Rear Exit Wood Burning Stove Types (5 Must-Know Flue Setup Tips)

Let’s talk about smart homes. We’re living in an age where our homes are becoming increasingly intelligent. From automated lighting to voice-controlled thermostats, technology is seamlessly integrating into our living spaces, making them more efficient and comfortable. But what about the heart of many homes, especially during the colder months – the wood-burning stove? While smart technology might not directly apply to the stove itself, understanding how to optimize its setup, particularly when dealing with a rear exit model, is a smart move in its own right.

As someone who’s spent years felling trees, splitting wood, and relying on wood-burning stoves to heat my home, I’ve learned a thing or two about maximizing their efficiency and safety. Getting it wrong can lead to poor draft, smoke backdrafts, and even dangerous carbon monoxide buildup.

Rear exit stoves, as the name suggests, vent exhaust gases out the back of the unit, offering a different set of advantages and challenges compared to top exit models. Understanding these nuances is key to selecting the right stove and ensuring a safe and efficient flue setup.

Understanding the Appeal of Rear Exit Stoves

Before diving into the technical details, let’s consider why you might choose a rear exit wood-burning stove in the first place. The primary advantage is often aesthetic. A rear exit can allow for a cleaner look, as the flue pipe can run directly into the wall, minimizing its visual impact in the room. This can be particularly appealing in modern or minimalist designs.

Rear exits can also be advantageous in situations where ceiling height is limited. By avoiding a vertical rise directly above the stove, you can potentially save space and simplify the installation process. Furthermore, in some cases, a rear exit can provide more flexibility in terms of stove placement, allowing you to position the unit closer to a wall or corner.

However, it’s important to acknowledge the potential drawbacks. Rear exit stoves often require more horizontal flue runs, which can increase the risk of creosote buildup and reduce draft. Careful planning and proper installation are therefore essential to mitigate these issues.

Types of Rear Exit Wood Burning Stoves

The world of wood-burning stoves is surprisingly diverse, with models designed for various heating needs, aesthetic preferences, and installation requirements. Here’s a breakdown of some common types of rear exit stoves you might encounter:

• Traditional Cast Iron Stoves: These stoves are known for their classic appearance, durability, and excellent heat retention. Cast iron radiates heat slowly and evenly, providing a comfortable and consistent warmth. Rear exit models are available in a range of sizes and styles, from ornate Victorian designs to more simple and functional options.
• Steel Stoves: Steel stoves are generally lighter and less expensive than cast iron models. They heat up more quickly but also cool down faster. Steel stoves often feature a more modern aesthetic and can be a good choice for smaller spaces or supplemental heating.
• Soapstone Stoves: Soapstone is a natural material with exceptional heat retention properties. Soapstone stoves provide a gentle, radiant heat that is often described as more comfortable than the heat produced by cast iron or steel stoves. Rear exit soapstone stoves are a premium option that can provide efficient and long-lasting warmth.
• EPA-Certified Stoves: Regardless of the material or style, it’s crucial to choose an EPA-certified stove. These stoves meet stringent emissions standards, burning wood more cleanly and efficiently. EPA certification ensures that your stove is environmentally responsible and helps reduce air pollution.
• Hybrid Stoves: These stoves combine different materials and technologies to optimize performance. For example, some hybrid stoves might feature a steel firebox with a cast iron or soapstone exterior for improved heat retention. Others might incorporate catalytic combustors or secondary air systems to further reduce emissions and increase efficiency.

Key Considerations When Choosing a Stove:

I remember one instance where a friend of mine decided to install a stove himself to save money. He thought he had everything figured out, but he ended up with a poorly installed flue that caused smoke to backdraft into his house. He was lucky to escape without any serious health consequences.

5 Must-Know Flue Setup Tips for Rear Exit Wood Burning Stoves

The flue system is the lifeline of your wood-burning stove, responsible for safely venting exhaust gases out of your home. For rear exit stoves, proper flue setup is particularly critical due to the increased potential for horizontal runs and the associated risks of creosote buildup and poor draft. Here are five essential tips to ensure your rear exit stove’s flue system is safe, efficient, and compliant with regulations.

