Husqvarna 55 Chain Size (5 Pro Tips for Perfect Cuts)

Craftsmanship, in my eyes, isn’t just about wielding a tool; it’s about understanding the soul of the wood, the heartbeat of the engine, and the dance between man and machine. It’s about respecting the forest, honoring the tradition, and striving for perfection with every cut. I’ve spent years in the field, learning from seasoned loggers, forestry experts, and, frankly, from my own mistakes. This guide, focusing on the Husqvarna 55 and achieving that elusive “perfect cut,” is a distillation of that experience. It’s not just about chain size; it’s about understanding the interplay of factors that contribute to safe, efficient, and, yes, beautiful wood processing. Pull up a stump, and let’s dive in.

Husqvarna 55 Chain Size: 5 Pro Tips for Perfect Cuts

The Husqvarna 55. It’s a workhorse. A classic. A chainsaw that many, like myself, have grown up with. It’s reliable, powerful enough for most tasks, and relatively easy to maintain. But even the best chainsaw is only as good as the chain you put on it. The wrong chain size, the wrong type, or a poorly maintained chain can turn a powerful tool into a frustrating, dangerous liability. Here, I want to share some insights I’ve gleaned over the years, focusing specifically on chain size and how it impacts the performance of your Husqvarna 55. These aren’t just theoretical musings; these are lessons learned the hard way, often covered in sawdust and smelling of bar oil.

1. Understanding Chain Pitch, Gauge, and Drive Links

This is where we lay the foundation. You can’t choose the right chain without understanding these three critical measurements. Think of it like choosing the right shoes – you need the right size and width for comfort and performance.

• Pitch: The pitch is the distance between any three consecutive rivets on the chain, divided by two. It’s usually expressed in inches. The Husqvarna 55 typically uses a .325″ pitch chain, although some models may accommodate a 3/8″ low profile. It’s crucial to verify the correct pitch for your specific saw model. Using the wrong pitch will damage the drive sprocket and chain. I once tried to force a 3/8″ chain onto a .325″ sprocket. Let’s just say it was a learning experience that involved a lot of frustration and a trip to the repair shop. Learn from my mistake!
  • Data Point: A .325″ pitch chain means that the distance between three rivets is .65″ (.325″ x 2).
• Gauge: The gauge is the thickness of the drive links – the part of the chain that fits into the groove of the bar. The Husqvarna 55 typically uses a .050″ gauge chain. Using the wrong gauge will result in the chain either being too loose (and potentially derailing) or too tight (and causing excessive wear on the bar and chain).
  • Data Point: A .050″ gauge is equivalent to 1.27mm.
• Drive Links: The number of drive links is the total number of these links on your chain. This number is crucial for determining the correct length of the chain for your specific bar. The number of drive links will vary depending on the bar length you are using. For example, a 16″ bar on a Husqvarna 55 typically requires a chain with 66 drive links. A 18″ bar will need a chain with 72 drive links.
  • Data Point: Always count the drive links on your old chain before replacing it, or consult your saw’s manual. Don’t rely on memory; it’s surprisingly easy to misremember.

Why is this important?

Imagine trying to fit a square peg in a round hole. That’s what happens when you use the wrong chain size. The saw won’t cut efficiently, the chain will wear out prematurely, and you’ll be putting undue stress on the engine. All of this leads to wasted time, wasted money, and increased risk of injury.

Practical Tip: Always double-check the pitch, gauge, and drive link count before purchasing a new chain. Your saw’s manual is your best friend here. If you’re unsure, take your old chain to a reputable chainsaw shop, and they can help you identify the correct replacement.

2. Matching Chain Type to Cutting Task

Not all chains are created equal. There are different chain types designed for different cutting tasks. Choosing the right type can significantly improve cutting performance and extend chain life.

