How to Test Chainsaw Coil with Multimeter (3 Pro Tips)

Have you ever been deep in the woods, ready to tackle a mountain of firewood, only to be betrayed by your chainsaw? The frustrating pull of the starter cord, the engine refusing to roar to life—it’s a feeling every woodcutter knows. More often than not, the culprit is a faulty ignition coil. But before you resign yourself to a day of manual labor, let me show you how to diagnose the problem yourself. With a simple multimeter and a few pro tips, you can determine if your chainsaw coil is the issue and potentially save yourself a costly repair bill.

In this article, I’ll share my decades of experience in wood processing and chainsaw maintenance to guide you through testing your chainsaw coil with a multimeter. Forget the guesswork. I’ll provide you with clear, step-by-step instructions, backed by practical insights and a few hard-earned lessons from my own time in the field.

Key Takeaways:

• Learn how to safely and accurately test your chainsaw coil using a multimeter.
• Understand the common causes of coil failure and how to prevent them.
• Discover pro tips to troubleshoot ignition problems beyond just the coil.
• Gain the confidence to diagnose and potentially fix your chainsaw yourself, saving time and money.

Let’s get started.

Understanding the Chainsaw Ignition System

Before diving into the testing process, it’s crucial to understand the role of the ignition system in your chainsaw. It’s the heart of the engine, responsible for creating the spark that ignites the fuel-air mixture, allowing the engine to run. The ignition system comprises several key components:

• Flywheel: A rotating wheel with magnets embedded in it.
• Ignition Coil (or Magneto): A transformer that steps up the low voltage from the flywheel magnets to a high voltage sufficient to create a spark.
• Spark Plug: The device that delivers the high-voltage spark to the combustion chamber.
• Kill Switch: A simple switch that grounds the ignition coil, stopping the spark and shutting off the engine.

When the flywheel rotates, its magnets pass by the ignition coil, inducing a low-voltage current. The coil then amplifies this voltage, sending a powerful surge to the spark plug, which ignites the fuel-air mixture, driving the piston and turning the chain.

The Ignition Coil’s Role

The ignition coil is a critical component in this process. It’s essentially a transformer, consisting of two sets of windings:

• Primary Winding: A few turns of heavy-gauge wire.
• Secondary Winding: Thousands of turns of fine-gauge wire.

The low-voltage current from the flywheel flows through the primary winding, creating a magnetic field. When the magnetic field collapses, it induces a much higher voltage in the secondary winding. This high voltage is then sent to the spark plug.

Why Coils Fail

Ignition coils can fail for several reasons, including:

• Overheating: Prolonged use, especially in hot weather, can cause the coil to overheat and break down.
• Vibration: The constant vibration of a chainsaw can weaken the coil’s internal components over time.
• Moisture: Moisture can corrode the coil’s windings and connections, leading to failure.
• Physical Damage: Impacts or mishandling can damage the coil’s insulation and internal components.
• Age: Like any electrical component, ignition coils have a limited lifespan and will eventually wear out.

Data-Backed Insights

Industry data shows that ignition system problems account for a significant percentage of chainsaw failures. A study by the Outdoor Power Equipment Institute (OPEI) found that approximately 20% of chainsaw repairs are related to ignition issues, with the ignition coil being a frequent culprit. This highlights the importance of understanding how to diagnose and maintain your chainsaw’s ignition system.

Tools and Materials You’ll Need

Before you start testing your chainsaw coil, make sure you have the following tools and materials:

• Multimeter: A digital multimeter is preferred for its accuracy and ease of use. An analog multimeter will also work, but it may be more difficult to read.
• Screwdrivers: You’ll need screwdrivers to remove the chainsaw’s cover and access the ignition coil.
• Wrench or Socket Set: Depending on your chainsaw model, you may need a wrench or socket set to remove the spark plug.
• Spark Plug Wrench: A specialized wrench for removing the spark plug.
• Clean Rags: To wipe away dirt and debris.
• Safety Glasses: To protect your eyes from debris.
• Gloves: To protect your hands.
• Chainsaw Service Manual (Optional): This can provide specific instructions and wiring diagrams for your chainsaw model.

