How Much Thread Needs for FS 56 RC Recoil Spring (Fix Tips)

Flooring, to me, isn’t just a surface; it’s an art form. It’s the foundation upon which we build our lives, literally and figuratively. And like any art form, the beauty lies not only in the final product but also in the meticulous details of its creation. Speaking of meticulous details, I’ve found myself wrestling with the recoil spring of my Stihl FS 56 RC more times than I care to admit. It’s a common problem, and getting the right amount of thread tension on that spring is crucial for a smooth start. This guide is born from my own frustrations and hard-won knowledge, aimed at helping you fix your FS 56 RC recoil starter correctly, the first time.

Understanding the FS 56 RC Recoil Starter System

Before we dive into the nitty-gritty of thread count, let’s understand what we’re dealing with. The recoil starter is the mechanism that allows you to manually start your FS 56 RC. It works by engaging a pawl that catches the engine’s flywheel, allowing you to crank the engine. The recoil spring is the heart of this system, providing the force to retract the starter rope after you pull it. Too much or too little tension on this spring, and you’ll face starting problems. It’s like Goldilocks and the three bears – it needs to be just right.

The Importance of Proper Spring Tension

Proper spring tension is paramount for several reasons:

• Reliable Starting: The engine needs to crank over with sufficient force to ignite the fuel-air mixture. Insufficient spring tension means a weak pull, leading to starting failures.
• Smooth Retraction: The rope should retract smoothly and completely after each pull. Incorrect tension can cause the rope to retract slowly, jerkily, or not at all.
• Longevity of Components: Over-tightening the spring puts excessive stress on the spring itself and the surrounding plastic components, leading to premature wear and breakage. Under-tightening causes the rope to slip on the spool, accelerating wear on both the rope and the spool.

Diagnosing Recoil Starter Problems

Before you start adjusting the spring, it’s important to diagnose the root cause of the problem. Here are some common symptoms and their potential causes:

• Rope won’t retract: This is often caused by a broken spring, a spring with insufficient tension, or a binding rope.
• Rope retracts slowly: This could be due to dirt and debris in the starter housing, a weak spring, or excessive friction.
• Rope is difficult to pull: This may indicate a seized engine (unlikely in this context, but worth checking), an over-tightened spring, or binding components.
• Rope slips on the spool: This is usually caused by an under-tightened spring or a worn rope.

Determining the Correct Thread Count: A Practical Approach

Now, to the million-dollar question: how much thread do you need? Unfortunately, there’s no single, universally agreed-upon number. Stihl doesn’t publish a specific thread count for the FS 56 RC recoil spring. The tension is typically adjusted by feel and observation. However, based on my experience and research, here’s a practical approach:

The “Feel” Method (My Preferred Method)

This is the method I prefer because it allows for fine-tuning based on the specific condition of the spring and starter components.

1. Clean Everything: Before you start, thoroughly clean the starter housing, spool, and spring. Remove any dirt, debris, or old grease. Use a degreaser if necessary. This ensures smooth operation and accurate adjustment.
2. Insert the Spring: Carefully insert the recoil spring into the starter housing. Make sure it’s seated properly.
3. Pre-tension the Spring: This is where the “feel” comes in. Rotate the spool (the part the rope wraps around) in the direction that winds the spring before you install the rope. Start with a small amount of pre-tension. I usually aim for about 3/4 to 1 full turn initially.
4. Install the Rope: Thread the starter rope through the hole in the spool and tie a secure knot. Make sure the knot is seated properly in the recess of the spool.
5. Test the Retraction: Holding the starter housing securely, pull the rope out completely and release it. Observe the retraction.
6. Adjust as Needed:
   • If the rope retracts too slowly or not completely: Add more pre-tension to the spring by rotating the spool in the winding direction another 1/4 to 1/2 turn.
   • If the rope retracts too forcefully or is difficult to pull: Reduce the pre-tension by rotating the spool in the opposite direction.
7. Repeat: Keep testing and adjusting in small increments until you achieve a smooth, consistent retraction. The goal is for the rope to retract fully and briskly without feeling overly tight or loose.