• Full Chisel: These chains have square-cornered cutters and offer the fastest cutting speed. They are ideal for clean wood and experienced users. However, they dull quickly if they come into contact with dirt or debris. I primarily use full chisel chains when felling trees in relatively clean environments. The speed and efficiency are unmatched.
  • Data Point: Full chisel chains typically require more frequent sharpening than other types.
• Semi-Chisel: These chains have rounded cutters and are more forgiving in dirty conditions. They are a good all-around choice for general cutting tasks. I often switch to a semi-chisel chain when bucking firewood, as it’s more resistant to dulling from dirt and bark.
  • Data Point: Semi-chisel chains offer a good balance between cutting speed and durability.
• Low-Profile (Micro-Chisel): These chains have smaller cutters and are designed for smaller saws and less experienced users. They offer reduced kickback and are easier to control. While not as fast as full or semi-chisel chains, they are a safer option for beginners.
  • Data Point: Low-profile chains are often recommended for homeowners and occasional users.
• Ripping Chain: These chains are specifically designed for cutting wood with the grain, as opposed to across it. They have a different cutter angle that allows for smoother, more efficient ripping. If you’re milling lumber with your Husqvarna 55 (using an Alaskan mill, for example), a ripping chain is essential.
  • Data Point: Ripping chains have a shallower cutter angle, typically around 10 degrees, compared to cross-cutting chains.

Personal Story: I once spent an entire afternoon trying to mill a log with a standard cross-cutting chain. The results were… less than impressive. The chain kept binding, the saw was overheating, and the cuts were rough and uneven. It was a frustrating experience that taught me the importance of using the right tool for the job. After switching to a proper ripping chain, the difference was night and day.

Practical Tip: Consider the type of wood you’ll be cutting and the conditions you’ll be working in when choosing your chain type. If you’re primarily cutting clean wood, a full chisel chain will give you the best performance. If you’re working in dirty conditions, a semi-chisel chain is a better choice. For milling, a ripping chain is a must.

3. Chain Sharpening: The Key to Performance and Safety

A sharp chain is a safe chain. A dull chain requires more force to cut, which increases the risk of kickback and other accidents. Regular chain sharpening is not just about performance; it’s about safety.

• When to Sharpen: Sharpen your chain whenever you notice a decrease in cutting performance. Signs of a dull chain include:
  • The saw produces sawdust instead of chips.
  • You have to apply more pressure to cut.
  • The saw vibrates excessively.
  • The chain pulls to one side.
• Sharpening Tools: You can sharpen your chain with a variety of tools, including:
  • Round File and Guide: This is the most common and affordable method. It requires some practice, but it allows for precise sharpening.
    • Data Point: Use a file size appropriate for your chain pitch. A .325″ pitch chain typically requires a 5/32″ round file.
  • Electric Chain Sharpener: This is a faster and easier option, but it can be more expensive. Electric sharpeners can also remove more material than hand filing, potentially shortening the life of your chain.
  • Bar-Mounted Sharpener: These sharpeners attach directly to the chainsaw bar and allow you to sharpen the chain while it’s still on the saw. They are convenient for field sharpening.
• Sharpening Technique:
  1. Secure the chain in a vise or on the bar.
  2. Use a file guide to maintain the correct filing angle.
  3. File each cutter consistently, using smooth, even strokes.
  4. Check the depth gauge (raker) height and file them down if necessary.
     • Data Point: The depth gauge should be slightly lower than the cutter. Consult your chain manufacturer’s specifications for the correct depth gauge setting.

Original Research: I conducted a small experiment where I compared the cutting speed of a freshly sharpened chain to that of a moderately dull chain. I used the same Husqvarna 55, the same type of wood (seasoned oak), and the same cutting technique. The results were significant. The sharp chain cut through the log in approximately half the time of the dull chain. This not only highlights the importance of sharpening for performance but also demonstrates the potential for increased productivity.

Practical Tip: Invest in a good quality file and guide. Watch videos and practice your sharpening technique. Don’t be afraid to experiment until you find a method that works for you. Remember, a sharp chain is a safe and efficient chain.

4. Bar Length and Chain Selection: Finding the Right Match

The bar length is the length of the cutting bar, measured from the tip to where it enters the saw housing. Choosing the right bar length is crucial for safety and performance. A bar that is too long can be difficult to control and increase the risk of kickback. A bar that is too short may limit your cutting capacity.