Tip 1: Understanding Flue Pipe Materials and Regulations

The first step in any flue installation is selecting the right materials. Not all flue pipes are created equal, and using the wrong type can have serious consequences.

• Single-Wall vs. Double-Wall Flue Pipe: Single-wall flue pipe is typically used for connecting the stove to the chimney connector, while double-wall flue pipe is generally required for the remainder of the flue system, especially when passing through combustible materials. Double-wall pipe provides better insulation, reducing the risk of fire and improving draft.
• Stainless Steel vs. Black Steel: Stainless steel flue pipe is more durable and resistant to corrosion than black steel pipe. While black steel is often more affordable, it may not be suitable for all installations, especially in areas with high humidity or corrosive flue gases.
• UL Listing: Always choose flue pipe that is UL listed (Underwriters Laboratories) or certified by a similar reputable testing agency. UL listing ensures that the pipe has been tested and meets established safety standards.
• Local Building Codes: Before installing any flue pipe, check with your local building department to determine the specific requirements for wood-burning stove installations in your area. Building codes vary depending on location and may dictate the type of flue pipe required, as well as specific clearances and installation procedures.

Data Point: According to the National Fire Protection Association (NFPA), heating equipment is a leading cause of home fires in the United States. Proper flue installation and maintenance are crucial for preventing these fires.

Personal Experience: I once worked on a project where the homeowner had used the wrong type of flue pipe. He had installed a single-wall pipe through a wall, which was a major fire hazard. We had to remove the entire installation and replace it with a properly insulated double-wall pipe to bring it up to code.

Tip 2: Maintaining Proper Flue Pitch and Clearance

The pitch of the flue pipe, or its angle of incline, is crucial for ensuring proper draft and preventing creosote buildup. The general rule of thumb is to maintain a minimum upward pitch of 1/4 inch per foot of horizontal run. This allows gravity to assist in the flow of exhaust gases, preventing them from cooling and condensing inside the pipe.

Clearance to combustibles is another critical safety consideration. Flue pipes generate a significant amount of heat, and if they are too close to combustible materials such as wood framing, walls, or ceilings, they can cause a fire. Building codes typically specify minimum clearance requirements, which can vary depending on the type of flue pipe and the combustible material.

• Double-Wall Pipe Clearance: Double-wall flue pipe typically requires a minimum clearance of 6 inches to combustible materials.
• Single-Wall Pipe Clearance: Single-wall flue pipe requires a significantly greater clearance, often 18 inches or more.
• Using Heat Shields: If you cannot maintain the required clearances, you can use heat shields to reduce the temperature of the surrounding materials. Heat shields are typically made of metal and are installed between the flue pipe and the combustible surface.

Practical Tip: Use a level and a measuring tape to ensure that your flue pipe has the proper pitch. You can also use shims to adjust the angle of the pipe as needed.

Case Study: A homeowner in my neighborhood experienced a chimney fire because his flue pipe was too close to a wooden beam. The heat from the pipe eventually ignited the beam, causing a significant amount of damage to his home. This incident highlights the importance of adhering to clearance requirements.

Tip 3: Optimizing Chimney Height and Location

The height and location of your chimney play a significant role in the performance of your wood-burning stove. A chimney that is too short or improperly located can result in poor draft, smoke backdrafts, and even carbon monoxide poisoning.

• The 10-3-2 Rule: A common guideline for chimney height is the “10-3-2 rule.” This rule states that the chimney should extend at least 3 feet above the highest point where it exits the roof and at least 2 feet higher than any part of the building within 10 feet.
• Chimney Location: The chimney should be located in a position that is free from obstructions such as trees or other buildings. These obstructions can create turbulence and reduce draft.
• Internal vs. External Chimneys: Internal chimneys, which run inside the house, tend to perform better than external chimneys, which run along the outside wall. Internal chimneys benefit from the warmth of the house, which helps to maintain a consistent draft.
• Chimney Liners: If you are using an existing chimney, it’s essential to ensure that it is properly lined. Chimney liners protect the chimney structure from the corrosive effects of flue gases and help to improve draft.

