Purlin Size Guide: 5 Key Wood Specs You Didn’t Know

I’ve spent years working with wood, from felling trees in the crisp autumn air to building my own off-grid cabin. I’ve learned firsthand the importance of understanding wood properties and making informed decisions. Believe me, nothing is more disheartening than seeing a roof sag because of undersized purlins. This guide is designed to prevent that from happening to you. I’ll share my knowledge, experiences, and some hard-won lessons to help you confidently select the right purlin size for your project.

Understanding the Importance of Purlin Size

Before diving into the specifics, let’s solidify why purlin size matters so much. Purlins act as the backbone of your roof. They bridge the gap between rafters (or trusses) and provide a surface to attach the roofing material. If your purlins are too small, they will deflect excessively under load, potentially leading to roof sagging, leaks, and even structural failure. Conversely, using unnecessarily large purlins increases material costs and adds unnecessary weight to the roof structure. Finding the sweet spot – the optimal size that provides adequate strength without being wasteful – is the goal.

Current Market Trends and Cost Considerations

The global wood market is dynamic. According to a report by Grand View Research, the global lumber market size was valued at USD 529.03 billion in 2022 and is expected to grow at a compound annual growth rate (CAGR) of 4.6% from 2023 to 2030. This growth is fueled by increased construction activity and a growing demand for sustainable building materials.

However, lumber prices can fluctuate significantly due to factors like supply chain disruptions, tariffs, and seasonal demand. This makes accurate planning and cost estimation even more crucial. When calculating purlin costs, consider not only the price per board foot but also the cost of fasteners, preservatives, and any specialized tools required for installation.

Key Wood Specs: Unveiling the Hidden Factors

Now, let’s get to the heart of the matter: the five key wood specs that often get overlooked when sizing purlins.

1. Wood Species and Bending Strength (Fb)

This is arguably the most critical factor. Different wood species have vastly different bending strengths (Fb), which represents the wood’s ability to resist bending stress. Using the wrong species can have disastrous consequences.

Why it matters: Fb is a direct measure of how much load a purlin can handle before it starts to bend and potentially fail.
The Data: Softwoods like Spruce, Pine, and Fir (SPF) are commonly used in construction, but their Fb values are lower than hardwoods like Oak or Maple. For example, the design bending strength (Fb) for No. 2 Grade Southern Yellow Pine can be around 850 psi, while for No. 2 Grade Red Oak, it can be closer to 1200 psi. That’s a significant difference!
My Experience: I once worked on a barn renovation where the original purlins were made of a low-grade pine. Over time, they had sagged considerably under the weight of snow and roofing materials. We replaced them with Douglas Fir, a stronger softwood, and the difference was immediately noticeable.
Actionable Tip: Consult a lumber grading guide or the American Wood Council’s National Design Specification (NDS) for Wood Construction to determine the Fb value of the wood species you’re considering. Don’t guess!
Case Study: A small workshop in rural Vermont decided to build a storage shed using locally sourced Eastern White Pine for the purlins. They initially planned to space the purlins 4 feet apart. However, after consulting the NDS and realizing the relatively low Fb value of Eastern White Pine, they reduced the spacing to 2 feet to compensate for the lower strength. This simple adjustment significantly improved the roof’s structural integrity.

2. Moisture Content and its Impact on Strength

Wood is hygroscopic, meaning it absorbs and releases moisture from the surrounding environment. This moisture content (MC) significantly affects its strength and stiffness.

Why it matters: As wood dries, it shrinks and becomes stronger (up to a certain point). Conversely, when wood is wet, it swells and loses strength. Using green (unseasoned) wood for purlins is a recipe for disaster.
The Data: The NDS provides adjustment factors to account for moisture content. For example, the bending strength (Fb) of lumber used in wet service conditions (MC > 19%) can be reduced by as much as 25%.
My Experience: I once made the mistake of using partially dried lumber for a small shed roof. Over the following months, as the wood continued to dry and shrink, the purlins twisted and warped, causing the roofing to buckle. I learned my lesson the hard way!
Actionable Tip: Always use seasoned lumber for purlins. Aim for a moisture content between 12% and 19% for most applications. Use a moisture meter to verify the MC before installation.
Case Study: A firewood producer in Maine decided to build a large wood storage shed. They used green lumber for the purlins to save on costs. Within a year, the roof started to sag significantly, and they had to reinforce it with additional supports. The cost of the extra materials and labor far outweighed the initial savings from using green lumber.

3. Load Duration Factor (Cd)

This is a factor that accounts for the duration of the load applied to the purlin. Wood can withstand higher loads for short periods than it can for long periods.

