
Face Cord: A face cord (also known as a rick or stove cord) is a stack of firewood that is 4 feet high and 8 feet long, but the width varies.
- Important Limitation: Be aware that a face cord is not a standardized unit of measurement, so the volume can vary depending on the width of the stack.

11. Tool Calibration Standards: Ensuring Accuracy and Safety

Maintaining your chainsaw and other wood processing tools to proper calibration standards is crucial for safety and efficiency.

Chainsaw Chain Tension: Proper chain tension is essential for safe and efficient cutting.
- Calibration Standard: The chain should be snug against the guide bar but should be able to be pulled away slightly (about 1/8 inch) at the midpoint of the bar.
Chainsaw Carburetor Adjustment: As mentioned earlier, proper carburetor adjustment is critical for engine performance.
- Technical Requirement: Use a tachometer to ensure that the engine is running at the correct RPM (revolutions per minute). Consult the Stihl MS170 service manual for the correct RPM specifications.
Moisture Meter Calibration: If you’re using a moisture meter to check the moisture content of firewood, make sure it’s properly calibrated.
- Best Practice: Follow the manufacturer’s instructions for calibrating your moisture meter.
Splitting Maul Weight and Balance: If you’re splitting wood by hand, choose a splitting maul with the appropriate weight and balance for your strength and experience.
- Practical Example: A heavier maul (6-8 lbs) is generally more effective for splitting larger logs, while a lighter maul (4-6 lbs) is easier to handle for smaller logs and less experienced users.
Axes & Sharpness: Keeping axes sharp is one of the most important requirements. Dull axes can increase the chances of accidents.
- Safety Equipment: Always wear cut-resistant gloves and proper foot protection when using axes.

12. Original Research and Case Studies: Real-World Insights

Over the years, I’ve conducted some informal research on firewood drying times and BTU (British Thermal Unit) output based on different wood species in my local area. While not scientifically rigorous, these observations have provided valuable insights.

Firewood Drying Time: I found that oak, when properly split and stacked, typically takes 12-18 months to reach a moisture content of 20% or less in my climate (Pacific Northwest). Maple, on the other hand, dries slightly faster, typically in 9-12 months.
BTU Output: I also compared the BTU output of different wood species using a simple, non-scientific method. I burned equal volumes of different wood species in my wood stove and measured the temperature output. I found that oak consistently produced the highest temperature, followed by maple, and then fir.

Case Study: The Wet Wood Dilemma

I once had a client who insisted on burning freshly cut wood in their wood stove. Despite my warnings about the dangers of burning wet wood, they proceeded to do so. Within a few weeks, their chimney was completely clogged with creosote, and they had to hire a professional chimney sweep to clean it. This experience reinforced the importance of burning properly seasoned firewood.

13. Resources and Further Reading

Stihl MS170 Owner’s Manual: This is the most important resource for your chainsaw. It contains detailed information on operation, maintenance, and safety.
Stihl Website: The Stihl website has a wealth of information on their products, including troubleshooting guides and parts diagrams.
Forestry Extension Services: Your local forestry extension service can provide valuable information on wood selection, firewood processing, and forest management.
Online Forums: There are many online forums dedicated to chainsaws and wood processing. These forums can be a great place to ask questions and get advice from other users.

Conclusion: Empowering You for Success

Troubleshooting a Stihl MS170 starting problem can seem daunting, but with a systematic approach and a little patience, you can often diagnose and solve the issue yourself. Remember to start with the basics – fuel, spark, and air – and then move on to more complex issues like the carburetor and compression. Always prioritize safety and follow the manufacturer’s recommendations.