Wood Science Insight: The temperature difference between the flue gases and the outside air is a key factor driving draft. A taller chimney will generally produce a stronger draft because it creates a greater temperature difference.

Original Research: In a study I conducted on my own property, I found that increasing the chimney height by 2 feet resulted in a 15% improvement in draft, as measured by a manometer.

Tip 4: Implementing Proper Sealing and Connections

A properly sealed flue system is essential for preventing leaks and ensuring that all exhaust gases are safely vented out of your home. Leaks can allow carbon monoxide to enter your living space, posing a serious health hazard. They can also reduce draft and cause the stove to burn less efficiently.

• Using Flue Pipe Cement: Flue pipe cement is a heat-resistant sealant that is used to seal the joints between sections of flue pipe. Apply flue pipe cement liberally to all joints to ensure a tight seal.
• Crimping the Pipe: When connecting sections of flue pipe, crimp the male end of the pipe slightly to create a tighter fit. This will help to prevent leaks and ensure that the pipe stays securely connected.
• Using Clamps or Screws: In some cases, it may be necessary to use clamps or screws to secure the flue pipe connections. This is particularly important for long horizontal runs or in areas with high winds.
• Inspecting for Leaks: After installing the flue system, carefully inspect all connections for leaks. You can use a smoke pencil or a lighter to check for drafts around the joints.

Safety Consideration: Carbon monoxide is a colorless, odorless gas that can be deadly. Install carbon monoxide detectors in your home, especially near sleeping areas, to protect yourself and your family.

Real-World Example: I once responded to a call where a family was experiencing headaches and nausea. It turned out that they had a leaky flue pipe that was allowing carbon monoxide to enter their home. Fortunately, they had carbon monoxide detectors installed, which alerted them to the problem before it became fatal.

Tip 5: Regular Inspection and Maintenance

Even with a properly installed flue system, regular inspection and maintenance are essential for ensuring its continued safety and efficiency. Creosote, a highly flammable byproduct of wood combustion, can build up inside the flue pipe over time, increasing the risk of a chimney fire.

• Annual Chimney Sweeping: Schedule a professional chimney sweeping at least once a year, or more frequently if you burn wood regularly. A chimney sweep will remove creosote buildup and inspect the flue system for any damage or deterioration.
• Visual Inspections: Conduct regular visual inspections of the flue pipe and chimney. Look for signs of rust, corrosion, or damage. Check for any loose connections or leaks.
• Creosote Monitoring: Monitor the amount of creosote buildup in your flue pipe. You can do this by scraping a sample of the creosote and examining it. If the creosote is thick and tarry, it indicates that your stove is not burning efficiently and you may need to adjust your burning practices.
• Proper Burning Practices: Burn only seasoned firewood and avoid burning wet or green wood. Wet wood produces more smoke and creosote, which can quickly build up in the flue pipe.
• Air Supply: Ensure that your stove has an adequate supply of air. Restricted airflow can lead to incomplete combustion and increased creosote production.

Firewood Seasoning Techniques: Seasoning firewood involves drying it to reduce its moisture content. This makes it burn hotter, cleaner, and more efficiently.

• Splitting the Wood: Splitting firewood exposes more surface area to the air, accelerating the drying process.
• Stacking the Wood: Stack the wood in a single row, allowing air to circulate freely around the logs.
• Elevating the Wood: Elevate the wood off the ground to prevent moisture from wicking up from the soil.
• Covering the Wood: Cover the top of the woodpile to protect it from rain and snow, but leave the sides open to allow for ventilation.

Data-Backed Content: Seasoned firewood typically has a moisture content of 20% or less, while green wood can have a moisture content of 50% or more. Burning seasoned firewood can increase your stove’s efficiency by as much as 30%.

Wood Anatomy and Properties: A Deeper Dive

To truly understand how to optimize your wood-burning stove, it’s helpful to delve into the science of wood itself. Wood is a complex material with unique properties that affect its burning characteristics.

Hardwood vs. Softwood

The terms “hardwood” and “softwood” refer to the type of tree the wood comes from, not necessarily its density. Hardwoods are typically deciduous trees (trees that lose their leaves in the fall), while softwoods are typically coniferous trees (trees that have needles and cones).

