How Is a Chainsaw Bar Measured? (5 Pro Tips Woodcutters Use)

Measuring a chainsaw bar accurately is crucial for several reasons. You need to know the correct size when replacing a worn bar, purchasing a new chain, or simply understanding the capabilities of your saw. Getting it wrong can lead to wasted money, a poorly performing saw, and even potential safety hazards. I’ve seen firsthand the frustration of ordering the wrong size bar and chain, and trust me, it’s something you want to avoid.

Understanding Chainsaw Bar Terminology

Before we get into the nitty-gritty of measuring, let’s clarify some essential terms related to chainsaw bars:

Bar Length: This is the most commonly referenced measurement and often what people mean when they ask about bar size. It’s the distance from the tip of the bar to where it enters the chainsaw body.
Effective Cutting Length: This refers to the portion of the bar that actually houses the chain and is available for cutting. It’s slightly shorter than the overall bar length.
Gauge: The gauge is the thickness of the drive links on the chain that fit into the bar groove. It needs to match the bar’s groove width.
Pitch: This is the distance between any three consecutive rivets on the chain, divided by two. It determines the size of the chain’s drive links.
Mounting Pattern: This refers to the specific arrangement of bolt holes and oiling holes on the bar that match the chainsaw’s powerhead.

Why Accurate Measurement Matters

Chain Compatibility: The bar length directly dictates the number of drive links needed in the chain. An incorrect measurement means the chain won’t fit properly, leading to slippage, premature wear, or even chain breakage.
Optimal Performance: Using the correct bar length ensures the saw is balanced and performs as intended. A bar that’s too long can overtax the engine, while one that’s too short might limit the saw’s cutting capacity.
Safety: A properly sized bar and chain contribute to safer operation. A mismatched setup can increase the risk of kickback or chain breakage.
Replacement Parts: When ordering a new bar or chain, knowing the exact measurements ensures you get the right replacement parts, saving you time and money.

Pro Tip 1: Measure the Existing Bar (If Possible)

The easiest and most reliable way to determine your chainsaw bar size is to measure the bar you already have. Here’s how:

Remove the Bar and Chain: Always start by disengaging the chain brake and removing the chain and bar from the chainsaw. Remember to wear gloves to protect your hands from the sharp chain.
Locate the Measurement Point: The bar length is measured from the tip of the bar to the point where it meets the chainsaw body. This is usually where the mounting bolts are located.
Use a Measuring Tape: Use a standard measuring tape to measure the distance between these two points. Extend the tape from the tip of the bar down to the mounting surface.
Read the Measurement: Note the measurement in inches or centimeters. This is your bar length.
Verify with Stamped Information: Many bars have the length stamped directly on them. Look for markings near the mounting area. This can serve as a quick confirmation of your measurement.

Personal Story: I once spent hours trying to figure out the bar size of an old chainsaw I inherited. The bar was so worn that the stamped information was illegible. I finally had to resort to carefully measuring the bar multiple times to ensure accuracy. It taught me the importance of keeping that stamped information clean and visible.

Example: If you measure from the tip of the bar to the mounting point and find it to be 18 inches, you have an 18-inch bar.

Why This Works: Measuring the existing bar eliminates guesswork and ensures you get the correct replacement size. It’s especially helpful if you’re unsure of the original bar size or if the chainsaw is used.

Potential Challenges: The bar might be damaged or worn, making accurate measurement difficult. In such cases, proceed to the next tip.

Pro Tip 2: Consult the Chainsaw’s User Manual

Your chainsaw’s user manual is a treasure trove of information, including the recommended bar lengths for your specific model.

Locate the User Manual: If you still have the original user manual, great! If not, you can often find a digital version on the manufacturer’s website.
Find the Specifications Section: Look for a section that lists the technical specifications of your chainsaw model. This section usually includes information about the engine size, weight, and recommended bar lengths.
Identify the Recommended Bar Lengths: The manual might list a range of acceptable bar lengths. Choose the length that best suits your typical cutting tasks.
Consider Cutting Needs: Shorter bars are generally better for limbing and smaller trees, while longer bars are needed for felling larger trees.

Data Point: According to a study by the U.S. Forest Service, using the appropriate bar length for the size of the tree being cut can significantly reduce the risk of kickback and improve cutting efficiency by up to 20%.

Example: Your user manual might state that your chainsaw model is compatible with bar lengths ranging from 16 to 20 inches. If you primarily cut firewood from medium-sized trees, an 18-inch bar might be the best choice.