Safety First

Before you begin any work on your chainsaw, always follow these safety precautions:

• Disconnect the Spark Plug Wire: This will prevent the engine from accidentally starting while you’re working on it.
• Wear Safety Glasses and Gloves: Protect your eyes and hands from debris and potential hazards.
• Work in a Well-Ventilated Area: Avoid working in enclosed spaces where flammable fumes may accumulate.
• Refer to Your Chainsaw’s Manual: Consult your chainsaw’s service manual for specific safety instructions and warnings.

Step-by-Step Guide to Testing Your Chainsaw Coil

Now that you have your tools and materials ready, let’s get down to testing your chainsaw coil. I’ll walk you through the process step-by-step.

Step 1: Accessing the Ignition Coil

The first step is to access the ignition coil. This usually involves removing the chainsaw’s cover.

1. Locate the Cover: The cover is typically located on the side of the chainsaw, near the engine.
2. Remove the Cover: Use a screwdriver to remove the screws or bolts holding the cover in place.
3. Inspect the Coil: Once the cover is removed, you should be able to see the ignition coil. It’s usually a small, rectangular component with wires connected to it.

Step 2: Visual Inspection

Before you start testing with the multimeter, take a close look at the ignition coil. Look for any signs of damage, such as:

• Cracks: Cracks in the coil’s housing can indicate that it’s been damaged by impact or overheating.
• Burn Marks: Burn marks can indicate that the coil has overheated and failed.
• Corrosion: Corrosion on the coil’s terminals or wires can prevent proper electrical contact.
• Loose Wires: Loose or disconnected wires can prevent the coil from functioning properly.

If you see any of these signs of damage, it’s likely that the coil is faulty and needs to be replaced.

Step 3: Setting Up Your Multimeter

Now it’s time to set up your multimeter for testing.

1. Set the Multimeter to Ohms: Turn the multimeter’s dial to the “Ohms” (Ω) setting. This setting measures electrical resistance.
2. Select the Appropriate Range: If your multimeter has multiple Ohms ranges, select the lowest range that’s higher than zero. For example, if your multimeter has ranges of 200Ω, 2kΩ, and 20kΩ, select the 200Ω range.

Step 4: Testing the Primary Winding

The primary winding is the first part of the coil we’ll test.

1. Locate the Primary Terminals: The primary terminals are usually two small metal tabs on the coil.
2. Connect the Multimeter Probes: Touch one multimeter probe to each of the primary terminals.
3. Read the Resistance: Look at the multimeter’s display and note the resistance reading.

Interpreting the Results:

• Good Coil: A good coil will typically have a low resistance reading, usually between 0.5 and 2.0 ohms. This indicates that the primary winding is intact and conducting electricity properly.
• Bad Coil: A reading of zero ohms (a short circuit) or infinite ohms (an open circuit) indicates a problem with the primary winding. A short circuit means that the wire is broken somewhere inside the coil, preventing current from flowing properly. An open circuit means that the wire is broken somewhere inside the coil, preventing current from flowing at all.

Step 5: Testing the Secondary Winding

Next, we’ll test the secondary winding.

1. Locate the Secondary Terminals: One secondary terminal is usually the spark plug wire connector. The other is often grounded to the coil’s body.
2. Connect the Multimeter Probes: Touch one multimeter probe to the spark plug wire connector and the other probe to the coil’s body (or the grounded terminal).
3. Read the Resistance: Look at the multimeter’s display and note the resistance reading.

Interpreting the Results:

• Good Coil: A good coil will typically have a high resistance reading, usually between 2,000 and 10,000 ohms (2kΩ to 10kΩ). This indicates that the secondary winding is intact and capable of producing the high voltage needed for a spark.
• Bad Coil: A reading of zero ohms (a short circuit) or infinite ohms (an open circuit) indicates a problem with the secondary winding. A short circuit means that the wire is broken somewhere inside the coil, preventing current from flowing properly. An open circuit means that the wire is broken somewhere inside the coil, preventing current from flowing at all.

Step 6: Testing for Ground

Finally, we’ll test to make sure the coil isn’t shorted to ground.

1. Set the Multimeter to Ohms: Make sure your multimeter is still set to measure resistance (Ohms).
2. Connect the Multimeter Probes: Touch one multimeter probe to either of the primary terminals and the other probe to the coil’s body (or any metal part of the chainsaw’s engine).
3. Read the Resistance: Look at the multimeter’s display and note the resistance reading.