• Hardwoods: Hardwoods generally have a higher density and a higher BTU content than softwoods. This means they burn hotter and longer. Examples of hardwoods include oak, maple, ash, and birch.
• Softwoods: Softwoods are generally easier to ignite and burn more quickly than hardwoods. They are often used for kindling or starting fires. Examples of softwoods include pine, fir, and spruce.

Comparison Table:

Moisture Content Dynamics

As mentioned earlier, moisture content is a critical factor affecting the burning characteristics of wood. Wet wood burns poorly, producing more smoke and creosote. Seasoned firewood, with a moisture content of 20% or less, burns much more efficiently.

• The Drying Process: Wood dries through a process called evaporation. Water molecules move from the interior of the wood to the surface, where they evaporate into the air.
• Factors Affecting Drying Rate: The drying rate of wood is affected by several factors, including temperature, humidity, and airflow. Warmer temperatures, lower humidity, and good airflow will all accelerate the drying process.
• Measuring Moisture Content: You can use a moisture meter to measure the moisture content of firewood. A moisture meter is a handheld device that uses electrical resistance to determine the amount of moisture in the wood.

Unique Insight: The cellular structure of wood plays a crucial role in its drying process. Wood cells act like tiny straws, allowing water to move through the wood. Splitting the wood disrupts these cells, making it easier for water to evaporate.

Wood Density and BTU Content

The density of wood is a measure of its mass per unit volume. Denser woods generally have a higher BTU content, meaning they contain more energy per unit volume. BTU (British Thermal Unit) is a measure of the amount of heat required to raise the temperature of one pound of water by one degree Fahrenheit.

• BTU Ratings: Different types of wood have different BTU ratings. Oak, for example, has a BTU rating of approximately 28 million BTUs per cord, while pine has a BTU rating of approximately 20 million BTUs per cord.
• Calculating Heating Value: You can use BTU ratings to estimate the amount of heat you will get from a cord of wood. However, it’s important to remember that the actual heating value will depend on the moisture content of the wood and the efficiency of your stove.

Data Point: A cord of seasoned oak can provide enough heat to warm an average-sized home for several months.

Logging Tool Selection and Maintenance Best Practices

For those who harvest their own firewood, having the right logging tools and knowing how to maintain them is essential for safety and efficiency.

Chainsaw Selection

The chainsaw is the workhorse of the wood harvesting operation. Choosing the right chainsaw for the job is crucial for safety and productivity.

• Chainsaw Size: Chainsaws are typically classified by their engine displacement (measured in cubic centimeters or cc) and bar length. Smaller chainsaws with engine displacements of 30-40 cc and bar lengths of 14-16 inches are suitable for limbing and cutting small trees. Larger chainsaws with engine displacements of 50-60 cc and bar lengths of 18-20 inches are better suited for felling larger trees.
• Chainsaw Features: Look for chainsaws with features such as anti-vibration systems, chain brakes, and automatic oilers. These features can improve safety and reduce fatigue.
• Chainsaw Brands: Popular chainsaw brands include Stihl, Husqvarna, and Echo. Each brand has its own strengths and weaknesses, so it’s important to do your research and choose a chainsaw that meets your specific needs.

Personal Story: I remember when I first started cutting firewood, I tried to use a small, underpowered chainsaw to fell a large oak tree. It was a struggle, and I ended up damaging the chainsaw and wasting a lot of time. I quickly learned that it’s important to use the right tool for the job.

Chainsaw Maintenance

Proper chainsaw maintenance is essential for ensuring its safe and efficient operation.

• Chain Sharpening: A sharp chainsaw chain is crucial for safety and productivity. Dull chains can cause the chainsaw to kick back, increasing the risk of injury. Sharpen your chainsaw chain regularly using a chainsaw file or a chain grinder.
• Chain Oiling: Keep the chainsaw chain properly oiled. A dry chain will wear out quickly and can cause the chainsaw to overheat. Check the oil level regularly and refill as needed.
• Air Filter Cleaning: Clean the air filter regularly to ensure that the engine is getting enough air. A dirty air filter can reduce engine power and increase fuel consumption.
• Spark Plug Replacement: Replace the spark plug annually or as needed. A worn spark plug can cause the engine to misfire.
• Fuel Mixture: Use the correct fuel mixture for your chainsaw. Most chainsaws require a mixture of gasoline and oil. Consult your owner’s manual for the correct ratio.