Key Considerations:

• Spring Condition: A new spring will require slightly less pre-tension than an older, worn spring.
• Rope Condition: A thicker or stiffer rope may require slightly more pre-tension.
• Lubrication: A small amount of silicone-based lubricant on the spring and spool can improve smoothness and reduce friction. Avoid petroleum-based lubricants, as they can attract dirt and debris.

A More Structured Approach (For Beginners)

If you’re uncomfortable with the “feel” method, here’s a more structured approach using thread count as a starting point. Note that this is an estimate and will still require some fine-tuning.

1. Disassemble and Clean: Same as above – clean everything thoroughly.
2. Count Threads: Carefully observe the number of threads visible on the spring before disassembly (if possible). This gives you a baseline. If the spring was completely unwound, this step is skipped.
3. Initial Thread Count: Based on my experience, a good starting point for the FS 56 RC is to aim for approximately 4-6 visible threads on the spring after it’s installed and pre-tensioned.
4. Install and Pre-tension: Install the spring and pre-tension it until you see approximately 4-6 threads.
5. Install Rope and Test: Install the rope and test the retraction as described above.
6. Adjust: Add or remove pre-tension (and thus, thread count) as needed until you achieve the desired retraction.

Important Notes:

• Thread count is a guide, not a rule. The optimal thread count will vary depending on the spring and components.
• Focus on the feel of the retraction. A smooth, consistent retraction is more important than hitting a specific thread count.
• Don’t over-tighten! Over-tightening the spring can damage it and the starter housing.

Practical Tips and Best Practices

Here are some additional tips and best practices to keep in mind:

• Use the Right Tools: Use a pair of needle-nose pliers or a small screwdriver to carefully manipulate the spring. Avoid using excessive force, as this can damage the spring.
• Work in a Clean Environment: A clean workspace will prevent dirt and debris from contaminating the starter mechanism.
• Take Pictures: Before disassembling the starter, take pictures of each step. This will help you remember how everything goes back together.
• Safety First: Wear safety glasses to protect your eyes from flying debris.
• Consider a New Spring: If your spring is old, rusty, or damaged, it’s best to replace it with a new one. A new spring will provide more consistent tension and improve the reliability of the starter. Stihl part number 4144-190-0300 is the correct replacement spring.
• Lubrication is Key: A light application of silicone-based lubricant to the spring and spool will help reduce friction and improve smoothness.
• Rope Quality Matters: Use a high-quality starter rope that is the correct diameter for the FS 56 RC. A worn or frayed rope can cause slipping and premature wear. The correct rope diameter is typically 3.0mm to 3.5mm.
• Proper Knotting: Use a secure knot to attach the rope to the spool. A loose knot can slip and cause the rope to retract improperly. A figure-eight knot is a good choice.
• Inspect the Pawls: While you have the starter disassembled, inspect the pawls (the little “fingers” that engage the flywheel). Make sure they are clean, move freely, and are not worn or damaged. Replace them if necessary. Stihl part number 4144-195-7200 is the correct pawl replacement kit.
• Check the Flywheel: Inspect the flywheel for any damage or wear where the pawls engage. A damaged flywheel can prevent the starter from working properly.

Troubleshooting Common Problems

Here are some common problems you might encounter and how to troubleshoot them:

• Starter rope pulls out easily but doesn’t engage the engine: This usually indicates a problem with the pawls. They may be stuck, worn, or broken. Clean or replace the pawls.
• Starter rope is difficult to pull: This could be due to a seized engine (unlikely), an over-tightened spring, or binding components. Check the engine first. If the engine is okay, try loosening the spring tension slightly.
• Starter rope retracts slowly or not at all: This is often caused by a weak spring, dirt and debris, or excessive friction. Clean the starter housing and spool. Lubricate the spring. If the problem persists, replace the spring.
• Starter rope slips on the spool: This is usually caused by an under-tightened spring or a worn rope. Tighten the spring or replace the rope.
• Starter rope breaks frequently: This could be due to a worn rope, sharp edges on the starter housing, or excessive strain on the rope. Replace the rope with a high-quality rope. Smooth any sharp edges on the starter housing. Avoid pulling the rope out to its full extent.