Interpreting the Results:

• Good Coil: A good coil should have a very high resistance reading (ideally infinite ohms) when tested for ground. This indicates that there is no electrical connection between the coil’s windings and the chainsaw’s body.
• Bad Coil: A low resistance reading (close to zero ohms) indicates that the coil is shorted to ground. This means that electricity is leaking from the coil to the chainsaw’s body, which can prevent the coil from producing a spark.

3 Pro Tips for Chainsaw Ignition Troubleshooting

Testing the coil is an important step, but it’s not the only thing you should check when troubleshooting ignition problems. Here are three pro tips that I’ve learned over the years:

Pro Tip 1: Check the Spark Plug

The spark plug is the final link in the ignition chain. A fouled, cracked, or worn-out spark plug can prevent the engine from starting, even if the coil is working perfectly.

• Inspect the Spark Plug: Remove the spark plug and inspect it for cracks, carbon buildup, or other damage.
• Clean the Spark Plug: If the spark plug is fouled with carbon, clean it with a wire brush or spark plug cleaner.
• Check the Gap: Use a spark plug gapping tool to ensure that the gap between the electrode and the ground strap is within the manufacturer’s specifications.
• Test the Spark: Reconnect the spark plug to the spark plug wire and hold it against the engine block. Pull the starter cord and watch for a strong, blue spark. If the spark is weak, yellow, or nonexistent, the spark plug may be faulty and needs to be replaced.

Pro Tip 2: Inspect the Spark Plug Wire and Boot

The spark plug wire and boot connect the ignition coil to the spark plug. Damage to these components can interfere with the spark.

• Check for Cracks and Damage: Inspect the spark plug wire and boot for cracks, cuts, or other damage.
• Check for Loose Connections: Make sure the spark plug wire is securely connected to the ignition coil and the spark plug.
• Test the Wire: Use a multimeter to test the resistance of the spark plug wire. A good wire should have a low resistance reading (usually less than 5,000 ohms). A high resistance reading or an open circuit indicates a problem with the wire.

Pro Tip 3: Verify the Air Gap

The air gap is the distance between the ignition coil and the flywheel. If the air gap is too large or too small, it can prevent the coil from producing a spark.

• Locate the Air Gap: The air gap is usually located on the side of the flywheel, near the ignition coil.
• Use a Feeler Gauge: Use a feeler gauge to measure the air gap. The correct air gap is usually specified in your chainsaw’s service manual. A typical air gap is between 0.010 and 0.020 inches (0.25 to 0.50 mm).
• Adjust the Air Gap: If the air gap is not within the specified range, loosen the screws holding the ignition coil in place and adjust its position until the air gap is correct. Then, tighten the screws.

Expert Insight

I once worked alongside a seasoned chainsaw mechanic who swore by a simple trick: “Always check the kill switch wiring first,” he’d say. “A frayed wire grounding out the ignition can mimic a bad coil every time.” This saved me hours of unnecessary work on more than one occasion. It’s a reminder that sometimes the simplest solutions are the easiest to overlook.

Chainsaw Coil Replacement: A Step-by-Step Guide

If your testing reveals that the ignition coil is indeed faulty, you’ll need to replace it. Here’s a step-by-step guide to help you through the process:

Step 1: Disconnect the Spark Plug Wire

As always, the first step is to disconnect the spark plug wire from the spark plug to prevent accidental starting.

Step 2: Remove the Old Ignition Coil

1. Remove the Cover: Remove the chainsaw’s cover to access the ignition coil.
2. Disconnect the Wires: Disconnect the wires connected to the ignition coil. Be sure to note the location of each wire so you can reconnect them correctly later.
3. Remove the Mounting Screws: Use a screwdriver or wrench to remove the screws or bolts holding the ignition coil in place.
4. Remove the Old Coil: Carefully remove the old ignition coil from the chainsaw.

Step 3: Install the New Ignition Coil

1. Position the New Coil: Position the new ignition coil in the same location as the old coil.
2. Install the Mounting Screws: Install the mounting screws or bolts and tighten them securely.
3. Connect the Wires: Reconnect the wires to the ignition coil, making sure to connect them to the correct terminals. Refer to your notes or the chainsaw’s wiring diagram if needed.
4. Set the Air Gap: Set the air gap between the new ignition coil and the flywheel. Use a feeler gauge to measure the gap and adjust the coil’s position as needed.
5. Reinstall the Cover: Reinstall the chainsaw’s cover.