Why This Works: The user manual provides the manufacturer’s recommended bar lengths, ensuring compatibility and optimal performance.

Potential Challenges: You might not have the user manual, or the manual might not list the specific bar lengths. In this case, move on to the next tip.

Pro Tip 3: Use the Chainsaw Model Number

Even without the user manual, you can often determine the correct bar size by using your chainsaw’s model number.

Locate the Model Number: The model number is usually found on a sticker or plate attached to the chainsaw body. It might be near the engine, handle, or fuel tank.
Search Online: Use a search engine to search for your chainsaw model number along with the keywords “bar length” or “chain size.”
Check Manufacturer’s Website: Visit the chainsaw manufacturer’s website and enter your model number in the search bar. The website should provide detailed specifications, including the recommended bar lengths and chain sizes.
Consult Online Retailers: Many online retailers that sell chainsaw parts also list the compatible bar lengths and chain sizes for specific chainsaw models.

Personal Story: I once helped a friend find the right bar for his chainsaw by using the model number. He had lost the user manual and wasn’t sure of the correct size. A quick search on the manufacturer’s website revealed that his chainsaw was compatible with a 16-inch bar, which he then ordered and installed successfully.

Example: You find the model number “MS 271” on your chainsaw. A quick online search reveals that the MS 271 is typically used with a 16-inch or 18-inch bar.

Why This Works: The model number is a unique identifier that allows you to access specific information about your chainsaw, including the recommended bar lengths.

Potential Challenges: The online information might be inaccurate or incomplete. Always double-check the information from multiple sources before making a purchase.

Pro Tip 4: Measure the Effective Cutting Length

While the bar length is the most common measurement, the effective cutting length can also be useful, especially when comparing different bar types.

Remove the Chain: As always, start by removing the chain from the bar.
Measure the Exposed Portion: Measure the length of the bar that is exposed and available for cutting. This is the distance from the tip of the bar to the point where the chain enters the chainsaw body.
Consider Bar Type: Different bar types, such as laminated bars and solid bars, might have slightly different effective cutting lengths for the same overall bar length.

Data Point: A study by Oregon Products found that the effective cutting length can vary by as much as 1 inch between different bar types of the same nominal length.

Example: You measure the effective cutting length of your bar and find it to be 17 inches. This means that while the bar might be advertised as an 18-inch bar, only 17 inches of it are actually used for cutting.

Why This Works: Measuring the effective cutting length provides a more accurate representation of the bar’s cutting capacity.

Potential Challenges: This measurement can be slightly less precise than measuring the overall bar length, as it depends on the specific design of the bar.

Pro Tip 5: Understand Chain Pitch and Gauge

In addition to bar length, understanding chain pitch and gauge is crucial for ensuring compatibility between the bar and chain.

Identify the Pitch: The pitch is the distance between any three consecutive rivets on the chain, divided by two. Common pitches include 0.325 inch, 3/8 inch, and 0.404 inch. You can usually find the pitch stamped on the drive links of the chain.
Identify the Gauge: The gauge is the thickness of the drive links that fit into the bar groove. Common gauges include 0.043 inch, 0.050 inch, 0.058 inch, and 0.063 inch. The gauge is also usually stamped on the drive links of the chain.
Match Pitch and Gauge: Ensure that the pitch and gauge of the chain match the specifications of the bar. Using the wrong pitch or gauge can damage the bar and chain and create a safety hazard.

Personal Story: I once made the mistake of using a chain with the wrong gauge on my chainsaw. The chain didn’t fit properly in the bar groove, causing excessive vibration and making it difficult to control the saw. I quickly realized my error and switched to the correct chain, which immediately resolved the problem.

Example: Your chain has a pitch of 0.325 inch and a gauge of 0.050 inch. You need to ensure that the bar you use is designed for a 0.325-inch pitch and a 0.050-inch gauge.

Why This Works: Matching the chain pitch and gauge to the bar specifications is essential for proper chain fit and safe operation.

Potential Challenges: Identifying the pitch and gauge can be difficult if the markings on the chain are worn or illegible. In this case, you might need to use a specialized tool to measure the pitch and gauge accurately.