Why it matters: The load duration factor (Cd) recognizes that wood can handle short-term loads better than long-term loads. For example, a heavy snow load that lasts only a few days is different from the constant weight of the roofing material.
The Data: The NDS assigns different Cd values based on the duration of the load. For normal duration loads (e.g., the weight of the roofing), Cd = 1.0. For short-term loads like snow, Cd can be as high as 1.15 or 1.25, depending on the region and snow load calculations.
My Experience: Living in a snowy region, I always over-engineer my roofs to account for heavy snow loads. I use a higher Cd value in my calculations to ensure the purlins can handle even the heaviest snowfalls.
Actionable Tip: Determine the appropriate Cd value for your location based on local building codes and weather patterns. Consult with a structural engineer if you’re unsure.
Case Study: A group of volunteers in the Rocky Mountains built a community greenhouse. They initially used a Cd value of 1.0 in their purlin size calculations. However, after consulting with a local engineer, they realized that the area was prone to exceptionally heavy snowfalls. They increased the Cd value to 1.15, which resulted in slightly larger purlin sizes but provided a much greater margin of safety.

4. Size Factor (Cf) and Flat Use Factor (Cfu)

These factors account for the size and orientation of the purlin. Wider and thicker purlins are generally stronger than narrower and thinner ones. Also, purlins loaded on their narrow face are weaker than those loaded on their wide face.

Why it matters: The size factor (Cf) adjusts the bending strength (Fb) based on the dimensions of the lumber. The flat use factor (Cfu) accounts for the reduced strength when a purlin is loaded on its narrow face.
The Data: The NDS provides tables of Cf values for different lumber sizes. Generally, as the dimensions of the lumber increase, the Cf value decreases. The Cfu value is typically less than 1.0, indicating a reduction in strength when the purlin is used “flat.”
My Experience: I’ve seen builders mistakenly use 2x4s as purlins on their narrow face, thinking they were saving money. This is a dangerous practice. Always use the correct orientation to maximize the strength of the purlin.
Actionable Tip: Consult the NDS to determine the appropriate Cf and Cfu values for your purlin size and orientation.
Case Study: A builder in Oregon was constructing a carport. He initially planned to use 2×6 lumber as purlins, loaded on their narrow face. After consulting the NDS and realizing the significant reduction in strength due to the flat use factor, he switched to 2×8 lumber, loaded on its wide face. This resulted in a much stronger and safer roof structure.

5. Deflection Limits

While a purlin might be strong enough to support the load without breaking, it can still deflect (bend) excessively. Excessive deflection can damage the roofing material, cause leaks, and create an unsightly appearance.

Why it matters: Deflection is the amount a purlin bends under load. Building codes typically specify maximum allowable deflection limits to prevent damage to the roofing and maintain structural integrity.
The Data: Common deflection limits are L/180 or L/240, where L is the span (distance between supports). For example, if a purlin spans 10 feet (120 inches), the maximum allowable deflection might be 120/240 = 0.5 inches.
My Experience: I’ve seen roofs where the purlins deflected so much that water pooled in the low spots, eventually leading to leaks and rot. Proper purlin sizing is essential to prevent this.
Actionable Tip: Determine the allowable deflection limit based on local building codes and the type of roofing material you’re using. Calculate the expected deflection using engineering formulas and adjust the purlin size as needed.
Case Study: A homeowner in Canada was building a shed with a metal roof. He initially sized the purlins based solely on strength requirements. However, after installing the metal roofing, he noticed significant deflection under the weight of snow. He had to add additional purlins to reduce the span and bring the deflection within acceptable limits.

A Step-by-Step Guide to Purlin Sizing

Now that we’ve covered the key wood specs, let’s walk through a step-by-step guide to purlin sizing. This is a simplified approach, and for complex projects, I highly recommend consulting with a structural engineer.

Step 1: Determine the Roof Load

The roof load consists of dead load (the weight of the roofing material, purlins, and other permanent components) and live load (temporary loads like snow, wind, or people).

Dead Load: Research the weight of your roofing material per square foot. Add an estimate for the weight of the purlins themselves (this can be refined later).
Live Load: Consult local building codes for the required snow load and wind load in your area. These values are typically expressed in pounds per square foot (psf).

Step 2: Calculate the Load on Each Purlin

Multiply the total roof load (dead load + live load) by the spacing between purlins to determine the load on each purlin.

Example: If the total roof load is 40 psf and the purlins are spaced 2 feet apart, the load on each purlin is 40 psf * 2 feet = 80 pounds per linear foot (plf).

Step 3: Select a Wood Species and Grade

Choose a wood species and grade based on its bending strength (Fb) and availability in your area. Remember to consider the cost and durability of different species.

Tip: Douglas Fir is a good all-around choice for many applications due to its high strength and relatively low cost.

Step 4: Determine the Adjustment Factors

Determine the appropriate adjustment factors based on the conditions of use, including moisture content (Cm), load duration (Cd), size (Cf), and flat use (Cfu). Consult the NDS for guidance.

Step 5: Calculate the Required Section Modulus (S)

The section modulus is a geometric property of the purlin that relates to its resistance to bending. Calculate the required section modulus using the following formula:

S = (3 * w * L^2) / (2 * Fb’ )

Where:

S = Section Modulus (in^3)
w = Load per linear foot (plf)
L = Span (distance between supports) in feet
Fb’ = Adjusted Bending Strength (Fb * Cm * Cd * Cf * Cfu)

Step 6: Select a Purlin Size

Consult a lumber size chart to find a purlin size with a section modulus equal to or greater than the required section modulus.