Step 4: Test the Chainsaw

1. Reconnect the Spark Plug Wire: Reconnect the spark plug wire to the spark plug.
2. Start the Chainsaw: Start the chainsaw and see if it runs properly.

If the chainsaw starts and runs smoothly, you’ve successfully replaced the ignition coil. If it still doesn’t start, double-check your wiring connections and the air gap. If you’re still having problems, there may be other issues with the chainsaw’s engine that need to be addressed.

Preventing Chainsaw Coil Failure

Prevention is always better than cure. Here are some tips to help you prevent chainsaw coil failure:

• Keep Your Chainsaw Clean: Clean your chainsaw regularly to remove dirt, debris, and moisture that can damage the ignition coil.
• Store Your Chainsaw Properly: Store your chainsaw in a dry, well-ventilated area to prevent corrosion.
• Avoid Overheating: Avoid running your chainsaw for extended periods of time, especially in hot weather. Give it a break to cool down periodically.
• Use the Correct Fuel Mixture: Use the correct fuel-to-oil mixture recommended by the chainsaw manufacturer. Using the wrong mixture can cause the engine to overheat and damage the ignition coil.
• Maintain Your Chainsaw Regularly: Perform regular maintenance on your chainsaw, including cleaning the air filter, replacing the spark plug, and checking the fuel lines.
• Avoid Physical Damage: Handle your chainsaw carefully to avoid impacts or mishandling that can damage the ignition coil.

Data-Backed Insights

Regular maintenance and proper storage can significantly extend the life of your chainsaw’s ignition coil. A study by STIHL found that chainsaws that are properly maintained and stored have a 50% lower rate of ignition system failures compared to those that are neglected.

Case Studies: Real-World Chainsaw Coil Problems

To further illustrate the importance of understanding chainsaw ignition systems, let’s look at a couple of real-world case studies:

Case Study 1: The Overheated Coil

A professional logger was using his chainsaw to fell trees in the summer heat. He ran the chainsaw continuously for hours without giving it a break. One day, the chainsaw suddenly stopped working. He tried to restart it, but it wouldn’t start.

After troubleshooting the problem, he discovered that the ignition coil had overheated and failed. The constant use in hot weather had caused the coil to break down.

Lesson Learned: Avoid running your chainsaw continuously for extended periods of time, especially in hot weather. Give it a break to cool down periodically.

Case Study 2: The Corroded Coil

A homeowner stored his chainsaw in a damp shed during the winter. When he went to use it in the spring, it wouldn’t start.

After inspecting the chainsaw, he found that the ignition coil was corroded. The moisture in the shed had caused the coil to corrode and fail.

Lesson Learned: Store your chainsaw in a dry, well-ventilated area to prevent corrosion.

The Future of Chainsaw Ignition Systems

As technology advances, chainsaw ignition systems are becoming more sophisticated. Some newer chainsaws feature electronic ignition systems that offer improved performance and reliability. These systems use electronic components to control the timing and intensity of the spark, resulting in more efficient combustion and reduced emissions.

While these advanced systems offer several advantages, they can also be more complex to diagnose and repair. However, the basic principles of ignition system troubleshooting still apply. Understanding the role of the ignition coil and how to test it with a multimeter will remain a valuable skill for chainsaw owners and mechanics alike.

Conclusion

Testing your chainsaw coil with a multimeter is a simple yet effective way to diagnose ignition problems. By following the steps outlined in this article and using the pro tips I’ve shared, you can determine if your chainsaw coil is the culprit and potentially save yourself time and money.

Remember, safety is always the top priority when working on your chainsaw. Disconnect the spark plug wire, wear safety glasses and gloves, and work in a well-ventilated area.

If you’re not comfortable working on your chainsaw yourself, don’t hesitate to take it to a qualified mechanic. But with a little knowledge and the right tools, you can tackle many chainsaw repairs yourself and keep your equipment running smoothly for years to come.

Now, armed with this knowledge, go forth and conquer those wood piles! And remember, a well-maintained chainsaw is a happy chainsaw.