• Recommended Bar Length for Husqvarna 55: The Husqvarna 55 is typically used with bar lengths ranging from 16″ to 20″. I personally find that an 18″ bar offers a good balance between maneuverability and cutting capacity for most tasks.
  • Data Point: Using a bar length outside the recommended range can void your warranty and potentially damage your saw.
• Chain Length: As mentioned earlier, the number of drive links on your chain must match the bar length. Consult your saw’s manual or the bar manufacturer’s specifications to determine the correct chain length for your bar.
• Matching Chain Type to Bar Length: For shorter bars (16″), a low-profile or semi-chisel chain may be a good choice, as they are easier to control. For longer bars (18″ – 20″), a full chisel or semi-chisel chain will provide better cutting performance.

Case Study: I once worked on a project where we were clearing a large area of overgrown brush and small trees. We were using Husqvarna 55s with 16″ bars and low-profile chains. While the low-profile chains were easy to control, they were slow and inefficient for cutting through larger branches. We switched to semi-chisel chains, and the cutting speed improved significantly. This experience highlighted the importance of matching the chain type to the size and type of material being cut.

Practical Tip: Consider the size and type of material you’ll be cutting when choosing your bar length. If you’re primarily cutting small trees and branches, a shorter bar may be sufficient. If you’re cutting larger trees, a longer bar will be necessary. Always use the correct chain length for your bar.

5. Chain Tension: Maintaining Optimal Performance and Preventing Problems

Proper chain tension is critical for safe and efficient chainsaw operation. Too loose, and the chain can derail, causing damage to the saw and potentially injuring the operator. Too tight, and the chain can overheat and break, damaging the bar and sprocket.

• Checking Chain Tension: Check the chain tension before each use and periodically during use. The chain should be snug against the bar but still able to be pulled away slightly.
  • Data Point: A properly tensioned chain should be able to be pulled away from the bar approximately 1/8″ to 1/4″ at the midpoint of the bar.
• Adjusting Chain Tension: The chain tension is adjusted using the tensioning screw located on the side of the saw. Loosen the bar nuts, adjust the tensioning screw until the chain is properly tensioned, and then tighten the bar nuts.
• Factors Affecting Chain Tension: Chain tension can be affected by temperature, bar wear, and chain wear. As the chain heats up during use, it will expand, causing the tension to increase. As the bar and chain wear, the tension will decrease.
• Troubleshooting Chain Tension Problems:
  • Chain is too loose: Tighten the chain tension. If the chain continues to loosen, check for bar wear or chain stretch.
  • Chain is too tight: Loosen the chain tension. If the chain continues to tighten, check for bar damage or chain binding.
  • Chain derails frequently: Check for worn drive sprocket, damaged bar, or incorrect chain size.

Personal Experience: I once neglected to check the chain tension on my Husqvarna 55 before starting a large firewood cutting project. After a few hours of cutting, the chain became dangerously loose and eventually derailed. Fortunately, I was able to stop the saw before any serious damage occurred. This incident served as a valuable reminder of the importance of regular chain tension checks.

Practical Tip: Get into the habit of checking the chain tension before each use. Carry a wrench with you so you can adjust the tension as needed. Pay attention to how the chain feels and sounds while you’re cutting. If you notice any changes, stop and check the tension.

Bonus Tip: Always use the correct bar oil. Bar oil lubricates the chain and bar, reducing friction and wear. Using the wrong type of oil can damage the bar and chain. I prefer a high-quality, biodegradable bar oil.

Additional Considerations for Optimal Husqvarna 55 Performance

Beyond chain size, several other factors contribute to achieving the “perfect cut” with your Husqvarna 55. Ignoring these aspects can negate even the best chain selection.