Chainsaw Bar Maintenance Tips

Once you have the correct bar size and chain, proper maintenance is crucial for extending their lifespan and ensuring optimal performance. Here are some essential maintenance tips:

Regular Cleaning: Clean the bar groove regularly to remove sawdust, dirt, and debris. Use a bar groove cleaner or a small screwdriver to clear the groove.
Lubrication: Ensure that the bar and chain are properly lubricated. Use a high-quality bar and chain oil and check the oil level frequently.
Filing: Keep the chain sharp by filing the cutters regularly. Use a chain filing kit with the correct file size and angle.
Bar Dressing: Periodically dress the bar to remove burrs and uneven wear. Use a bar dressing tool or a flat file.
Chain Tension: Maintain proper chain tension. The chain should be snug against the bar but still able to be pulled around by hand.
Storage: Store the bar and chain in a dry place when not in use. Consider using a bar cover to protect the bar from damage.

Common Mistakes to Avoid

Guessing the Bar Size: Never guess the bar size. Always measure the existing bar or consult the user manual.
Ignoring Chain Pitch and Gauge: Failing to match the chain pitch and gauge to the bar specifications can lead to serious problems.
Over-Tightening the Chain: Over-tightening the chain can cause excessive wear on the bar and chain.
Neglecting Lubrication: Insufficient lubrication can lead to premature wear and damage to the bar and chain.
Using the Wrong Oil: Using the wrong type of oil can damage the bar and chain and reduce their lifespan.

Understanding Different Types of Chainsaw Bars

Different types of chainsaw bars are designed for specific applications and offer varying levels of performance and durability. Here’s a breakdown of some common types:

Laminated Bars: These are the most common type of chainsaw bar, consisting of multiple layers of steel laminated together. They are relatively lightweight and affordable, making them suitable for general-purpose use.
Solid Bars: Solid bars are made from a single piece of steel, making them more durable and resistant to bending and wear. They are typically used for heavy-duty applications such as professional logging and felling large trees.
Sprocket Nose Bars: These bars have a sprocket at the tip, which helps to reduce friction and improve cutting speed. They are often used for high-speed cutting and limbing.
Carving Bars: Carving bars are narrow and have a small radius at the tip, allowing for precise and intricate cuts. They are specifically designed for chainsaw carving.

Choosing the Right Bar Length for Your Needs

The ideal bar length for your chainsaw depends on the type of cutting you’ll be doing and the size of the trees you’ll be working with. Here are some general guidelines:

12-16 inches: Suitable for limbing, pruning, and cutting small trees and branches. These shorter bars are lightweight and easy to maneuver, making them ideal for beginners and occasional users.
16-20 inches: A good all-around choice for cutting firewood, felling medium-sized trees, and general yard work. These bars offer a balance of cutting capacity and maneuverability.
20-24 inches: Best for felling larger trees and cutting thick logs. These longer bars provide increased reach and cutting power, but they can be more challenging to handle.
24 inches and longer: Primarily used by professional loggers for felling very large trees. These bars require significant skill and experience to operate safely and effectively.

Safety First: Essential Chainsaw Safety Tips

Operating a chainsaw can be dangerous if proper safety precautions are not followed. Here are some essential safety tips to keep in mind:

Wear Appropriate Safety Gear: Always wear a helmet, eye protection, hearing protection, gloves, chainsaw chaps, and sturdy boots when operating a chainsaw.
Read the User Manual: Familiarize yourself with the chainsaw’s user manual and follow all safety instructions.
Inspect the Chainsaw: Before each use, inspect the chainsaw for any damage or loose parts. Ensure that the chain is properly sharpened and tensioned.
Maintain a Safe Distance: Keep bystanders and pets at least 50 feet away from the cutting area.
Use Proper Cutting Techniques: Use proper cutting techniques to avoid kickback and other hazards.
Be Aware of Your Surroundings: Be aware of your surroundings and watch out for obstacles, such as rocks, roots, and overhead branches.
Never Cut Above Shoulder Height: Avoid cutting above shoulder height, as this can be dangerous and difficult to control.
Take Breaks: Take frequent breaks to avoid fatigue, which can increase the risk of accidents.
Never Operate a Chainsaw Under the Influence: Never operate a chainsaw under the influence of alcohol or drugs.

Advanced Techniques for Wood Processing

Once you’ve mastered the basics of chainsaw operation and maintenance, you can explore more advanced techniques for wood processing, such as:

Timber Grading: Understanding timber grading allows you to select the best wood for specific applications, such as construction, furniture making, or firewood.
Sawmill Operations: Learning about sawmill operations can help you process logs into lumber efficiently and effectively.
Wood Drying: Proper wood drying is essential for preventing warping, cracking, and decay.
Splitting Techniques: Efficient splitting techniques can save you time and effort when preparing firewood.

The Future of Chainsaw Technology

Chainsaw technology is constantly evolving, with new innovations aimed at improving performance, safety, and efficiency. Some of the latest trends include:
