Dump Trailer Wood Sides (3 Pro Tips for Sturdy Arborist Builds)

The crackling fire, the scent of burning wood – there’s a primal comfort in warmth. For many of us, that warmth begins long before the first match is struck. It starts with the felling of a tree, the processing of logs, and finally, the stacking of firewood, ready to combat the chill. And often, at the heart of that process, is a trusty dump trailer, made even more effective with sturdy wood sides. Over the years, I’ve learned a thing or two about building those sides, and I’m here to share my hard-earned wisdom.

Dump Trailer Wood Sides: 3 Pro Tips for Sturdy Arborist Builds

As an arborist, I’m constantly moving wood. Whether it’s clearing storm damage, removing hazardous trees, or simply thinning out overgrown areas, a reliable dump trailer is essential. But the factory-installed sides often fall short, especially when dealing with heavy loads of green wood or awkwardly shaped logs. That’s where custom-built wood sides come in. They increase capacity, provide better containment, and, when built correctly, add significant structural integrity to the trailer.

1. Choosing the Right Wood and Design for Durability

The first, and arguably most crucial, step is selecting the right materials. Don’t skimp here. The wood you choose will determine the lifespan and strength of your trailer sides.

Wood Selection: Hardwoods Reign Supreme

I’ve experimented with various types of wood over the years, and I’ve found that hardwoods are the only way to go for long-term durability. Softwoods like pine or fir might seem like a cheaper option initially, but they’ll quickly succumb to rot, impact damage, and the sheer weight of the wood you’re hauling.

Here’s a breakdown of my preferred hardwoods:

• Oak: The gold standard. Oak is incredibly strong, resistant to rot, and readily available in most areas. White oak is even more rot-resistant than red oak, but both are excellent choices. Expect to pay a premium for oak, but consider it an investment.
  • Typical Cost: $3 – $6 per board foot (depending on grade and region)
  • Density: ~45-55 lbs per cubic foot
• Ash: A close second to oak. Ash is strong, relatively lightweight, and has good shock resistance. It’s also easier to work with than oak, making it a good choice if you’re new to woodworking.
  • Typical Cost: $2 – $5 per board foot
  • Density: ~40-48 lbs per cubic foot
• Maple: Another solid choice. Maple is strong and durable, although it’s slightly less rot-resistant than oak or ash. However, it’s readily available and often more affordable.
  • Typical Cost: $2 – $4 per board foot
  • Density: ~35-45 lbs per cubic foot

Important Considerations:

• Moisture Content: Always use kiln-dried lumber. Green wood will shrink and warp as it dries, weakening your structure. Aim for a moisture content of 12-15%.
• Grading: Look for lumber that is graded as “Select” or “Number 1 Common.” These grades have fewer knots and imperfections, resulting in stronger, more reliable sides.
• Treatment: Consider treating the wood with a preservative to further enhance its rot resistance. Copper naphthenate is a good option.
• Thickness: I recommend a minimum thickness of 2 inches for the vertical supports and 1.5 inches for the side boards. This provides ample strength to withstand the loads you’ll be hauling.

Design Considerations: Strength in Structure

The design of your wood sides is just as important as the wood itself. A well-designed structure will distribute the load evenly and prevent stress points that could lead to failure.

Here are some key design elements I’ve incorporated into my own dump trailer builds:

• Vertical Supports: These are the backbone of your structure. Space them no more than 24 inches apart. I use 4×4 oak posts for my vertical supports, ensuring they are securely bolted to the trailer frame.
  • Pro Tip: Weld steel plates to the trailer frame where the vertical supports will attach. This provides a much stronger and more secure connection than simply bolting to the frame.
• Horizontal Side Boards: These boards run horizontally between the vertical supports. I use 2×6 oak boards for my side boards, overlapping them slightly to create a stronger, more rigid structure.
  • Pro Tip: Use tongue-and-groove boards for a tighter, more weather-resistant seal.
• Top Rail: A top rail adds significant strength and rigidity to the entire structure. I use a 2×6 oak board for my top rail, securely fastening it to the vertical supports.
• Reinforcement: For extra-heavy loads, consider adding diagonal bracing to the sides. This will prevent the sides from flexing outward under pressure.
• Hinged or Removable Sections: Think about incorporating hinged or removable sections into your design. This allows you to easily load and unload materials from the side of the trailer.
  • Pro Tip: Use heavy-duty hinges and latches to ensure that the hinged sections are secure.

Example Design Measurements for an 8-foot Dump Trailer:

• Vertical Supports: 4×4 oak posts, 48 inches tall, spaced 24 inches apart (5 posts total)
• Horizontal Side Boards: 2×6 oak boards, 96 inches long, 3 boards per side, overlapping by 1 inch
• Top Rail: 2×6 oak board, 96 inches long
• Fasteners: 1/2-inch diameter bolts, washers, and lock nuts for attaching vertical supports to the trailer frame. 3-inch exterior-grade screws for attaching side boards and top rail to the vertical supports.

Case Study: My Oak-Reinforced Dump Trailer

Several years ago, I built a set of wood sides for my 10-foot dump trailer using the principles I’ve outlined above. I used 4×4 oak vertical supports, 2×6 oak side boards, and a 2×6 oak top rail. I also welded steel plates to the trailer frame for added support. The result was a rock-solid structure that has held up incredibly well over the years. I’ve hauled countless loads of green wood, gravel, and even demolition debris without any signs of weakness or failure. The initial investment in high-quality materials and careful construction has paid off handsomely in terms of durability and reliability.

Takeaway: Choosing the right wood and design is paramount. Invest in hardwoods like oak or ash, and design a structure with strong vertical supports, overlapping side boards, and a sturdy top rail.

2. Mastering Fastening Techniques for a Solid Build

Even with the best materials and design, a poorly fastened structure will eventually fail. The key is to use the right fasteners and techniques to create a strong, durable connection between the wood and the trailer frame.

Fastener Selection: Bolts, Screws, and More

I’ve used a variety of fasteners over the years, and I’ve found that a combination of bolts and screws works best for building dump trailer wood sides.

• Bolts: Use bolts to attach the vertical supports to the trailer frame. This is the most critical connection point, so you need a fastener that can withstand significant shear forces. I recommend using 1/2-inch diameter bolts with washers and lock nuts.
  • Pro Tip: Drill pilot holes slightly smaller than the diameter of the bolt to ensure a tight fit.
• Screws: Use screws to attach the side boards and top rail to the vertical supports. I recommend using 3-inch exterior-grade screws. These screws are designed to resist corrosion and provide a strong, reliable hold.
  • Pro Tip: Use a countersinking drill bit to create a recess for the screw heads. This will prevent the screw heads from protruding and catching on materials.
• Nails: Avoid using nails for structural connections. Nails are not as strong as bolts or screws and are more likely to pull out over time.

Fastening Techniques: The Devil is in the Details

The way you fasten the wood together is just as important as the fasteners themselves. Here are some key techniques to keep in mind:

• Pre-Drilling: Always pre-drill pilot holes for screws and bolts. This will prevent the wood from splitting and make it easier to drive the fasteners.
• Staggered Screws: When attaching side boards to the vertical supports, stagger the screws. This will distribute the load more evenly and prevent the wood from splitting.
• Proper Torque: When tightening bolts, use a torque wrench to ensure that they are tightened to the proper specification. Over-tightening can damage the wood or the bolt, while under-tightening can result in a loose connection.
  • Pro Tip: Consult a torque chart for the recommended torque specifications for different bolt sizes and materials.
• Lock Nuts: Use lock nuts on all bolts to prevent them from loosening over time. Lock nuts have a nylon insert that creates friction and prevents the nut from backing off.
• Washers: Use washers under the bolt heads and nuts to distribute the load and prevent the fasteners from digging into the wood.
• Countersinking: Countersink all screw heads to prevent them from protruding and catching on materials.

Example Fastening Schedule for a Vertical Support:

• Attach the vertical support to the trailer frame using four 1/2-inch diameter bolts, washers, and lock nuts.
• Space the bolts evenly, with two bolts near the top of the support and two bolts near the bottom.
• Tighten the bolts to the recommended torque specification (e.g., 75 ft-lbs for a 1/2-inch bolt).

My Experience with a Bolt Failure (and How I Prevented It)

I once had a bolt fail on one of my dump trailer wood sides. I was hauling a particularly heavy load of green oak logs, and the bolt simply sheared off. The failure was due to a combination of factors: I had used a lower-grade bolt than I should have, and I had over-tightened it, weakening the metal.

Since then, I’ve been much more careful about selecting the right bolts and tightening them to the proper torque specification. I also make sure to inspect the bolts regularly for signs of wear or damage.

Takeaway: Use high-quality bolts and screws, pre-drill pilot holes, stagger your screws, and tighten your bolts to the proper torque specification. Regular inspection is also key.

3. Protecting Your Investment: Sealing and Maintenance

Once you’ve built your sturdy wood sides, you’ll want to protect them from the elements and ensure they last for years to come. This involves sealing the wood and performing regular maintenance.

Sealing the Wood: Combatting Moisture

Moisture is the enemy of wood. It can lead to rot, decay, and warping, all of which will weaken your trailer sides. Sealing the wood is essential to prevent moisture from penetrating and causing damage.

Here are some effective sealing options:

• Paint: Painting the wood provides a good barrier against moisture and UV rays. Use a high-quality exterior paint that is designed for use on wood.
  • Pro Tip: Apply two coats of paint for maximum protection.
• Stain: Staining the wood allows the natural grain to show through while still providing some protection against moisture. Use a stain that contains a sealant.
  • Pro Tip: Choose a stain color that complements the color of your trailer.
• Water Repellent: Applying a water repellent is a simple and effective way to protect the wood from moisture. Use a water repellent that is specifically designed for use on wood.
  • Pro Tip: Reapply the water repellent every year to maintain its effectiveness.
• Oil-Based Sealant: Oil-based sealants penetrate the wood and provide excellent protection against moisture. Linseed oil is a popular choice.
  • Pro Tip: Apply several coats of oil, allowing each coat to dry completely before applying the next.
• Epoxy Resin: For maximum protection, consider coating the wood with epoxy resin. Epoxy resin is waterproof, durable, and resistant to chemicals.
  • Pro Tip: Epoxy resin can be expensive and difficult to apply, but it provides the best possible protection for your wood sides.

My Preferred Sealing Method: A Two-Part Approach

Over the years, I’ve developed a two-part sealing method that I’ve found to be particularly effective. First, I apply two coats of a penetrating oil-based sealant, such as boiled linseed oil. This helps to protect the wood from within. Then, I apply two coats of a high-quality exterior paint. This provides an additional layer of protection against moisture and UV rays.

Maintenance: Keeping Your Sides in Top Shape

Even with the best sealing, your wood sides will require regular maintenance to keep them in top shape.

Here are some key maintenance tasks:

• Regular Inspections: Inspect your wood sides regularly for signs of damage, such as cracks, rot, or loose fasteners.
  • Pro Tip: Pay particular attention to the areas around the fasteners, as these are the most likely to develop problems.
• Tightening Fasteners: Tighten any loose fasteners immediately. Loose fasteners can weaken the structure and lead to further damage.
• Replacing Damaged Wood: Replace any damaged wood as soon as possible. Rotting or cracked wood can compromise the integrity of the entire structure.
• Re-Sealing: Re-seal the wood every year or two to maintain its protection against moisture.
• Cleaning: Clean the wood sides regularly to remove dirt, debris, and mildew. Use a mild soap and water solution.
• Storage: When not in use, store your dump trailer in a covered area to protect it from the elements.
• Check for Wear and Tear: Routinely check the wood for signs of wear and tear, especially after heavy use. Look for cracks, splits, or areas where the wood is becoming soft.
• Address Issues Promptly: If you notice any issues, address them promptly to prevent them from escalating into more significant problems.

My Annual Maintenance Ritual

Every spring, I perform a thorough inspection of my dump trailer wood sides. I tighten any loose fasteners, replace any damaged wood, and re-seal the wood. This annual maintenance ritual takes a few hours, but it ensures that my wood sides will last for many years to come.

Case Study: The Trailer I Almost Lost to Rot

I once neglected the maintenance on a set of wood sides I had built for a smaller trailer. I didn’t re-seal the wood regularly, and I didn’t catch a small patch of rot until it had spread significantly. By the time I realized the extent of the damage, the wood sides were beyond repair. I had to completely rebuild them, which was a costly and time-consuming process.

That experience taught me the importance of regular maintenance. Now, I’m much more diligent about inspecting and maintaining my wood sides.

Takeaway: Seal your wood sides to protect them from moisture, and perform regular maintenance to keep them in top shape. Regular inspections, tightening fasteners, and re-sealing are all essential.

Building sturdy wood sides for your dump trailer is an investment in its functionality and longevity. By choosing the right wood and design, mastering fastening techniques, and protecting your investment with sealing and maintenance, you can create a reliable and durable structure that will serve you well for years to come. Remember, the warmth of a fire starts long before the match is struck, and a well-maintained dump trailer with sturdy wood sides is a crucial part of that journey.