• Carburetor Adjustment: A properly tuned carburetor ensures the engine is receiving the correct air-fuel mixture. A lean mixture can cause the engine to overheat and lose power. A rich mixture can cause the engine to smoke and run poorly. Adjust the carburetor according to the manufacturer’s instructions.
  • Technical Limitation: Carburetor adjustments should be made with caution and only by experienced users. Improper adjustments can damage the engine.
• Air Filter Maintenance: A clean air filter is essential for proper engine performance. A dirty air filter restricts airflow, causing the engine to run poorly and overheat. Clean the air filter regularly, following the manufacturer’s instructions.
  • Industry Standard: Most manufacturers recommend cleaning the air filter after every 5-10 hours of use.
• Spark Plug Inspection: Inspect the spark plug regularly for signs of wear or fouling. A worn or fouled spark plug can cause the engine to run poorly or not start at all. Replace the spark plug as needed.
  • Tool Requirement: A spark plug wrench is required to remove and install the spark plug.
• Fuel Mixture: Use the correct fuel mixture as specified in the owner’s manual. Using the wrong fuel mixture can damage the engine. The Husqvarna 55 typically requires a 50:1 fuel-to-oil ratio.
  • Precise Measurement: Use a calibrated measuring container to ensure accurate fuel mixture.
• Regular Maintenance: Perform regular maintenance on your Husqvarna 55, including cleaning, lubricating, and inspecting all components. Regular maintenance will help to extend the life of your saw and ensure optimal performance.

Wood Selection and Preparation: The Foundation of a Perfect Cut

The type of wood you’re cutting and how it’s prepared also play a significant role in achieving a perfect cut.

• Hardwoods vs. Softwoods: Hardwoods, such as oak, maple, and hickory, are denser and more difficult to cut than softwoods, such as pine, fir, and spruce. Choose a chain type and bar length appropriate for the type of wood you’re cutting.
  • Data Point: Hardwoods typically have a density of 40 lbs/cubic foot or higher, while softwoods have a density of less than 40 lbs/cubic foot.
• Wood Moisture Content: The moisture content of the wood affects its cutting properties. Green wood (freshly cut wood) is easier to cut than dry wood. However, green wood is also heavier and more likely to bind. Seasoned wood (wood that has been dried) is more difficult to cut but is lighter and less likely to bind.
  • Technical Limitation: The maximum moisture content for firewood is typically 20%.
• Log Dimensions: The diameter of the log also affects the cutting process. Larger logs require more power and a longer bar.
  • Practical Tip: When cutting large logs, make multiple passes to avoid binding and overheating the saw.
• Log Preparation: Remove any dirt, rocks, or debris from the log before cutting. These materials can dull the chain and damage the saw.

Safety First: Essential Practices for Chainsaw Operation

No discussion of chainsaw operation is complete without emphasizing safety. Chainsaws are powerful tools that can cause serious injury if used improperly.

• Personal Protective Equipment (PPE): Always wear appropriate PPE, including:
  • Helmet: Protects your head from falling debris.
  • Eye Protection: Protects your eyes from flying debris.
  • Hearing Protection: Protects your ears from the loud noise of the chainsaw.
  • Gloves: Protect your hands from cuts and abrasions.
  • Chainsaw Chaps: Protect your legs from chainsaw cuts.
  • Steel-Toed Boots: Protect your feet from falling logs and chainsaw cuts.
• Safe Cutting Techniques:
  • Maintain a firm grip on the saw with both hands.
  • Keep your feet firmly planted and maintain a stable stance.
  • Be aware of your surroundings and avoid cutting in hazardous locations.
  • Never cut above shoulder height.
  • Never cut with the tip of the bar (kickback zone).
• Kickback Prevention: Kickback is a sudden, uncontrolled movement of the chainsaw bar that can cause serious injury. To prevent kickback:
  • Avoid cutting with the tip of the bar.
  • Keep the chain sharp.
  • Maintain proper chain tension.
  • Be aware of the potential for kickback when cutting small branches or logs.
• Emergency Procedures:
  • Know how to stop the saw quickly in an emergency.
  • Have a first-aid kit readily available.
  • Know how to contact emergency services.

Data-Backed Content: According to the Consumer Product Safety Commission (CPSC), chainsaws cause tens of thousands of injuries each year. Most of these injuries are preventable with proper training and safety precautions.

Conclusion

Achieving the “perfect cut” with a Husqvarna 55 is a multifaceted process that involves understanding chain size, matching chain type to the task, maintaining a sharp chain, selecting the right bar length, and ensuring proper chain tension. But it’s also about respecting the wood, understanding the limitations of your equipment, and prioritizing safety above all else. I hope this guide has provided you with the knowledge and insights you need to improve your chainsaw skills and achieve those perfect cuts. Remember, practice makes perfect, so get out there, experiment, and learn from your experiences. And always, always prioritize safety. Happy cutting!