Case Study: My Own Recoil Spring Saga

I once spent an entire afternoon wrestling with the recoil starter on my FS 56 RC. I had disassembled it to clean it, and when I put it back together, the rope wouldn’t retract properly. I tried adjusting the spring tension every which way, but nothing seemed to work. I was about to throw in the towel when I realized that I had forgotten to lubricate the spring. A quick application of silicone grease, and the starter worked like new. This taught me the importance of paying attention to the small details. Lubrication is often the key to smooth operation.

Safety Considerations

Working on power equipment can be dangerous. Always follow these safety precautions:

• Disconnect the spark plug: Before working on the recoil starter, disconnect the spark plug wire to prevent accidental starting.
• Wear safety glasses: Protect your eyes from flying debris.
• Work in a well-ventilated area: Avoid breathing in fumes from cleaning solvents or lubricants.
• Use the right tools: Using the wrong tools can damage the equipment or cause injury.
• Take your time: Don’t rush the job. Rushing can lead to mistakes and accidents.
• If in doubt, seek professional help: If you’re not comfortable working on the recoil starter yourself, take it to a qualified technician.

Alternative Solutions: When to Seek Professional Help

Sometimes, despite your best efforts, you might not be able to fix the recoil starter yourself. Here are some situations where it’s best to seek professional help:

• The spring is broken: Replacing a broken spring can be tricky, especially if you don’t have the right tools or experience.
• The starter housing is damaged: A cracked or broken starter housing can prevent the starter from working properly.
• You’ve tried everything and nothing works: If you’ve exhausted all the troubleshooting steps and the starter still doesn’t work, it’s time to call in the professionals.

The Importance of Regular Maintenance

To prevent recoil starter problems in the first place, it’s important to perform regular maintenance:

• Clean the starter housing regularly: Remove any dirt, debris, or old grease.
• Lubricate the spring periodically: A light application of silicone-based lubricant will help keep the spring working smoothly.
• Inspect the rope for wear and tear: Replace the rope if it’s worn or frayed.
• Store the equipment properly: Store the FS 56 RC in a clean, dry place.

Long-Term Recoil Spring Longevity

To maximize the lifespan of your recoil spring, consider these strategies:

• Avoid Over-Pulling: Don’t pull the starter rope out to its full extent repeatedly. This puts unnecessary stress on the spring.
• Smooth Pulls: Use smooth, controlled pulls when starting the engine. Jerky pulls can damage the spring.
• Proper Storage: Store the FS 56 RC in a way that the starter rope isn’t constantly under tension.
• Quality Replacement Parts: When replacing the spring, opt for a genuine Stihl part or a high-quality aftermarket equivalent. Cheap springs often fail prematurely.
• Consider a Soft Start System: While not directly related to the spring, ensuring the engine isn’t overly difficult to start will reduce strain on the entire recoil system, including the spring.

Data-Backed Insights: Spring Material and Lifespan

While precise data on the FS 56 RC recoil spring material isn’t publicly available, most high-quality recoil springs are made from high-carbon steel or spring steel alloys. These materials offer excellent tensile strength and fatigue resistance, allowing them to withstand repeated winding and unwinding.

• Spring Steel Specifications: Typical spring steel alloys used in recoil springs have a tensile strength of 1800-2200 MPa (megapascals).
• Fatigue Life: A well-maintained recoil spring, under normal operating conditions, can last for hundreds or even thousands of starts. However, factors such as over-pulling, improper lubrication, and exposure to harsh environments can significantly reduce its lifespan.
• Industry Standards: While there aren’t specific industry standards for recoil spring lifespan, manufacturers typically design them to last for the expected lifespan of the equipment.

Conclusion: Mastering the Recoil Spring

Fixing the recoil spring on your Stihl FS 56 RC might seem daunting at first, but with a little patience and the right knowledge, it’s a task you can confidently tackle. Remember to prioritize cleanliness, lubrication, and proper tension adjustment. Whether you prefer the “feel” method or a more structured approach, the key is to focus on achieving a smooth, consistent retraction. And most importantly, always prioritize safety. By following these tips and best practices, you can keep your FS 56 RC running smoothly for years to come. After all, the art of woodworking (or, in this case, weed whacking) is all about the details. And a properly functioning recoil starter is a detail that can make all the difference.