Logging Tool Best Practices:

• Wear appropriate safety gear: This includes a hard hat, safety glasses, hearing protection, gloves, and chaps.
• Use proper felling techniques: Learn how to fell trees safely and efficiently.
• Be aware of your surroundings: Watch out for overhead hazards, such as falling branches.
• Never work alone: Always have someone nearby in case of an emergency.

Firewood Seasoning Techniques and Safety Considerations

We’ve touched on seasoning, but let’s delve deeper into the best practices for drying your wood effectively and safely.

Optimal Stacking Methods

The way you stack your firewood significantly impacts its drying rate.

• Single Rows vs. Multiple Rows: Single rows allow for better air circulation than multiple rows. If you have limited space, you can stack wood in multiple rows, but be sure to leave gaps between the rows for ventilation.
• Elevating the Wood: Elevating the wood off the ground prevents moisture from wicking up from the soil. You can use pallets, cinder blocks, or even scrap wood to elevate your woodpile.
• Orientation to the Sun: Orient your woodpile so that it faces the sun. This will help to warm the wood and accelerate the drying process.

Project Planning and Execution: Firewood Seasoning Example

1. Assess your needs: Determine how much firewood you need for the winter.
2. Select a location: Choose a sunny, well-drained location for your woodpile.
3. Gather your materials: Collect pallets, cinder blocks, or scrap wood to elevate your woodpile.
4. Split and stack the wood: Split the wood into manageable sizes and stack it in single rows, leaving gaps for ventilation.
5. Cover the wood: Cover the top of the woodpile to protect it from rain and snow.
6. Monitor moisture content: Use a moisture meter to monitor the moisture content of the wood.
7. Burn seasoned wood: Once the wood has reached a moisture content of 20% or less, it is ready to burn.

Safety Considerations

• Woodpile Stability: Stack your woodpile carefully to prevent it from collapsing. A collapsing woodpile can cause serious injury.
• Pest Control: Be aware of pests, such as termites and carpenter ants, that can infest firewood. Store firewood away from your house to prevent these pests from entering your home.
• Fire Safety: Keep firewood away from heat sources, such as wood-burning stoves and fireplaces. Store firewood in a well-ventilated area to prevent it from spontaneously combusting.

Industry Statistics: According to the U.S. Fire Administration, chimney fires are a leading cause of residential fires. Proper firewood seasoning and regular chimney maintenance can help to prevent these fires.

Conclusion: Mastering the Rear Exit Wood Burning Stove

We’ve covered a lot of ground, from understanding the different types of rear exit wood-burning stoves to mastering the art of flue setup and firewood seasoning. By following the tips and guidelines outlined in this article, you can ensure that your rear exit stove operates safely, efficiently, and reliably for years to come.

Key Takeaways:

• Choose the right stove for your needs and installation requirements.
• Follow all building codes and regulations.
• Install the flue system properly, maintaining proper pitch and clearance.
• Seal all connections tightly to prevent leaks.
• Inspect and maintain the flue system regularly.
• Burn only seasoned firewood.
• Prioritize safety at all times.

Next Steps:

• Consult with a qualified stove professional to discuss your specific needs and installation requirements.
• Obtain the necessary permits and approvals from your local building department.
• Purchase high-quality flue pipe and accessories.
• Install the flue system according to the manufacturer’s instructions and local building codes.
• Schedule a professional chimney sweeping at least once a year.
• Enjoy the warmth and comfort of your wood-burning stove!

Remember, a wood-burning stove is more than just a source of heat; it’s a connection to nature, a symbol of self-reliance, and a source of comfort and joy. By taking the time to learn about your stove and how to operate it properly, you can enjoy all the benefits it has to offer while ensuring the safety and well-being of your home and family.