Tip: It’s always better to err on the side of caution and choose a slightly larger purlin size.

Step 7: Check Deflection

Calculate the expected deflection of the purlin using engineering formulas. Ensure that the deflection is within the allowable limits. If not, increase the purlin size or reduce the span.

Step 8: Document Your Calculations

Keep a record of all your calculations and assumptions. This will be helpful for future reference and may be required for building permits.

Tools of the Trade: Chainsaws, Axes, and More

When working with wood, having the right tools is essential. Here’s a brief overview of some common tools used in wood processing and firewood preparation:

Chainsaws: Indispensable for felling trees, bucking logs, and cutting lumber. Choose a chainsaw with the appropriate power and bar length for the size of the trees you’ll be working with. I personally prefer Stihl and Husqvarna chainsaws for their reliability and performance.
Axes: Useful for splitting logs, felling small trees, and shaping wood. A good splitting axe can make firewood preparation much easier.
Log Splitters: Hydraulic log splitters can significantly reduce the effort required to split large logs. They are available in gas-powered and electric models.
Moisture Meters: Essential for measuring the moisture content of wood. Choose a pin-type or pinless moisture meter for accurate readings.
Measuring Tools: Tape measures, levels, and squares are essential for accurate layout and construction.
Safety Gear: Always wear appropriate safety gear, including a hard hat, safety glasses, hearing protection, and gloves, when working with wood.

Chainsaw vs. Axe: A Personal Perspective

I’ve used both chainsaws and axes extensively throughout my career. While chainsaws are undoubtedly faster and more efficient for large-scale wood processing, I still appreciate the satisfaction of splitting wood with an axe. There’s something primal and rewarding about it. However, for serious firewood production, a log splitter is a game-changer.

Troubleshooting Common Purlin Problems

Even with careful planning, problems can arise during purlin installation. Here are some common issues and how to address them:

Purlins Sagging: This is usually caused by undersized purlins or excessive load. Reinforce the purlins with additional supports or replace them with larger ones.
Purlins Twisting or Warping: This is often due to using green lumber. Replace the warped purlins with seasoned lumber.
Purlins Splitting: This can be caused by over-driving fasteners or using the wrong type of fastener. Use the correct fasteners and avoid over-tightening them.
Purlins Rotting: This is due to moisture exposure. Protect the purlins with a wood preservative and ensure proper ventilation.

Cost Considerations and Budgeting Tips

Building projects can quickly become expensive. Here are some tips for managing costs when sizing and installing purlins:

Shop Around: Get quotes from multiple lumber suppliers to find the best prices.
Consider Alternative Materials: Explore alternative materials like engineered lumber or metal purlins, which may be more cost-effective in some cases.
Buy in Bulk: Purchase lumber in bulk to take advantage of quantity discounts.
Salvage Lumber: Consider using salvaged lumber for non-structural components.
Plan Carefully: Accurate planning can help you avoid costly mistakes and wasted materials.

The Art of Wood Seasoning: A Patient Process

Properly seasoned firewood burns hotter, cleaner, and more efficiently. The key is to reduce the moisture content to below 20%. Here’s my tried-and-true method:

Split the Wood: Splitting the wood increases the surface area exposed to air, accelerating the drying process.
Stack it Right: Stack the wood in a single row, elevated off the ground on pallets or timbers. This allows air to circulate freely around the wood.
Sun and Wind: Choose a sunny and windy location for your wood stack.
Cover the Top: Cover the top of the stack with a tarp or roofing material to protect it from rain and snow. Leave the sides open for ventilation.
Patience is Key: Allow the wood to season for at least six months, and preferably a year or more.

Next Steps and Additional Resources

Congratulations! You’ve now gained a solid understanding of purlin sizing and wood processing. Here are some next steps you can take:

Consult with a Structural Engineer: For complex projects, I highly recommend consulting with a structural engineer to ensure the safety and integrity of your structure.
Visit Your Local Lumberyard: Talk to the experts at your local lumberyard to get advice on wood species, grades, and pricing.
Review Local Building Codes: Familiarize yourself with the building codes in your area.
Explore Online Resources: There are many excellent online resources available, including the American Wood Council’s website and various woodworking forums.
Find a Local Wood Drying Equipment Rental Service: Renting equipment to dry wood can be an option for some operations.

Suppliers of Logging Tools

Baileys: A well-known supplier of logging tools, chainsaws, and related equipment.
Northern Tool + Equipment: Offers a wide range of tools and equipment for various applications, including logging and wood processing.
Forestry Suppliers, Inc.: Specializes in forestry, surveying, and outdoor equipment.

In Conclusion: Building with Confidence

Choosing the right purlin size is a critical step in any building project. By understanding the key wood specs and following the step-by-step guide outlined in this article, you can confidently select the right purlin size for your needs and ensure the stability and longevity of your structure. Remember to always prioritize safety and consult with professionals when needed. Happy building!
